D-Link DMS-1100-10TP netwerk-switch Managed L2 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Zwart

D-Link DMS-1100-10TP, Managed, L2, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack-montage, 1U

Ruim op voorraad (levering verwacht binnen 3 dagen)

MPN DMS-1100-10TP
EAN 0790069437168
€ 907,00 excl. BTW

D-Link DMS-1100-10TP netwerk-switch Managed L2 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Zwart

The D-Link DMS-1100 Series 2.5 Gigabit Ethernet Smart Managed Switches are a cost-effective 2.5 Gigabit switch series capable of servicing a range of network needs in any type of business. Featuring eight 2.5 Gigabit access ports and two 10 Gigabit SFP+ uplink ports, these switches are ideal for deploying high-performance 802.11ac Wave 2 access points using 2.5 Gigabit connections, while providing 10 Gigabit wire-speed uplinks for optimal bandwidth when accessing the larger local area network.

Seamless Integration and Future Proof

The DMS-1100 switches support IEEE 802.3bz and are fully backwards compatible with 802.3ab Gigabit Ethernet to deliver 2.5 Gigabit speed over commonly deployed Cat 5e cables over distances up to 100 meters.

Driven by the increasing popularity of 802.11ac Wave 2 access points and the emerging trend of 2.5 Gigabit LAN connections, 2.5 Gigabit technology will ultimately replace Gigabit as the standard for Ethernet connectivity. With backwards compatibility for older standards, the DMS-1100 Series can be flawlessly integrated into existing Gigabit Ethernet network infrastructures while simultaneously making networks future-proof for the next generation of 2.5 Gigabit connectivity.

Complete Layer 2 and Troubleshooting Features

The DMS-1100 switches come with a complete lineup of L2 features, including port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The switches also feature loopback detection and cable diagnostics to help network administrators identify and solve network problems quickly and easily. Loopback detection is used to detect loops created by a specific port and automatically shuts down the affected port. Cable diagnostics helps network administrators quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.

Versatile Management

The DMS-1100 switches support a variety of management options. An intuitive, web-based Graphical User Interface (GUI) enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.

These switches also come with the D-Link Network Assistant (DNA) utility that simplifies the configuration of devices supporting the D-Link Discovery Protocol. This utility allows network administrators to discover multiple D-Link Smart Managed Switches within the same L2 network segment and displays them on screen for instant access. With this utility, users do not need to change the IP address of their PC. It further allows for simultaneous configuration and basic setup of all discovered devices, including password changes and firmware upgrades.

The DMS-1100 Series also supports D-View. D-View is a network management system that allows for the central management of critical network characteristics such as availability, reliability, resilience, and security.

Power over Ethernet Support

The DMS-1100-10TP supports industry standard IEEE 802.3at power over Ethernet across all eight copper ports. It features a total power budget of 240 W, capable of supplying up to 30 W of power per port to connected PoE-enabled devices. Power over Ethernet simplifies deployment of surveillance devices and access point infrastructures by reducing cable clutter, and eliminating the need for dedicated power supplies to allow PoE devices to be installed in remote locations.

Lifetime Warranty and NBD Replacement

D-Link offers a Lifetime Warranty and Next Business Day (NBD) hardware replacement on the DMS-1100 Series 2.5 Gigabit Ethernet Smart Managed switches to further its commitment to product quality and long-term customer confidence.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
System event log
Ja
MIB-ondersteuning
RFC768 UDP, RFC791 IP, RFC792 ICMP, RFC793 TCP, RFC826 ARP, RFC1213 MIB II, RFC768 UDP, RFC791 IP, RFC792 ICMP, RFC793 TCP, RFC826 ARP, RFC1213 MIB II

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
2.5G Ethernet (100/1000/2500)
Aantal moduleslots SPF+
2

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Ja
Koperen ethernetbekabelingstechnologie
100BASE-TX, 1000BASE-T
Ondersteundende kabel types
Cat5e
Port mirroring
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Auto MDI/MDI-X
Ja
Spanning tree protocol
Ja
Head-of-line (HOL) blocking
Ja
Ethernet Ring Protection Switching (ERPS)
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Voice VLAN, Tagged VLAN, Port-based VLAN
Aantal VLANs
4094

Optische vezel

Fiber ethernet cabling technologie
1000BASE-X

Data-uitwisseling

Switchingcapaciteit*
80 Gbit/s
Throughput
59,52 Mpps
MAC-adrestabel*
16000 entries
Store-and-forward
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
9216

Beveiliging

DHCP-functies
DHCP client
IGMP snooping
Ja
IGMP-vermeldingen
192

Beveiliging

Ondersteunde beveiligingsalgoritmen
SNMP, SSL/TLS
DoS aanval preventie
Ja
Algoritmen wachtrijplanning
Strict Priority Queue (SPQ), Deficit weighted round robin (DWRR), Weighted Round Robin (WRR)

Multicast-functies

Multicast-ondersteuning
Ja
MLD-vermeldingen
192

Design

Rack-montage*
Ja
Vormfactor
1U
Kleur van het product
Zwart
LED-indicatoren
Activiteit, Fan fail, Link, Power over Ethernet (PoE), Stroom, Snelheid
Aantal ventilatoren
1 ventilator(en)
Veiligheid
cUL, CB, CE, CCC, BSMI
Certificering
CE, FCC, C-Tick, VCCI, BSMI, CCC

Prestatie

Maximum kabellengte
100 m
Mean time between failures (MTBF)
676329 uur

Energie

AC-ingangsspanning
100 - 240 V
Vermogensverbruik (max)
293,4 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Aantal Power over Ethernet plus (PoE +)-poorten
8
Totaal Power over Ethernet (PoE)-budget
240 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-5 - 50 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent
Luchtvochtigheid bij opslag
0 - 95 procent

Gewicht en omvang

Breedte
440 mm
Diepte
250 mm
Hoogte
44 mm
Gewicht
3,43 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
