Digitus DN-651111 network splitter Zwart

Digitus DN-651111, IEEE 802.3bt, 10/100/1000Base-T(X), Zwart, Metaal, IP30, Taiwan

Nog slechts 4 beschikbaar

Fabrikant Digitus
MPN DN-651111
EAN 4016032441182
€ 200,00 excl. BTW

Digitus DN-651111 network splitter Zwart

- Gigabit Splitter with up to 95W PoE feed
- Flexibly adjustable output voltage: 12VDC, 16VDC, 24VDC, 48VDC
- Gigabit data output for network connection

The DIGITUS® Industrial Gigabit PoE Splitter is designed for harsh environments, in which it is exposed to moisture, temperature variations and vibrations. With a temperature range of -40°C to 75°C, the Industrial Gigabit PoE Splitter can be used under the most adverse conditions. It ensures a constant availability in highly sensitive areas such as transport, production, traffic and safety monitoring. The simple plug-and-play system allows a fast integration of the Industrial Gigabit PoE Splitter into the respective environment. The DIGITUS® DN-651111 is an unmanaged Plug & Play Industrial Gigabit PoE Splitter in a rugged IP30 protected aluminum housing. The Gigabit connectivity, as well as the selectable voltage that can be provided for non-PoE compatible devices, make the Industrial Gigabit PoE Splitter a flexible, cost-effective solution for the industrial environment. The supply voltage can be selected in the range of 12VDC, 16VDC, 24VDC or 48VDC. The IEEE802.3bt standard allows PoE feed of up to 95W. Two parallel current outputs are provided for terminal devices.
  • Gigabit Splitter with up to 95W PoE feed
  • Flexibly adjustable output voltage: 12VDC, 16VDC, 24VDC, 48VDC
  • Gigabit data output for network connection
  • Backward compatible with IEEE802.3af/at standard
  • Store and forward technology for optimized data transfer
  • Auto MDI/MDI-X function
  • Diagnostic LEDs for status and activity monitoring
  • Operating temperature: -40°C to +75°C

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Prestatie

Netwerkstandaard
IEEE 802.3bt
Bekabelingstechnologie
10/100/1000Base-T(X)
Auto MDI/MDI-X
Ja

Design

Kleur van het product
Zwart
Materiaal behuizing
Metaal
Internationale veiligheidscode (IP)
IP30
LED-indicatoren
Ja
Plug and play
Ja
Land van herkomst
Taiwan

Poorten & interfaces

RJ-45 invoer ports
1
RJ-45 uitgang ports
1

Energie

Power over Ethernet (PoE)
Nee
Spanning
12 - 48 V
Uitgangsvermogen
55 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-40 - 75 °C

Gewicht en omvang

Breedte
103,5 mm
Diepte
81,5 mm
Hoogte
32 mm
Gewicht
150 g
Breedte verpakking
65 mm
Diepte verpakking
215 mm
Hoogte verpakking
65 mm
Gewicht verpakking
437,5 g
Verpakkingsvolume
2305,88 cm³

Inhoud van de verpakking

Snelle installatiehandleiding
Ja

Logistieke gegevens

Code UK-handelstarief
85176200
(Buitenste) hoofdverpakking breedte
560 mm
(Buitenste) hoofdverpakking lengte
350 mm
(Buitenste) hoofdverpakking hoogte
240 mm
(Buitenste) hoofdverpakking brutogewicht
7 kg
(Buitenste) hoofdverpakking inhoud
47040 cm³
Hoeveelheid per (buitenste) hoofdverpakking
16 stuk(s)
