D-Link DWL-8620AP draadloos toegangspunt (WAP) 2533 Mbit/s Wit Power over Ethernet (PoE)

D-Link DWL-8620AP, 2533 Mbit/s, 800 Mbit/s, 1733 Mbit/s, 10,100,1000 Mbit/s, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.1s,..., AES, TKIP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise

Nog 19 beschikbaar

MPN DWL-8620AP
EAN 0790069441219
€ 613,00 excl. BTW

D-Link DWL-8620AP draadloos toegangspunt (WAP) 2533 Mbit/s Wit Power over Ethernet (PoE)

Enjoy Faster Business with Wave 2
The DWL-8620AP is designed for medium to large-scale Wi-Fi networks, delivering fast Wave 2 wireless speeds. It’s highly manageable, it fits into any existing network, and can be scaled to meet future wireless demands.

Greater Speeds and Reliable Connectivity
Utilise the full potential of 802.11ac Wave 2. Provide faster connectivity with combined data rates of up to 2.5 Gbps2.

It also supports Link Aggregation, which allows two Gigabit Ethernet ports to be linked together to act as a single port to double the available bandwidth and maximise the access point’s overall throughput.

Increase Network Efficiency
The DWL-8620AP’s 4 x 4 MU-MIMO takes full advantage of all streams to serve more wireless clients, dramatically improving wireless performance.

MU-MIMO (Multi-User Multiple Input Multiple Output) simultaneously communicates with multiple clients using multiple antennas. This allows the access point to utilise the spectrum more efficiently and significantly increase the network capacity.

Rapid Deployments
It can be ceiling mounted or wall mounted to provide the best wireless coverage. The built-in Power over Ethernet (PoE) port makes deployments faster and means it can be installed in areas without power outlets.

Robust Management
When working in conjunction with D-Link Unified Wireless Controllers (DWC-1000, and DWC-2000), multiple DWL-8620AP units in the Wi-Fi network can be easily and efficiently centrally managed.

Automatic Radio Frequency (RF) Management
Radio Frequency (RF) resource management allows wireless coverage to be managed automatically, providing the best possible coverage for wireless clients.

When access points are deployed in close proximity to each other, there may be interference between channels if RF management is not implemented. When the DWL-8620AP senses a neighbouring AP nearby, it will automatically select a non-interfering channel.

This greatly reduces RF interference and allows you to deploy APs more densely. To further minimise interference, when a nearby AP is on the same channel, the DWL-8620AP will automatically adjust its transmission power. If an AP goes down, others will increase their transmission power to expand coverage.

Band Steering
It places clients on the optimal wireless band to avoid congestion and allows for smooth streaming of video, seamless browsing, and fast downloads speeds.

Airtime Fairness
Ensures equal airtime given to each client. Increases performance even if slower devices are connected.

802.11k Fast Roaming
Allows the wireless client to roam seamlessly between access points.

802.1p Quality of Service (QoS)
Supports 802.1p QoS for enhanced throughput and better performance of time-sensitive traffic like VoIP and streaming DSCP.

Wi-Fi Multimedia (WMM)
In the event of network congestion, time-sensitive traffic can be given priority ahead of other traffic.
  • 802.11ac Wave 2, Dual-Band, up to 2.5 Gbps2
  • 2 Internal Omnidirectional Antennas
  • Up to 64 dynamic VLANs per access point
  • 802.11k Fast Roaming1, MU-MIMO and QoS with WMM
  • Link Aggregation

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

2,4 GHz*
Ja
5 GHz*
Ja
Maximale overdrachtssnelheid van gegevens*
2533 Mbit/s
Maximale overdrachtssnelheid van gegevens (2.4 GHz)
800 Mbit/s
Maximale overdrachtssnelheid van gegevens (5 GHz)
1733 Mbit/s
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Netwerkstandaard
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.1s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Automatische kanaalselectie
Ja
MIMO
Ja
Wifi Multimedia (WMM)/(WME)
Ja
Snelle roaming
Ja
Bandbreedteaansturing
Ja
Airtime Fairness (ATF)
Ja
Quality of Service (QoS)
Ja

Beveiliging

Ondersteunde beveiligingsalgoritmen*
AES, TKIP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
MAC adres filtering
Ja
Aantal SSID-ondersteuningen
32
Auto Wireless Distribution System (WDS)
Ja

Protocollen

Beheerprotocollen
SNMP v1/v2c/v3

Beheerfuncties

Opdrachtregelinterface (CLI)
Ja

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
2
Aansluiting voor netstroomadapter
Ja

Energie

Power over Ethernet (PoE)*
Ja
AC-ingangsspanning
12 V
Stroom
2.5 A
Vermogensverbruik (max)
24,24 W

Design

Kleur van het product*
Wit
Materiaal behuizing
Kunststof
Certificering
CE,

Antenne

Soort antenne*
Intern
Type antennerichting
Omni-directioneel
Antennas quantity
2

Antenne

Antenne versterkingsniveau (max)
4 dBi

Technische details

(Binnenste) verzendverpakking lengte
44,9 cm
(Binnenste) verzendverpakking breedte
31,2 cm
(Binnenste) verzendverpakking hoogte
32,8 cm
Nettogewicht transportverpakking
7,33 kg
Producten per (binnenste) verzendverpakking
5 stuk(s)
Pallet brutogewicht (lucht)
222,3 kg
Aantal dozen per pallet (lucht)
24 stuk(s)
Aantal per pallet (lucht)
120 stuk(s)
Pallet brutolengte
110 cm
Pallet brutobreedte
120 cm
Pallethoogte (lucht)
144,7 cm
Pallet brutogewicht (zee)
272 kg
Aantal dozen per pallet (zee)
30 stuk(s)
Producten per pallet (zee)
150 stuk(s)
Pallethoogte (zee)
177,5 cm
(Binnenste) verzendverpakking gewicht
8,2 kg

Gewicht en omvang

Breedte
220 mm
Diepte
220 mm
Hoogte
47 mm
Gewicht
790 g

Verpakking

Breedte verpakking
295 mm
Diepte verpakking
296 mm
Hoogte verpakking
94 mm
Gewicht verpakking
1,47 kg

Inhoud van de verpakking

Aantal producten inbegrepen
1 stuk(s)
Snelstartgids
Ja

Eisen aan de omgeving

Relatieve vochtigheid in bedrijf (V-V)
0 - 40 procent
Bedrijfstemperatuur (T-T)
-20 - 65 °C
Temperatuur bij opslag
10 - 90 °C
Luchtvochtigheid bij opslag
5 - 95 procent

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
