Corsair HX1000i power supply unit 1000 W 24-pin ATX ATX Zwart
POWERFUL CONNECTIONS
With three EPS12V connectors and fully modular cabling, HXi Series platinum power supplies have every connection needed to power today’s most demanding PC upgrades now and into the future, including the latest generation of power-hungry graphics cards and processors.
ON THE CUTTING-EDGE
ATX 3.0 CERTIFIED
The ATX 3.0 standard demands a high level of reliability and power efficiency. While many CORSAIR PSUs meet these requirements, HXi Series PSUs are formally certified for ATX 3.0 compliance.
PCIe 5.0 12VHPWR GPU cable included for use with modern graphics cards such as the NVIDIA® GeForce RTX™ 40 Series.
QUIET OPERATION
HXi Series PSUs combine a 140mm fluid dynamic bearing fan with Zero RPM mode support for long-lasting fan performance and near-silent operation when the fan switches off at low and medium loads – only spinning as fast as it needs to.
UNWAVERING POWER AND QUALITY
80 PLUS Platinum certified with premium 100% Japanese 105°C electrolytic capacitors, HXi PSUs ensure up to 92% efficiency for exceptional power delivery and long-term reliability with low power consumption, less noise, and cooler temperatures.
POWER AT THE READY
As a fully digital power supply, each HXi Series PSU provides clean, consistent power while minimizing coil whine and noise for stable and quiet operation.
Supporting Modern Standby sleep mode, the HXi Series takes low-load efficiency to the next level with quiet operation and extremely fast wake-from-sleep times.
80 PLUS PLATINUM CERTIFIED
Steady power output at up to 92% efficiency, and Cybenetics-certified for lower power consumption, less noise, and cooler temperatures.
105°C-RATED CAPACITORS
Built with 100% Industrial-grade, 105°C-rated Japanese primary electrolytic capacitors for unwavering power and reliability.
iCUE SOFTWARE
YOUR SETUP AT YOUR COMMAND
With CORSAIR iCUE Software, you can monitor your power supply performance, toggle single rail or multi rail mode, and control fan speed directly from your desktop.
WORLD-CLASS SUPPORT
Our award-winning service means you can enjoy your gear worry-free.
With three EPS12V connectors and fully modular cabling, HXi Series platinum power supplies have every connection needed to power today’s most demanding PC upgrades now and into the future, including the latest generation of power-hungry graphics cards and processors.
ON THE CUTTING-EDGE
ATX 3.0 CERTIFIED
The ATX 3.0 standard demands a high level of reliability and power efficiency. While many CORSAIR PSUs meet these requirements, HXi Series PSUs are formally certified for ATX 3.0 compliance.
PCIe 5.0 12VHPWR GPU cable included for use with modern graphics cards such as the NVIDIA® GeForce RTX™ 40 Series.
QUIET OPERATION
HXi Series PSUs combine a 140mm fluid dynamic bearing fan with Zero RPM mode support for long-lasting fan performance and near-silent operation when the fan switches off at low and medium loads – only spinning as fast as it needs to.
UNWAVERING POWER AND QUALITY
80 PLUS Platinum certified with premium 100% Japanese 105°C electrolytic capacitors, HXi PSUs ensure up to 92% efficiency for exceptional power delivery and long-term reliability with low power consumption, less noise, and cooler temperatures.
POWER AT THE READY
As a fully digital power supply, each HXi Series PSU provides clean, consistent power while minimizing coil whine and noise for stable and quiet operation.
Supporting Modern Standby sleep mode, the HXi Series takes low-load efficiency to the next level with quiet operation and extremely fast wake-from-sleep times.
80 PLUS PLATINUM CERTIFIED
Steady power output at up to 92% efficiency, and Cybenetics-certified for lower power consumption, less noise, and cooler temperatures.
105°C-RATED CAPACITORS
Built with 100% Industrial-grade, 105°C-rated Japanese primary electrolytic capacitors for unwavering power and reliability.
iCUE SOFTWARE
YOUR SETUP AT YOUR COMMAND
With CORSAIR iCUE Software, you can monitor your power supply performance, toggle single rail or multi rail mode, and control fan speed directly from your desktop.
WORLD-CLASS SUPPORT
Our award-winning service means you can enjoy your gear worry-free.
- Compatible with NVIDIA 4000 series and AMD® Ryzen 7000 series GPUs
- Magnetic Levitation fan with Zero RPM mode
- 105°C rated 100% Japanese electrolytic capacitors
- ATX 3.0 & PCIe 5.0 certified
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Energie
Totaal vermogen*
1000 W
AC-ingangsspanning*
100 - 240 V
AC-ingangsfrequentie
47 - 63 Hz
Gecombineerd vermogen (+3.3V)
150 W
Gecombineerd vermogen (+12V)
999,6 W
Gecombineerd vermogen (+5V)
150 W
Gecombineerd vermogen(+5Vsb)
15 W
Max huidige output (+3.3V)
25 A
Max huidige output(+12V)
83,3 A
Max huidige output (+5V)
25 A
Max huidige output (+5Vsb)
3 A
Efficientie
92 procent
Poorten & interfaces
Motherboard power connector*
24-pin ATX
Aantal SATA power connectors
8
Peripheral (Molex) power connectors (4-pin)*
8
EPS-voedingsconnector (4+4 pin)
Ja
PCI Express power connectors (6+2 pin)
4
Poorten & interfaces
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen
1
Bekabelingstype
Modulair
Prestatie
80 PLUS certificatie*
80 PLUS Platinum
Bedoeld voor*
PC
Vormfactor van de voeding (PSU)*
ATX
ATX version
3.0
Stille modus
Ja
Design
Kleur van het product
Zwart
Ventilator diameter
14 cm
Aantal ventilatoren
1 ventilator(en)
Aan/uitschakelaar
Ja
Inhoud van de verpakking
Meegeleverde kabels
AC
Inclusief kabelbinder(s)
Ja
USB kabel lengte
0,525 m
