Digitus DN-19 SRV-26U-D, Vrijstaande rek, 26U, 600 kg, Grijs

Niet op voorraad

Fabrikant Digitus
MPN DN-19 SRV-26U-D
EAN 4016032336532

Digitus DN-19 SRV-26U-D rack Vrijstaande rek Grijs

The DIGITUS® Dynamic Basic Series is made for high demand IT-Infrastructure Solutions - designed and developed on highest standard in Germany

- Roof is prepared for fan units (punched out entries)
- Lock system with pivot lever on front- and rear door
- Base with punched out cable entry, covered with screwed metal plate

The 483 mm (19”) cabinets from the Dynamic series were developed for easy and especially cost-optimized network expansion. Clever placement of the cable inlets ensures effortless installation for every application. They are located at the back center in the floor structure, protected by a bolted cover plate. Cabinets from a width of 800 mm also feature cable inlets with a plastic cover to the left and right. These are also integrated into the roof (1 x for 600 mm cabinet width, 3 x for 800 mm cabinet width). To accommodate a fan module, the roof structure is also equipped with a pre-cut area. Two pairs of galvanized 483 mm (19”) profile rails labeled with rack units readable in both directions are installed on the inside. Their depth is adjustable and they are connected to additional depth bars in the cabinet. Each cabinet is made of up to 1.5 mm thick sheet steel. Coloring is done with electrostatic powder coating in the standard colors gray (RAL 7035) or jet black (RAL 9005). Removable side walls as well as lockable and removable perforated front and back door improve accessibility. The door hinges can be switched. Furthermore, the cabinets can be completely dismantled if necessary due to their collapsible design.
  • Safety class rating IP20
  • Steel front- and rear door with 70% perforation
  • Lock system with pivot lever on front- and rear door
  • 120° door opening angle on the front door
  • 1-point-locking-mechanism on all doors
  • Side panels are lockable and removable
  • incl. 4 pieces of leveling feet already pre-configured under the rack
  • 483 mm (19“) profile rails mounted on the front- and rear side inside of the rack, galvanized
  • 483 mm (19“) profile rails are adjustable in depth and with height unit marking
  • Built-in depth support bars for more stability
  • Base with punched out cable entry, covered with screwed metal plate
  • Roof with punched out cable entries with plastic covers
  • Roof is prepared for fan units (punched out entries)
  • Several earthing points for rack components
  • Incl. installation set (screws, cage nuts, washers)
  • Rack is completely mounted
  • Equipment mounting depth min.-max.: 630-950 mm

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

Rackcapaciteit*
26U
Soort*
Vrijstaande rek
Maximale gewichtscapaciteit*
600 kg
Kleur van het product
Grijs
Materiaal
Glas, Staal
Achterdeurconstructie
Steel/Perforated
Voordeurconstructie
Staal
Inbegrepen zijpanelen
Ja
Internationale veiligheidscode (IP)
IP20

Gewicht en omvang

Maat
48,3 cm (19")
Breedte
600 mm
Diepte
1000 mm
Hoogte
1342 mm

Verpakking

Breedte verpakking
650 mm
Diepte verpakking
1050 mm
Hoogte verpakking
1450 mm
Verpakkingsvolume
941850 cm³
Gewicht verpakking
81,5 kg

Logistieke gegevens

Code UK-handelstarief
94032080
Land van herkomst
Turkije
Code geharmoniseerd systeem (HS)
85381000

Overige specificaties

Lengte van de verpakking
108 cm
