Digitus DA-70863 notebook dock & poortreplicator Bedraad USB 3.2 Gen 2 (3.1 Gen 2) Type-C Zilver

Digitus DA-70863, Bedraad, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, 60 W, 3,5 mm, Zilver, MMC, MicroSD (TransFlash), SD, SDHC, SDXC

Ruim op voorraad

Fabrikant Digitus
MPN DA-70863
EAN 4016032435396
€ 68,00 excl. BTW

Digitus DA-70863 notebook dock & poortreplicator Bedraad USB 3.2 Gen 2 (3.1 Gen 2) Type-C Zilver

Het volledig functionele universele Docking Station, USB-type C van Digitus biedt u alles om een volledig functionele werkplek te realiseren. Twee video-interfaces (HDMI, Mini DP, VGA) waarbij twee beeldschermen tegelijk gebruikt kunnen worden. Hierbij is de maximale ondersteunde resolutie: Briljante UHD (4K2K/30Hz). Daarnaast drie USB 3.0-aansluitingen, waarbij een poort (5V/1,5A) kan worden gebruikt voor het opladen van mobiele apparaten. De USB-aansluitingen worden aangevuld met een USB-C met Power Delivery (PD 2.0) Functie. Daarnaast zijn twee kaartlezers ingebouwd (MicroSD, SDHC, SDXC/MMC). Via de Gigabit Ethernet-aansluiting kan uw notebook via een kabel op het netwerk worden aangesloten. Het geheel wordt afgerond met een stereo-audio-aansluiting. Breid uw notebook uit met 11 extra aansluitingen via slechts één USB-C-poort - met het multifunctionele universele Docking USB-type C.
  • Supports Ultra HD (30 Hz), 4096 x 2160p resolution (HDMI, MiniDP)
  • Dual monitor function - connect two monitors at the same time (HDMI+MiniDP / VGA+MiniDP)
  • 1 x HDMI (UHD resolution, 4K/30 Hz)
  • 1 x Mini DisplayPort (UHD resolution, 4K2K, 30 Hz)
  • 1 x VGA (Full HD)
  • 1 x USB-C™ port with power delivery (PD 2.0) function for fast charging of notebooks (60 W, 20 V / 3 A)
  • 3 x USB 3.0 (SuperSpeed, 5 Gbps max.), one port with charging function for mobile devices (5 V/1.5 A)
  • 1 x Stereo audio port – connects headphones or microphones
  • 1 x Gigabit Ethernet port - connects your notebook to the network via cable
  • 2 x Card readers (MicroSD / SDHC, SDXC, MMC)
  • USB-C™ version: USB 3.1 (Gen 1)
  • Premium and high-quality aluminum housing
  • Cable length: 10 cm
  • Color: silver
  • Dimensions: L 12.0 x W 12.0 x H 1.7 cm
  • Weight: 230 g
  • Not all USB-C™ ports support all features of the USB Type-C™ standard. Make sure your notebook's USB-C™ port supports DisplayPort Alternate Mode (DP-Alt Modi) and USB Power Delivery (PD).
  • The video output capability depends on the graphic card of your notebook and the connected monitor. Certain graphics cards have limited MST support, while some monitors also limit the available resolution.
  • The used power supply must supply at least 60 watts to power a connected notebook as well as the docking station via the USB-C™ port

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Connectiviteitstechnologie*
Bedraad
Hostinterface*
USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A*
3
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A
1
USB Power Delivery tot max.
60 W
Aantal HDMI-poorten*
1
VGA (D-Sub)poort(en)
1
Aantal DisplayPorts
1
Mini DisplayPort kwantiteit
1
Microfoon, line-in ingang*
Ja
Hoofdtelefoonuitgangen*
1
Type aansluitplug
3,5 mm

Netwerk

Ethernet LAN*
Ja
Aantal Ethernet LAN (RJ-45)-poorten
1

Prestatie

Geïntegreerde geheugenkaartlezer*
Ja
Compatibele geheugenkaarten
MMC, MicroSD (TransFlash), SD, SDHC, SDXC
Resolutie (maximum digitaal)
4096 x 2160 Pixels
Aantal displays ondersteund
2
Kleur van het product*
Zilver
Materiaal behuizing
Aluminium
Land van herkomst
China

Grafisch

Maximum resolutie
4096 x 2160 Pixels

Energie

Type stroombron
USB

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-10 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
10 - 90 procent

Gewicht en omvang

Breedte
120 mm
Diepte
120 mm
Hoogte
17 mm
Gewicht
230 g

Verpakking

Breedte verpakking
185 mm
Diepte verpakking
180 mm
Gewicht verpakking
382,5 g

Inhoud van de verpakking

Gebruikershandleiding
Ja

Technische details

Verpakkingsvolume
832,5 cm³

Logistieke gegevens

Code UK-handelstarief
84718000
Code geharmoniseerd systeem (HS)
84733020
