D-Link DBS-2000-28MP/E netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grijs

D-Link DBS-2000-28MP/E, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack-montage

Niet op voorraad

MPN DBS-2000-28MP/E
EAN 0790069471247
€ 637,00 excl. BTW

D-Link DBS-2000-28MP/E netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grijs

Cloud Networking, Refreshed
The DBS-2000 series of switches is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of your IT infrastructure as simple and hassle-free as possible.

Management Over the Cloud
DBS-2000 is a series of Smart Managed Switches, manageable via the Nuclias Cloud Web Portal through any compatible online PC or Tablet. Connectivity with the Nuclias Cloud platform is guaranteed, with a 99.9% Service-Level-Agreement (SLA), and operation will continue even if the Cloud connection fails.

Easy Troubleshooting
The DBS-2000 Series features Cable Diagnostics and Per Port Traffic Packet Counters to help network admins find & solve network problems. Cable Diagnostics enables quick examination of cable quality, recognition of cable type, and detection of cable errors, with the Per-Port Traffic Packet Counter helping to further isolate problems.

Advanced Security Features
The DBS-2000 series utilizes the Nuclias Cloud Web Portal interface, giving administrators an easy way to manage Layer-2 features, such as VLANs, Spanning Tree Protocol (STP), and 802.3ad Link Aggregation (static). With powerful security features, including IGMP snooping, Static MAC, and end-to-end encryption (WPA/WPA2/WPA3), these Cloud switches are a versatile solution for deployments that require easy configuration, without added complexities.

Full PoE Support
Select models in the DBS-2000 Series support Power over Ethernet (PoE) for copper access ports. Power over Ethernet greatly simplifies the installation of PoE-enabled devices such as VoIP phones and IP cameras in remote locations with no immediate access to a power outlet.
  • 24 x 10/100/1000BASE-T PoE ports
  • 4 x 10/100/1000BASE-T ports
  • 370W PoE power budget
  • Supports IEEE 802.3at PoE
  • Zero-Touch Deployment
  • Cloud Management w/99.9% SLA
  • WPA/WPA2/WPA3 Encryption
  • Innovative D-Link Green Energy-saving features
  • Intuitive Web Portal for comprehensive switch management
  • Multilingual Support

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Web-gebaseerd management
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Combo SFP-poorten
4
Console port
RJ-45

Netwerk

Netwerkstandaard*
IEEE 802.3ad, IEEE 802.3at
10G support*
Nee
Koperen ethernetbekabelingstechnologie
10BASE-T, 100BASE-TX, 1000BASE-T
Verbindingsaggregatie
Ja
Auto MDI/MDI-X
Ja
Spanning tree protocol
Ja

Data-uitwisseling

Switchingcapaciteit*
56 Gbit/s
Verzending snelheid
41,7 Mpps
MAC-adrestabel*
8000 entries
Packet buffergeheugen
4,1 MB

Beveiliging

IGMP snooping
Ja
Ondersteunde beveiligingsalgoritmen
WPA, WPA2

Design

Rack-montage*
Ja
Kleur van het product
Grijs
LED-indicatoren
Ja

Prestatie

Type processor
Ja
Frequentie van processor
500 MHz
Type geheugen
DDR3-SDRAM
Intern geheugen
256 MB
Flash memory
32 MB
Mean time between failures (MTBF)
277967 uur

Technische details

(Binnenste) verzendverpakking hoogte
39,3 cm
(Binnenste) verzendverpakking breedte
29,5 cm
(Binnenste) verzendverpakking lengte
53,9 cm
Nettogewicht transportverpakking
15,4 kg
Producten per (binnenste) verzendverpakking
3 stuk(s)

Technische details

Pallet brutogewicht (lucht)
409,5 kg
Aantal dozen per pallet (lucht)
24 stuk(s)
Aantal per pallet (lucht)
72 stuk(s)
Pallet brutolengte
110 cm
Pallet brutobreedte
120 cm
Pallethoogte (lucht)
131,4 cm
Pallet brutogewicht (zee)
670 kg
Aantal dozen per pallet (zee)
40 stuk(s)
Producten per pallet (zee)
120 stuk(s)
Pallethoogte (zee)
2,1 m
(Binnenste) verzendverpakking gewicht
16,2 kg

Energie

Stroombron*
DC/PoE
AC-ingangsspanning
100 - 240 V
Vermogensverbruik (max)
446,1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Hoeveelheid Power over Ethernet (PoE) ports
24
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
370 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-5 - 50 °C
Temperatuur bij opslag
-20 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent
Luchtvochtigheid bij opslag
0 - 95 procent
Hoogte, in bedrijf
0 - 1500 m
Warmtedissipatie
1521,99 BTU/h

Gewicht en omvang

Breedte
440 mm
Diepte
250 mm
Hoogte
44 mm
Gewicht
3,94 kg

Verpakking

Breedte verpakking
365 mm
Diepte verpakking
521 mm
Hoogte verpakking
92 mm
Gewicht verpakking
5,13 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
