Digitus DN-80069 netwerk-switch Unmanaged Fast Ethernet (10/100) Zwart

Digitus DN-80069, Unmanaged, Fast Ethernet (10/100), Full duplex

Nog slechts 4 beschikbaar

Fabrikant Digitus
MPN DN-80069
EAN 4016032478676
€ 20,00 excl. BTW

Digitus DN-80069 netwerk-switch Unmanaged Fast Ethernet (10/100) Zwart

8-port 10/100Mbps unmanage Fast Ethernet Switch, Auto-Negotiation RJ45 ports, All ports support Auto MDI/MDIX function

- 8 x RJ45 ports 10/100 Mbps
- All ports support 10/100 Mbps bandwidth
- Network standards: IEEE 802.3i, IEEE 802.3u, IEEE802.3x, IEEE802.3az
- Full-duplex flow control IEEE802.3x
- Store and forward mode operates
- Auto-negotiation / Auto-MDI/MDI-X
- No configuration necessary
- LED indicators for monitoring power, link/activity

The 8-Port 10/100 Mbps Networkswitch from DIGITUS® provides 5 x RJ45 ports with 10/100Mbps bandwidth each. Easily expand the existing network. No configuration is required on the switch itself; thanks to auto-negotiation and Auto MDI/MDI-X, cables and speeds are also automatically detected. The switch can be used as a desktop variant or mounted on a wall. Thanks to the external power supply, the switch does not need a fan at all. Ideal for expanding / setting up small home or company network.
  • Number of ports: 8 x 10/100 Mbps
  • Network standards: IEEE 802.3i, IEEE 802.3u, IEEE802.3x, IEEE802.3az
  • Auto-negotiation: Auto MDI/MDIX
  • IEEE802.3x full-duplex flow control
  • Transfer method: Store-and-forward
  • Forwarding capacity: 745 Kpps
  • LED indicators: 10/100Mbps link
  • Jumbo frames: 1552 Byte
  • Buffer memory: 448 kbit
  • MAC addresses: 1K
  • Fanless design
  • Operating voltage: 5 V DC / 500 mA
  • Power consumption: 1,4 W max.
  • Power supply Power supply: 100 - 240 V AC, 50/60 Hz,
  • Plug type power supply: safety plug type-C
  • Plug type device side: DC plug 5.5 mm/2.1 mm
  • Operating temperature: 0°C to 40°C
  • Operating humidity: 10% - 90% RH (non-condensing)
  • Storage temperature: -40°C to 70°C
  • Fanless design (air flow cooling)
  • Dimensions: W 140 x D 67 x H 26 mm
  • Weight: 635 g

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Fast Ethernet (10/100)
Fast Ethernet (koperen) ports kwantiteit
8
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Full duplex
Ja
Auto MDI/MDI-X
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100 Mbit/s
Auto-negotiation
Ja
VLAN=ondersteuning
Nee

Data-uitwisseling

Verzending snelheid
745 Mpps
MAC-adrestabel*
1000 entries
Store-and-forward
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
1552
Packet buffergeheugen
0,448 MB

Design

Rack-montage*
Nee
Stapelbaar*
Nee
Kleur van het product
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Activiteit, Link, Stroom
Vandaalbestendig
Nee
Geschikt voor buitengebruik
Nee
Land van herkomst
China

Prestatie

Fanloos
Ja

Energie

Stroombron*
AC/DC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
DC voltage input
5 V
Stroom
0.5 A
Vermogensverbruik (max)
1,4 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent

Gewicht en omvang

Breedte
140 mm
Diepte
67 mm
Hoogte
26 mm
Gewicht
635 g

Verpakking

Snelstartgids
Ja
Breedte verpakking
156 mm
Diepte verpakking
79 mm
Hoogte verpakking
67 mm
Verpakkingsvolume
825,708 cm³
Gewicht verpakking
393,333 g

Overige specificaties

Ethernet interface type
Fast Ethernet
