Axis T8504-E Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Wit

Axis T8504-E, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)

Niet op voorraad

Fabrikant Axis
MPN 01449-001
EAN 7331021063488
€ 1.755,00 excl. BTW

Axis T8504-E Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Wit

AXIS T8504-E Outdoor PoE Switch gives you a quick, easy way to deploy outdoor cameras over long distances and keep your installation costs low. With an integrated SFP port, it’s perfect for fiber-based installation. It’s also a robust, low-upkeep solution – but if and when maintenance work is needed, remote management makes taking care of it a simple matter.

For long distance connections
AXIS T8504-E is specifically designed for fiber-optic connections, which are typically used in city surveillance, airports and other long distance installations. Made for the surveillance industry AXIS T8504-E is a perfect complement to both Axis solutions and third party products.

Easy to install and configure
Just like all Axis product, AXIS T8504-E is easy to install using standard Axis tools like AXIS Camera Management and AXIS IP utility. AXIS IP Utility even automatically discover and displays Axis devices on the network and helps you set the IP address of Axis network video products.
  • Plug-and-play installation
  • SFP port – for fiber installation
  • Power over Ethernet (PoE)
  • Up to 60 W per port (total 150 W)
  • IP67 rating

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
4
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF
1
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.1Q, IEEE 802.3af, IEEE 802.3at
10G support*
Nee
Koperen ethernetbekabelingstechnologie
10BASE-T, 100BASE-TX, 1000BASE-T
VLAN=ondersteuning
Ja

Data-uitwisseling

Switchingcapaciteit*
20 Gbit/s
Throughput
14,9 Mpps
MAC-adrestabel*
8000 entries
Jumbo Frames ondersteuning
Ja
Jumbo frames
9216

Beveiliging

Ondersteunde beveiligingsalgoritmen
HTTPS, SNMP, SNMPv3, SSH
Wachtwoordbeveiliging
Ja

Protocollen

Ondersteunde netwerkprotocollen
IPv4, IPv6, HTTP, HTTPS, Bonjour, SNMP v1/v2c/v3, DNS, TCP, UDP, IGMP, ICMP, ARP, SSH, RADIUS, TACACS, TELNET, Syslog, 802.1Q (VLAN)

Design

Kleur van het product
Wit
Materiaal behuizing
Aluminium
Internationale veiligheidscode (IP)
IP67
Veiligheid
IEC/EN/UL 60950-1, IEC/EN/UL 60950-22, EAC
Elektromagnetische compatibiliteit
EN 55032 B, EN 55024, FCC 15 B B, RCM AS/NZS CISPR 32 B, EN 61000-4-5 5, EN 50121-4, IEC 62236-4

Design

Certificering
IEC 60529 IP67, NEMA 250 4X, GR-1089-CORE 4 ITU-T K.20

Prestatie

Plug and play
Ja

Energie

AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Spanningsbeveiliging
Ja
Overspanningsbeveiliging in voltage
6 kV

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Vermogen per poort Power over Ethernet (PoE)
60 W
Totaal Power over Ethernet (PoE)-budget
150 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-40 - 50 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 90 procent
Luchtvochtigheid bij opslag
0 - 90 procent

Gewicht en omvang

Breedte
240 mm
Diepte
166 mm
Hoogte
72 mm
Gewicht
2,9 kg

Verpakking

Gebruiksaanwijzing
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
