ASUS TUF GAMING Z690-PLUS Intel Z690 LGA 1700 ATX

ASUS TUF GAMING Z690-PLUS, Intel, LGA 1700, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,..., LGA 1700, DDR5-SDRAM, 128 GB

Niet op voorraad

Fabrikant ASUS
MPN 90MB1AV0-M0EAY0
EAN 4711081646266
€ 284,00 excl. BTW

ASUS TUF GAMING Z690-PLUS Intel Z690 LGA 1700 ATX

ASUS TUF GAMING Z690-PLUS - bundkort -

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processor socket*
LGA 1700
Compatibele processors*
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Supported processor sockets
LGA 1700

Geheugen

Ondersteunde geheugen types*
DDR5-SDRAM
Aantal geheugenslots*
4
Geheugen slots type
DIMM
Geheugen kanaal
Dubbelkanaals
ECC-compatibiliteit
Niet-ECC
Supported memory clock speeds
4800,5000,5200,5400,5600,5800,6000 MHz
Maximum intern geheugen*
128 GB
Niet gebufferd geheugen
Ja

Opslag-controllers

Ondersteunde types opslag-drives
HDD & SSD
Ondersteunde opslagstationinterfaces*
M.2, Micro SATA III, NVMe, PCI Express 4.0
Maximum aantal HDD's per behuizing
4
Aantal storage drives ondersteund
8
RAID support
Ja
Soorten RAID
0, 1, 5, 10

Grafisch

Ondersteuning voor parallel processing*
Niet ondersteund

Interne aansluitingen

USB 2.0 aansluitingen*
2
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen*
1
USB 3.2-connectoren (3.1 Gen 2)*
1
Aantal SATA III connectors*
4
Aansluiting voor audiopaneel aan voorzijde
Ja
Voorpaneel-connector
Ja
ATX Power connector (24-pin)
Ja
Aansluiting voor CPU koeler
Ja
Aansluitingen voor behuizingsventilatoren
4
Chassis intrusion aansluiting
Ja
EPS power connector (8-pin)
Ja
COM aansluitingen
1
Thunderbolt-headers
1
12V vermogen-connector
Ja
RGB LED-aansluitrail
Ja

Aansluitingen achterzijde

Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A*
4
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C*
1
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A*
2

Aansluitingen achterzijde

Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C*
1
Aantal Ethernet LAN (RJ-45)-poorten*
1
Aantal HDMI-poorten*
1
HDMI versie
2.1
Aantal DisplayPorts
1
DisplayPort versie
1.4
Hoofdtelefoonuitgangen
5
Digitale audio, optische uitgang
1

Netwerk

Ethernet LAN
Ja
Ethernet interface type
2.5 Gigabit Ethernet
Wifi*
Nee

Kenmerken

Chipset moederbord*
Intel Z690
Audio-uitgangskanalen*
7.1 kanalen
Component voor*
PC
Moederbord form factor*
ATX
Moederbord chipset familie*
Intel
Type stroombron
ATX
Aantal montagegaten
9
Ondersteunt Windows
Windows 10 x64, Windows 11 x64

Uitbreidingsmodules

PCI Express x1 (Gen 3.x) slots
2
PCI Express x4 slots
1
PCI Express x16 (Gen 3.x) slots
1
PCI Express x16 (Gen 5.x) sleuven
1
Aantal M.2 (M) slots
4

BIOS

BIOS type*
UEFI AMI
Grootte BIOS-geheugen
192 Mbit
Clear CMOS jumper
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84733020

Gewicht en omvang

Breedte
305 mm
Diepte
244 mm
Hoogte
71 mm

Inhoud van de verpakking

Meegeleverde kabels
SATA

Overige specificaties

Gewicht
1,43 kg
