Digitus DN-60021-2 netwerk-switch Unmanaged Fast Ethernet (10/100) Grijs
Ideal for sharing workgroups with multiple high-speed servers!
- Adds 24 extra ports (for servers, notebooks, PCs, routers, and so on) to your network
- Automatic full-duplex and half-duplex detection
- Energy Efficient Ethernet for low power consumption
The DIGITUS® 24-Port Fast Ethernet switch makes 24 10/100 Mbps RJ-45 ports with auto negotiation available. All ports support the Auto MDI/MDIX function, which eliminate the need for crossover cables and uplink ports. Low costs, simple use and high performance are the strengths of the DIGITUS® Fast Ethernet 24-Port switch and thus make it an excellent choice for your network.
- Adds 24 extra ports (for servers, notebooks, PCs, routers, and so on) to your network
- Automatic full-duplex and half-duplex detection
- Energy Efficient Ethernet for low power consumption
The DIGITUS® 24-Port Fast Ethernet switch makes 24 10/100 Mbps RJ-45 ports with auto negotiation available. All ports support the Auto MDI/MDIX function, which eliminate the need for crossover cables and uplink ports. Low costs, simple use and high performance are the strengths of the DIGITUS® Fast Ethernet 24-Port switch and thus make it an excellent choice for your network.
- 24 RJ45 ports
- Up to 20/200 Mbps in Full Duplex Mode
- Compatible to the following standards: IEEE 802.3, 802.3u, 802.3az and 802.3x
- Very low power consumption due to the EEE (Energy Efficient Ethernet) Technology
- Automatic cable detection - auto MDI / MDI-X function
- 8K MAC addresses
- Auto-negotiation of full- and half-duplex
- Power, link/active, speed indicators for network status
- Shielded metal housing
- Noiseless design - without fan
- Built-in Power Supply
- Suitable for rack mount (incl. mounting bracket)
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Beheerfuncties
Switch type*
Unmanaged
Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Fast Ethernet (10/100)
Netwerk
Netwerkstandaard*
IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Full duplex
Ja
Auto MDI/MDI-X
Ja
Auto-negotiation
Ja
VLAN=ondersteuning
Nee
Data-uitwisseling
MAC-adrestabel*
8000 entries
Design
Rack-montage*
Ja
Kleur van het product
Grijs
Materiaal behuizing
Metaal
LED-indicatoren
Ja
Vandaalbestendig
Nee
Geschikt voor buitengebruik
Nee
Land van herkomst
China
Energie
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Power over Ethernet (PoE)
Power over Ethernet (PoE)*
Nee
Gewicht en omvang
Breedte
280 mm
Diepte
173 mm
Hoogte
45 mm
Gewicht
1,21 kg
Verpakking
Meegeleverde kabels
AC
Gebruikershandleiding
Ja
Rekbevestigingspakket
Ja
Breedte verpakking
352 mm
Diepte verpakking
90 mm
Hoogte verpakking
252 mm
Verpakkingsvolume
7983,36 cm³
Gewicht verpakking
1,08 kg
Logistieke gegevens
Code UK-handelstarief
85176200
(Buitenste) hoofdverpakking breedte
365 mm
(Buitenste) hoofdverpakking lengte
268 mm
(Buitenste) hoofdverpakking hoogte
485 mm
Code geharmoniseerd systeem (HS)
85176990
(Buitenste) hoofdverpakking brutogewicht
5,4 kg
Hoeveelheid per (buitenste) hoofdverpakking
5 stuk(s)
Overige specificaties
Ethernet interface type
Fast Ethernet
