DELL Xeon Gold 5318Y processor 2,1 GHz 36 MB

DELL Xeon Gold 5318Y, Intel® Xeon® Gold, FCLGA4189, 10 nm, Intel, 5318Y, 2,1 GHz

Niet op voorraad

Fabrikant Dell
MPN 338-CBXV
EAN 5397184660263
€ 1.997,00 excl. BTW

DELL Xeon Gold 5318Y processor 2,1 GHz 36 MB

The Intel Xeon® Gold 5318Y 2.1GHz Twenty Four Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.

Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon Gold 5318Y 2.1GHz Twenty Four Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
3e generatie Intel® Xeon® schaalbaar
Processormodel*
5318Y
Basisfrequentie processor*
2,1 GHz
Processorfamilie*
Intel® Xeon® Gold
Aantal processorkernen*
24
Processor socket*
FCLGA4189
Component voor
Server/werkplaats
Processor lithografie*
10 nm
Processorserie
Intel Xeon Gold 5000 Series
Processor aantal threads
48
Systeembus
11,2 GT/s
Processor operating modes*
64-bit
Maximale turbofrequentie van processor
3,4 GHz
Processor cache
36 MB
Thermal Design Power (TDP)
165 W
Box*
Nee
Inclusief koeler*
Nee
Codenaam processor
Ice Lake

Geheugen

Maximaal intern geheugen ondersteund door processor
6000 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor
2933 MHz
Geheugen kanaal*
Achtkanaals
ECC
Ja

Grafisch

Ingebouwde grafische adapter*
Nee
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Niet beschikbaar
Discreet grafische adapter model*
Niet beschikbaar

Kenmerken

Execute Disable Bit
Ja
Marktsegment
Server
Maximaal aantal PCI Express-lijnen
64
PCI Express slots versie
4.0
Ondersteunde instructie sets
SSE4.2, AVX, AVX 2.0, AVX-512
Schaalbaarheid
2S
Ingebouwde opties beschikbaar
Ja
Export Control Classification Number (ECCN)
5A992CN3
Commodity Classification Automated Tracking System (CCATS)
G178966

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Trusted Execution Technology
Ja
Intel® Speed Shift-technologie
Ja
Intel® Transactional Synchronization Extensions
Ja
Intel® Total Memory Encryption
Ja
Intel® Crypto Acceleration
Ja
Ondersteuning voor Intel® Platform Firmware Resilience
Ja
Ondersteuning voor maximale enclavegrootte voor Intel® SGX
64 GB
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Software Guard Extensions (Intel® SGX)
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
AVX-512 Fused Multiply-Add (FMA) eenheden
2
Intel® Deep Learning Boost (Intel® DL Boost)
Ja
Intel® Speed Select-technologie - Prestatieprofiel (Intel® SST-PP)
Ja
Intel® Resource Director-technologie (Intel® RDT)
Ja
Intel® Volume Management Device (VMD)
Ja
Intel® Run Sure-technologie
Ja
Mode-based Execute Control (MBE)
Ja
Intel® Optane™ DC Persistent Memory ondersteunt
Ja

Eisen aan de omgeving

Tcase
87 °C

Technische details

Lanceringsdatum
Q2'21
Status
Launched
Ondersteunde geheugen types
DDR4-SDRAM
Geheugensnelheid (max)
2933 MHz
Aantal UPI-koppelingen
3

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85423119

Gewicht en omvang

Verpakkingsgrootte processor
77.5 x 56.5 mm

Overige specificaties

Maximum intern geheugen
6000 GB
