Digitus DN-651129 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Blauw
Robust and durable industrial solution for high temperature ranges and rough industrial environments - redundant power supply possible
- 16 x RJ45 ports 10/100/1000 Mbps
- Suitable for high temperature ranges from -40 °C to +80 °C
- Redundant power supply via terminal clamps
- Suitable for mounting on DIN rails (profile rail)
- Protects against impact and vibrations
- Integrated surge protection
- Full-duplex flow control IEEE802.3x
- Auto-Negotiation / Auto MDI/MDI-X Function
- Fanless design with protection type IP40
The DIGITUS® Industrial Gigabit Switch was designed for harsh environments in which it is exposed to moisture, temperature fluctuations and vibrations. With a temperature range from -40 °C to 80 °C, the Gigabit Switch with an IP40 housing can be used under the most adverse of conditions. Thanks to redundant power supply, it guarantees constant availability in highly sensitive sectors such as transport, production, transport and security surveillance. With its 16 Gigabit Ethernet ports, it is designed for a wide range of applications.
- 16 x RJ45 ports 10/100/1000 Mbps
- Suitable for high temperature ranges from -40 °C to +80 °C
- Redundant power supply via terminal clamps
- Suitable for mounting on DIN rails (profile rail)
- Protects against impact and vibrations
- Integrated surge protection
- Full-duplex flow control IEEE802.3x
- Auto-Negotiation / Auto MDI/MDI-X Function
- Fanless design with protection type IP40
The DIGITUS® Industrial Gigabit Switch was designed for harsh environments in which it is exposed to moisture, temperature fluctuations and vibrations. With a temperature range from -40 °C to 80 °C, the Gigabit Switch with an IP40 housing can be used under the most adverse of conditions. Thanks to redundant power supply, it guarantees constant availability in highly sensitive sectors such as transport, production, transport and security surveillance. With its 16 Gigabit Ethernet ports, it is designed for a wide range of applications.
- Number of RJ45 ports: 16 x 10/100/1000 Mbps
- Auto-Negotiation / Auto MDI/MDI-X Function
- Backplane bandwidth: 56 Gbps
- Forwarding capacity: 42 Mpps
- Package buffer storage: 4.1 Mbit
- MAC addresses: 8K
- Full-duplex flow control IEEE802.3x
- Network protocol: IEEE802.3, IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x
- Input voltage: 12 - 52 V DC, redundant feed-in
- Power consumption: <10 W
- Surge protection: +/- 4 kV
- Supports air discharge +/- 12 kV
- Supports contact discharge +/-8kV
- Industry standards: IEC 61000-4-4(EFT) IEC 61000-4-5 (Surge), Shock IEC 60068-2-27, Fire IEC 60068-2-32, Vibration: IEC 60068-2-6
- Average operating time: 300,000 h
- Protects against vibrations and impact
- Suitable for profile rail installation
- Fanless design
- Operating temperature: -40°C ~ 80°C
- Storage temperature: -40 °C to +80 °C
- Operating humidity: 5% - 95% (non condensing)
- Protection type: IP40
- Housing: Aluminum
- Dimensions (WxDxH): 175.6 x 135 x 45.5 mm
- Weight: 900 g
- Color: Blue
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Beheerfuncties
Switch type*
Unmanaged
Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten*
16
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
16
Netstekker
DC-in ingang
Netwerk
Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Full duplex
Ja
Datastroombeheer
Ja
Auto MDI/MDI-X
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
VLAN=ondersteuning
Nee
Data-uitwisseling
Switchingcapaciteit*
1 Gbit/s
Verzending snelheid
42 Mpps
MAC-adrestabel*
8000 entries
Packet buffergeheugen
4,1 MB
Design
Rack-montage*
Nee
Stapelbaar*
Nee
Kleur van het product
Blauw
Materiaal behuizing
Aluminium
Internationale veiligheidscode (IP)
IP40
DIN rail bevestiging
Ja
Vandaalbestendig
Nee
Geschikt voor buitengebruik
Nee
Land van herkomst
China
Prestatie
Fanloos
Ja
Mean time between failures (MTBF)
300000 uur
Energie
Stroombron*
DC
Vermogenstoevoer inclusief*
Nee
Redundante voeding
Ja
DC voltage input
12 - 52 V
Stroomverbruik (typisch)
10 W
Spanningsbeveiliging
Ja
Overspanningsbeveiliging in voltage
4 kV
Power over Ethernet (PoE)
Power over Ethernet (PoE)*
Nee
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
-40 - 80 °C
Temperatuur bij opslag
-40 - 80 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Gewicht en omvang
Breedte
175,6 mm
Diepte
135 mm
Hoogte
45,5 mm
Gewicht
900 g
Verpakking
Gebruikershandleiding
Ja
Breedte verpakking
208 mm
Diepte verpakking
186 mm
Hoogte verpakking
72,5 mm
Verpakkingsvolume
2804,88 cm³
Gewicht verpakking
1,08 kg
Logistieke gegevens
Code UK-handelstarief
85176200
Overige specificaties
Bandbreedte
56 Gbit/s
Ethernet interface type
Gigabit Ethernet
