Digitus DA-70865, Bedraad, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 100 W, 10,100,1000 Mbit/s, Zwart, MMC, MicroSD (TransFlash), MicroSDXC, SD

Ruim op voorraad

Fabrikant Digitus
MPN DA-70865
EAN 4016032441250

Digitus DA-70865 notebook dock & poortreplicator Bedraad USB 3.2 Gen 1 (3.1 Gen 1) Type-C Zwart

The most important interfaces are always there – expands your notebook by 9 additional ports via one single USB-C™ port

- Supports Ultra HD (30Hz), 3840 x 2160p resolution (HDMI)
- 2 x Video connections (HDMI, VGA) – video signal output with a maximum resolution of UHD 4K2K, 30 Hz (HDMI)
- 2 x USB 3.0 port for super-speed data transfer and one with additional charging function (BC 1.2) for mobile devices
- 1 x USB Type-C™ port – data transfer
- 1 x USB Type-C™ port with Power Delivery
- 1 x Gigabit Ethernet port - connects your laptop to the network via cable
- 2 x Card readers (MicroSD / SDHC, SDXC, MMC)

With the USB Type-C™ Universal Travel Docking Station from DIGITUS®, you always have the most important interfaces with you. The docking station extends your notebook by nine additional ports. It offers two video interfaces (HDMI and VGA). The highest possible supported resolution (HDMI): Brilliant UHD (4K2K/30Hz). In addition, it offers two USB 3.0 ports, one promises a charging function for mobile devices (BC 1.2) as well. Likewise, it offers two USB-C™ ports - 1x data transfer, 1x Power Delivery (PD 3.0). Your notebook can also be connected to the network by cable via the Gigabit Ethernet port. The whole thing is rounded off by two card readers (MicroSD, SDHC, SDXC / MMC). Due to the compact size, the low weight as well as the stowable connecting cable, the docking station is the perfect companion when out and about and when travelling.
  • Supports Ultra HD (30Hz), 3840 x 2160p resolution (HDMI)
  • 1 x HDMI (UHD resolution, 4K/30 Hz)
  • 1 x VGA (Full HD 1080p / 60 Hz)
  • 2 x USB 3.0 port for super-speed data transfer and one with additional charging function (BC 1.2) for mobile devices
  • 1 x USB-C™ for data transfer (5 Gbit/s max.)
  • 1 x USB-C™ with Power Delivery (PD) 3.0 functionality (100W, 20V/5A)
  • 1 x Gigabit Ethernet port – connection of your notebook to the network by cable (10/100/1000 Mb/s)
  • 2 x Card readers (MicroSD / SDHC, SDXC, MMC)
  • Stowable USB-C™ connecting cable (10 cm) – the connecting cable can be stored in the casing
  • USB-C™ version: USB 3.1 (Gen 1)
  • Ultra-compact size as well as low weight – perfect for travelling and out and about
  • Color: black
  • Dimensions: L 12.2 x W 7.0 x H 1.4 cm
  • Weight: 90 g
  • Not all USB-C™ ports support all features of the USB Type-C™ standard. Make sure your notebook's USB-C™ port supports DisplayPort Alternate Mode (DP-Alt Modi) and USB Power Delivery (PD).
  • The video output capability depends on the graphic card of your notebook and the connected monitor. Certain graphics cards have limited MST support, while some monitors also limit the available resolution.
  • The used power supply must supply at least 60 watts to power a connected notebook as well as the docking station via the USB-C™ port

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Connectiviteitstechnologie*
Bedraad
Hostinterface*
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A*
2
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C
2
USB Power Delivery tot max.
100 W
Aantal HDMI-poorten*
1
VGA (D-Sub)poort(en)
1
Microfoon, line-in ingang*
Nee

Netwerk

Ethernet LAN*
Ja
Aantal Ethernet LAN (RJ-45)-poorten
1
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s

Prestatie

Geïntegreerde geheugenkaartlezer*
Ja
Compatibele geheugenkaarten
MMC, MicroSD (TransFlash), MicroSDXC, SD
Inclusief optische drive
Nee
Overdrachtssnelheid
5 Gbit/s
Resolutie (maximum digitaal)
3840 x 2160 Pixels
Aantal displays ondersteund
1
Kleur van het product*
Zwart
Oplaadfunctie
Ja
Materiaal behuizing
Kunststof
Land van herkomst
China

Grafisch

Maximum resolutie
3840 x 2160 Pixels

Koeling

Ingebouwde ventilator
Nee

Opslagmedia

Ingebouwde HDD
Nee

Energie

Type stroombron
USB

Gewicht en omvang

Breedte
70 mm
Diepte
122 mm
Hoogte
14 mm
Gewicht
90 g

Verpakking

Aantal per verpakking
1 stuk(s)
Breedte verpakking
170 mm
Diepte verpakking
140 mm
Gewicht verpakking
226 g

Inhoud van de verpakking

Gebruikershandleiding
Ja

Technische details

Verpakkingsvolume
595 cm³

Logistieke gegevens

Code UK-handelstarief
84718000
Code geharmoniseerd systeem (HS)
84733020
