Asustor AS-7008T data-opslag-server NAS Ethernet LAN Zwart, Grijs i3-4330

Asustor AS-7008T, NAS, Intel® Core™ i3, i3-4330, Zwart, Grijs

Niet op voorraad

Fabrikant ASUS
MPN 90IX00B1-BW3S10
EAN 4710474830466
€ 1.193,00 excl. BTW

Asustor AS-7008T data-opslag-server NAS Ethernet LAN Zwart, Grijs i3-4330

A Surge in Data Transfer Performance
ADM 2.6 supports SMB 2.0 which reduces the burden of network traffic on the NAS while simultaneously providing greater data transfer capacity.In the ASUSTOR testing environment, SMB 2.0 was found to increase Windows networking performance by 30%-50%. SMB 2.0 also significantly increases the number of concurrent Windows client connections and simultaneously open files, making ADM 2.6 even more suitable for large-scale Microsoft network environments.

Advanced File Permissions Management - Windows ACL
For IT professionals, file permissions configuration is a very important topic, especially in enterprise environments. Because the native Linux system file permission mechanisms are different than those in Windows, in the past, IT professionals had to create a separate set of permissions for files stored on NAS servers. This also limited the number of permission configuration options that were available to them.

In order to help IT professionals simply their work, ASUSTOR has comprehensively integrated Windows ACL into ADM. Windows ACL provides a set of 13 different permissions settings, allowing administrators to configure permissions for individual files and folders that can be applied to different groups and users. Windows ACL permissions can be configured from within ADM's File Explorer or Microsoft Windows Explorer allowing administrators to easily manage permissions using familiar methods.

Optimized Cooling Design
When there is a high load on the NAS, the CPU will begin to heat up, affecting the stability of the system. A common way of dealing with this is to lower the CPU frequency which will then cause the temperature to decrease. However, this will also lower the overall performance of the system.

ASUSTOR's 70 Series devices utilize fans with wide speed ranges combined with a smart speed control mechanism that allows the CPU to maintain a controlled operating temperature even under high loads. Under most circumstances the fans will operate at a low speed, conserving energy. When the system load and temperature increases, the fans will automatically increase their speed to cool the CPU without it having to lower its frequency. This allows the NAS to maintain stability and high performance even under high loads.

Extreme Multimedia Playback
No matter if it's 4K or 10bit, KODI 17 paired with the Intel Core i3 dual-core processor's powerful built-in graphics engine gives you the ability to play any video files with ease. Get ready to enjoy brilliant and flawless images on ultra high resolution monitors.

Additionally, you can also further add a surround sound amplifier to create an unprecedented high definition multi-channel listening experience. Imagine watching your favorite racing movie and being immersed in the roar of the engines. Feel the thrill and the sense of speed as you listen to the sounds of cars whizzing by. Prepare for an unparalleled entertainment experience that will have you on the edge of your seat.

Even More Reliable After-Sales Service
ASUSTOR has extended the warranty period on all of its products to three years, continuing to make customer service a huge priority. It is ASUSTOR's mission to continue to provide its customers with products of the highest quality along with only the most reliable and attentive after-sales service and technical support.

Secure Disk Tray Lock Design
In order to help users avoid accidentally pushing disk tray buttons and releasing hard disks during operation, ASUSTOR has added a new lock mechanism to its hard disk trays. The lock's flat-head design ensures that users will not need any special keys or tools to unlock it, only a simple flat-head screw driver. The new disks trays can be used with all ASUSTOR NAS devices, providing an additional layer of security for applications requiring the frequent swapping of hard disks (e.g., MyArchive).

We've got it Ready: 4K Ultra High Definition
ASUSTOR Portal offers complete support for 4K ultra high definition output. With 4K ultra high definition, the desktop background and icons appear clearer and sharper giving you a luxurious and immersive visual experience.

Create a Stable, Reliable and High Quality Surveillance System
The powerful 70 Series devices provide you with stress free reliability when installing a surveillance system in your home or office environment. Installing the Surveillance Center App from App Central instantly turns your NAS into 24/7, high definition surveillance system. Surveillance Center provides comprehensive cross-platform support, allowing both Windows and Mac users to use familiar web browsers to access their surveillance feeds. Furthermore, ASUSTOR also offers the free AiSecure mobile app that gives users access to all their surveillance feeds while on the go. AiSecure also provides the ability to receive instant push notifications from Surveillance Center, allowing users to keep up with the latest developments. No matter if you need to protect individual assets, loved ones or your business, the powerful 70 Series devices are your optimal choice when creating a comprehensive surveillance system.
  • Windows + Mac + Linux cross-platform file sharing
  • Windows ACL support combined with Windows AD infrastructure enhances management efficiency for business applications
  • Military grade AES 256-bit encryption
  • 10GbE Ethernet card and memory expansion slots allow for further expansion as the need arises
  • New disk tray locks ensure that hard disks will not be accidentally ejected during operation
  • SMB 2/3 support increases Windows networking performance by 30%-50%

