Digitus DN-10162, Intern, Bedraad, PCI Express, Fiber, 20000 Mbit/s

Nog slechts 9 beschikbaar

Fabrikant Digitus
MPN DN-10162
EAN 4016032445197

Digitus DN-10162 netwerkkaart Intern Fiber 20000 Mbit/s

Connect your workstation directly to your 10G fiber optic network

- Use the SFP+ tranceiver of your choice
- Compatible with x8 and x16 PCIe slots
- Supports 802.1Q VLAN tagging

With this 10-Gigabit Fiber Optic network card you have a cost efficent solution for connecting your workstation to your network using the SPF+ Tranceiver of your choice. Thanks to the dual ports you also have the choice to reach speeds up to 20 Gigabit in full duplex mode. Due to the Intel chipset you have a reliable solution offering you features like up to 15,5K jumbo frames, IP, TCP and UDP checksum offloading (IPv4, IPv6) capabilities.
  • Compatible with x8 and x16 PCIe slots
  • Supports 802.1Q VLAN tagging
  • Supports 20G full duplex
  • Up to 15K Jumbo Frames
  • Supports 10G SFP+ optical and direct attached copper modules
  • PCI Express specification revision 2.0
  • IEEE 802.1Q Tagged VLAN
  • Supports Win 7, 8.1, 10, Server 2008 R2, 2012, 2012 R2, Linux 2.6.x and later
  • Chipset: Intel JL82599ES

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Connectiviteitstechnologie*
Bedraad
Hostinterface*
PCI Express
Interface*
Fiber
Fibre channel-poorten
2
PCI versie
3.0

Netwerk

Maximale overdrachtssnelheid van gegevens*
20000 Mbit/s
Netwerkstandaard*
IEEE 802.1Q
Full duplex
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000
VLAN-tagging
Ja

Design

Intern*
Ja
Chipset
Intel JL82599ES

Design

Land van herkomst
China

Verpakking

Meegeleverde drivers
Ja
Low-profile bracket
Ja
Breedte verpakking
145 mm
Diepte verpakking
210 mm
Gewicht verpakking
215 g

Inhoud van de verpakking

Gebruikershandleiding
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
Code UK-handelstarief
84718000

Overige specificaties

Verpakkingsvolume
1004,85 cm³
