D-Link DBA-2520P draadloos toegangspunt (WAP) 1900 Mbit/s Wit Power over Ethernet (PoE)

D-Link DBA-2520P, 1900 Mbit/s, 600 Mbit/s, 1299 Mbit/s, 10,100,1000 Mbit/s, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3ab,..., Multi User MIMO

Nog 3 beschikbaar (bel voor reservering)

MPN DBA-2520P
EAN 0790069448195
€ 571,00 excl. BTW

D-Link DBA-2520P draadloos toegangspunt (WAP) 1900 Mbit/s Wit Power over Ethernet (PoE)

Cloud Networking, Refreshed
The DBA-2520P Access Point (AP) is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of IT infrastructure as simple and hassle-free as possible.

Built for Heavy Workloads
The DBA-2520P delivers high-speed wireless AC (Wave 2) connection reliably, with maximum wireless signal rates of up to 1.9Gbps, and 3 x 3 MIMO (three spatial streams). Performance is further optimized via the Nuclias Cloud platform which adjusts the DBA-2520P’s channel selection, transmission power, and maximum number of client connections.

Advanced Management & Security
The Nuclias Cloud interface gives lets admins easily manage Layer-2 features, such as VLANs and Spanning Tree Protocol (STP). With SSID isolation, MAC address filtering, and end-to-end encryption, this is a versatile solution for those seeking easy configuration, without added complexities.

Full PoE Support
The DBA-2520P Access Point supports Power over Ethernet (IEEE 802.3at standard) for its Gigabit LAN port. Power over Ethernet greatly simplifies the installation of compatible devices such as VoIP phones and IP cameras in remote locations that lack easy access to a power outlet.
  • Zero-Touch Deployment
  • Cloud Management
  • 99.9% Service Level Agreement (SLA)
  • Intuitive Interface
  • Traffic Reporting & Analytics
  • Searchable & Auditable Event & Change Logs
  • Power-over-Ethernet
  • Multi-Tenant & Role-Based Administration
  • Authentication via Customizable Captive Portal, 802.1x and RADIUS Server, with Social Login

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

2,4 GHz*
Ja
5 GHz*
Ja
Maximale overdrachtssnelheid van gegevens*
1900 Mbit/s
Maximale overdrachtssnelheid van gegevens (2.4 GHz)
600 Mbit/s
Maximale overdrachtssnelheid van gegevens (5 GHz)
1299 Mbit/s
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Netwerkstandaard
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
MIMO
Ja
MIMO-type
Multi User MIMO
Datastroombeheer
Ja
Zendvermogen
25 dBmW

Beveiliging

Ondersteunde beveiligingsalgoritmen*
SSID, WPA, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK
MAC adres filtering
Ja
Aantal SSID-ondersteuningen
16

Protocollen

DHCP server
Ja

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
2

Energie

Power over Ethernet (PoE)*
Ja
Spanning
12 V
Output current
2,5 A
Stroomverbruik (typisch)
16,92 W
Vermogensverbruik (max)
19,68 W

Design

Plaatsing*
Plafond, Tafel, Muur
Kleur van het product*
Wit
Bevestigingsmogelijkheid voor kabelslot
Ja
Kabelslot sleuf type
Kensington
Certificering
CE B, FCC B, UL, IC B

Antenne

Soort antenne*
Intern
Type antennerichting
Omni-directioneel
Antennas quantity
2
Antenne versterkingsniveau (max)
4 dBi

Gewicht en omvang

Breedte
224,5 mm
Diepte
223,8 mm
Hoogte
50 mm
Gewicht
811 g

Inhoud van de verpakking

Aantal producten inbegrepen
1 stuk(s)

Eisen aan de omgeving

Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-20 - 65 °C
Luchtvochtigheid bij opslag
5 - 95 procent

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