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Opslagmedia

Opslag schijf-interface*
SATA II, SATA III
Opslag schijfgrootte
2.5/3.5"
Maximaal ondersteunde opslagcapaciteit
80 TB
RAID support*
Ja
Soorten RAID
0, 1, 5, 6, 10
Hot-swap drive bays
Ja
Opslagdrives geïnstalleerd*
Nee
Aantal storage drives ondersteund*
10
Geïnstalleerde opslag-drive*
Nee
Ondersteunde types opslag-drives*
HDD & SSD

Processor

Processorfabrikant*
Intel
Processorgeneratie
Vierde generatie Intel® Core™ i3
Processorfamilie*
Intel® Core™ i3
Processormodel*
i3-4330
Frequentie van processor*
3,5 GHz
Aantal processorkernen
2
Processor aantal threads
4
Processor cache
4 MB
Bus type
DMI2
CPU configuratie (max)
1
ECC ondersteund door processor
Ja
PCI Express configuraties
2x8, 1x8+2x4
Processor cache type
Smart Cache
Codenaam processor
Haswell
Processor lithografie
-, 22
Processor operating modes
64-bit
Verpakkingsgrootte processor
37.5 x 37.5 mm
Processor socket
LGA 1150 (Socket H3)
Schaalbaarheid
1S
Stepping
C0
Tcase
66,8 °C
Thermal Design Power (TDP)
65, 54
On-board graphics adapter model
Intel® HD Graphics 4600
Maximaal intern geheugen ondersteund door processor
32 GB
Geheugenbandbreedte ondersteund door de processor ( max)
25,6 GB/s
Conflictvrije processor
Ja

Geheugen

Intern geheugentype
DDR3
Ondersteund maximum RAM
16 GB
Intern geheugen*
2 GB

Netwerk

Ethernet LAN*
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s

Poorten & interfaces

USB-poort*
Ja
Aantal USB 2.0-poorten
2
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A
3
Aantal eSATA-poorten
2
Aantal HDMI-poorten
1
Aantal Ethernet LAN (RJ-45)-poorten*
2

Grafisch

Geheugen ingebouwde grafische adapter
1 GB
Basisfrequentie ingebouwde grafische adapter
350 MHz
Graphics on-board -adapter dynamische frequentie (max)
1150 MHz

Grafisch

On-board grafische adapter DirectX-versie
11.1
On-board grafische adapter ID
0x412
Maximaal geheugen ingebouwde grafische adapter
1,74 GB
Aantal displays ondersteund (door on-board grafische adapter)
3

Design

Kleur van het product
Zwart, Grijs
LED-indicatoren
HDD, Stroom, Status
Ingebouwd display
Ja
Type beeldscherm
LCD

Prestatie

Soort*
NAS
Backup-functie*
Ja

Energie

Stroomverbruik (typisch)
350 W
Slaapstand
1,97 W
AC-ingangsspanning
100-240 V

Gewicht en omvang

Breedte*
293 mm
Diepte*
230 mm
Hoogte*
215,5 mm
Gewicht
6,7 kg

Processor speciale functies

Ingebouwde opties beschikbaar
Ja
Enhanced Intel SpeedStep Technology
Ja
Execute Disable Bit
Ja
Graphics & IMC lithografie
22 nm
Idle States
Ja
Intel® 64
Ja
Intel® Enhanced Halt State
Ja
Intel® Small Business Advantage (SBA)-versie
1,00
Intel® Stable Image Platform Program (SIPP)
Nee
Versie Intel® Stable Image Platform Program (SIPP)
0,00
Intel® Trusted Execution Technology
Nee
Intel® TSX-NI
Nee
Versie Intel® TSX-NI
0,00
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Nee
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® InTru™ 3D Technology
Ja
Intel® Quick Sync Video Technology
Ja
Intel® Turbo Boost Technology
Nee
Intel® Wireless Display (Intel® WiDi)
Ja
Maximaal aantal PCI Express-lijnen
16
Thermal Monitoring Technologies
Ja
Thermal solution specificatie
PCG 2013C
Geheugenkanalen ondersteund door processor
Dual

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84714100

Overige specificaties

ARK ID processor
77769
