Digitus DN-80067 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Zwart

Digitus DN-80067, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex

Ruim op voorraad

Fabrikant Digitus
MPN DN-80067
EAN 4016032478706
€ 47,00 excl. BTW

Digitus DN-80067 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Zwart

8 x 10/100/1000 Mbit/s + 2SFP Uplink Ports

- 8 x RJ45 ports 10/100/1000 Mbps
- 2 ports 1000Mbps SFP Slots
- Support desktop and Wall mount installation
- Switching Capacity 20Gbps
- Network standards: IEEE 802.3, IEEE 802.3u, IEEE802.3x, IEEE802.3ab
- Durable metal enclosure
- Fanless design (air flow cooling)
- LED indicators for Link/ Activity / Speed

The Switch is 8 ports 10/100/1000Mbps + 2 ports 100/1000Mbps SFP Slots Unmanaged Ethernet Switch. This switch is a design of high integration level, exquisite, portable, easy to operate, which is suitable for the small and medium office and home network. The switch provide you with a simple, economic, standard and high performance of network application plan, it is ideal choice to promote the department and working group performance.It provide simple and understood LED indicator light on the front panel, so that you can quickly judge the working state of the switch, and help to diagnose the network failure.
  • 8 ports 10/100/1000 Mbps
  • 2 ports 1000Mbps SFP
  • Network standards: IEEE 802.3, IEEE 802.3u, IEEE802.3x, IEEE802.3ab standards
  • Auto-negotiation: Auto MDI/MDIX
  • IEEE802.3x full-duplex flow control
  • Transfer Method : Store and forward
  • Backplane bandwidth: 20 Gbps
  • 4K entry MAC address table of the switch with auto-learning and auto-aging
  • Buffer 1.5Mbit
  • Packet Forwarding Rate: 14.88Mbps
  • Jumbo Frame 9216Bytes
  • LED indicators: link, active , speed
  • Operating voltage: 12V DC / 1A
  • Power consumption: 5.78W max.
  • Power supply: 100 - 240 V AC, 50/60 Hz
  • Power Plug : DC plug 5.5 mm/2.1 mm
  • Operating temperature: 0°C to 45°C
  • Storage humidity: 5%~90% non-condensing
  • Dimensions: 190x100x28 mm
  • Weight: 378 g
  • Chipset: RTL8370MB+RTL8231

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
8
Aantal moduleslots SPF
2
Vezel-optische connector
SFP
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Full duplex
Ja
Auto MDI/MDI-X
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Auto-negotiation
Ja
MAC-adres zelflerende functie
Ja
MAC-adres zelfverouderende functie
Ja
VLAN=ondersteuning
Nee

Data-uitwisseling

Switchingcapaciteit*
20 Gbit/s
Verzending snelheid
14,88 Mpps
MAC-adrestabel*
4000 entries
Store-and-forward
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
9216
Packet buffergeheugen
1,5 MB

Design

Rack-montage*
Nee
Stapelbaar*
Nee
Kleur van het product
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Activiteit, Stroom, Link
Vandaalbestendig
Nee

Design

Geschikt voor buitengebruik
Nee
Land van herkomst
China

Prestatie

Fanloos
Ja

Energie

Stroombron*
AC/DC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
DC voltage input
5 V
Stroom
1 A
Stroomverbruik (typisch)
5 W
Vermogensverbruik (max)
5,78 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 90 procent

Gewicht en omvang

Breedte
190 mm
Diepte
100 mm
Hoogte
28 mm
Gewicht
378 g

Verpakking

Snelstartgids
Ja
Breedte verpakking
256 mm
Diepte verpakking
158 mm
Hoogte verpakking
79 mm
Verpakkingsvolume
3195,39 cm³
Gewicht verpakking
810 g

Overige specificaties

Ethernet interface type
Gigabit Ethernet
