Digitus DN-80066 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Zwart

Digitus DN-80066, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex

Nog slechts 4 beschikbaar

Fabrikant Digitus
MPN DN-80066
EAN 4016032478683
€ 33,00 excl. BTW

Digitus DN-80066 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Zwart

8-port 10/100/1000Mbps unmanage Gigabit Ethernet Switch, Auto-Negotiation RJ45 ports, All ports support Auto MDI/MDIX function

- 8 x RJ45 ports 10/100/1000 Mbps
- All ports support 10/100/1000 Mbps bandwidth
- Support desktop and Wall mount installation
- Switching Capacity: 16Gbps
- Network standards: IEEE 802.3i, IEEE 802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3az standards
- Auto-negotiation / Auto-MDI/MDI-X
- MAC address auto-learning and auto-aging
- LED indicators for monitoring power, link/activity
- Durable metal enclosure

This is a 8 port 10/100/1000Mbps Ethernet Switch, provides the seamless network connection. All ports support Auto MDI/MDIX function ,with 8 10/100/1000Mbps Auto-Negotiation RJ45 ports. The Switch with a low-cost, easy-to-use, high performance upgrade your old network to a 1000Mbps network.

The switch is easy to install and use. It is suitable for expanding your home or office network. The LED on the front panel can dynamically display the operation status of the network.
  • Number of ports: 8 x 10/100/1000 Mbps
  • Network standards: IEEE802.3i, IEEE802.3u, IEEE802.3ab
  • Auto-negotiation: Auto MDI/MDIX
  • IEEE802.3x full-duplex flow control
  • Switching Capacity: 16Gbps
  • Mac address Table: 4K
  • Packet Forwarding Rate: 11.9Mpps
  • Packet Buffer: 1.5Mbit
  • Jumbo Frame 9216Byte
  • Transfer Method: Store and Forward
  • LED indicators: link, active , power on
  • Operating voltage: 5V DC / 1A
  • Power consumption: 3.1W max.
  • Power supply Power supply: 100 - 240 V AC, 50/60 Hz, 5 W
  • Plug type device side: DC plug 5.5 mm/2.1 mm
  • Operating temperature: 0°C to 40°C
  • Operating humidity: 10% - 90% RH (non-condensing)
  • Storage temperature: -10°C to 70°C
  • Fanless design (air flow cooling)
  • Dimensions: 140x76x28 mm
  • Weight: 435 g
  • Chipset: RTL8370N-VB

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
8
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Full duplex
Ja
Auto MDI/MDI-X
Ja
Auto-negotiation
Ja
VLAN=ondersteuning
Nee

Data-uitwisseling

Switchingcapaciteit*
16 Gbit/s
Verzending snelheid
11,9 Mpps
MAC-adrestabel*
4000 entries
Store-and-forward
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
9216
Packet buffergeheugen
1,5 MB

Design

Rack-montage*
Nee
Stapelbaar*
Nee
Kleur van het product
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Activiteit, Link, Stroom
Vandaalbestendig
Nee
Geschikt voor buitengebruik
Nee
Land van herkomst
China

Prestatie

Fanloos
Ja

Energie

Stroombron*
AC/DC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
DC voltage input
5 V
Stroom
1 A
Stroomverbruik (typisch)
5 W
Vermogensverbruik (max)
3,1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-10 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent

Gewicht en omvang

Breedte
140 mm
Diepte
76 mm
Hoogte
28 mm
Gewicht
435 g

Verpakking

Snelstartgids
Ja
Breedte verpakking
163 mm
Diepte verpakking
122 mm
Hoogte verpakking
94 mm
Verpakkingsvolume
1869,28 cm³
Gewicht verpakking
510 g

Overige specificaties

Ethernet interface type
Gigabit Ethernet
