APC SMX1500RM2UC UPS Line-interactive 1,44 kVA 1200 W 8 AC-uitgang(en)

APC SMX1500RM2UC, Line-interactive, 1,44 kVA, 1200 W, Sinus, 75 V, 154 V

Niet op voorraad

Fabrikant APC
MPN SMX1500RM2UC
EAN 0731304401131
€ 1.541,00 excl. BTW

APC SMX1500RM2UC UPS Line-interactive 1,44 kVA 1200 W 8 AC-uitgang(en)

Avoids costly power problems by keeping your IT equipment and data safe and available
Network grade power conditioning protects from damaging surges and disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% and trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems

Smarter productivity with ability to tailor to your specific application needs
Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds and notifications.

Save time with easy and convenient remote accessibility
Network manageable via serial, USB or optional ethernet. Includes Powerchute® Business Edition Software for convenient monitoring and control, safe operating system shutdown and innovative energy management capabilities.

Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.

Low operating and maintenance costs with high efficiency, proven reliability and intelligent battery management
Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Dynamic battery replacement date indicator and automatic self tests insure battery reliability and warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed and manufactured by APC for over 23 years, Smart-UPS is the world’s most trusted network UPS with over 25 million units sold.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

UPS-topologie*
Line-interactive
Output power capacity*
1,44 kVA
Uitgangsvermogen*
1200 W
Golfvorm*
Sinus
Ingang operation voltage (min)*
75 V
Ingang operation voltage (max)*
154 V
Frequentie*
50/60 Hz
Uitgang operation voltage (max)
120 V
Output frequentie
50/60 Hz
Automatic Voltage Regulation (AVR)
Ja
Stroom (max.)
12 A
Surge energy rating
645 J
Emergency Power Off (EPO)
Ja
Output voltage THD
5 procent
Geluidsniveau
40 dB
Stroomspanning bescherming
Kortsluiting
Geluidsalarm(en)
Ja
Hoorbare alarmstanden
Alarm bij werking op batterij, Alarm bij laag batterijniveau, Alarm bij overbelasting
Auto-herstart
Ja

Poorten & interfaces

Stopcontacttypes
NEMA 5-15R
Stekker
NEMA 5-15P
Aantal AC uitgangen
8 AC-uitgang(en)
USB-poort
Ja
Aantal USB 2.0-poorten
1
USB-poorttype
USB Type-B
Seriële interface
Ja
Soort serieële aansluiting
RS-232
SmartSlot
Ja

Accu/Batterij

Batterijtechnologie
Sealed Lead Acid (VRLA)
Ondersteund aantal accu's/batterijen
1
Acculevensduur (max)
5 jaar

Accu/Batterij

Accu/Batterij oplaadtijd
3 uur
Hot-swap batterij
Ja
Automatische batterij test
Ja

Design

Vormfactor*
Rackmontage/toren
Rackcapaciteit
2U
Snoerlengte
2,44 m
Kleur van het product*
Zwart
Type beeldscherm
LCD
LED-indicatoren
Ja
Certificering
cUL Listed, TAA compliance, UL 1778

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-15 - 45 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent
Luchtvochtigheid bij opslag
0 - 95 procent
Hoogte, in bedrijf
0 - 3000 m
Hoogte bij opslag
0 - 15000 m

Technische details

Duurzaamheidscertificaten
ENERGY STAR, RoHS

Gewicht en omvang

Breedte
432 mm
Diepte
490 mm
Hoogte
89 mm
Gewicht
24,8 kg
Breedte verpakking
589 mm
Diepte verpakking
620 mm
Hoogte verpakking
246 mm
Gewicht verpakking
30 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85078000
