Digitus DN-80221-3 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Zwart, Grijs

Digitus DN-80221-3, Managed, L2, Gigabit Ethernet (10/100/1000), Rack-montage

Nog 14 beschikbaar

Fabrikant Digitus
MPN DN-80221-3
EAN 4016032467687
€ 185,00 excl. BTW

Digitus DN-80221-3 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Zwart, Grijs

Highest bandwidth and performance for professional demands. Superior manageability via WebUI!

- 24 x 10/100/1000BaseTX ports
- 2 x Uplink RJ45/SFP combo ports
- 2 x SFP uplink ports
- 1 x RJ45 console port integrated
- Layer-2 features configurable via WebUI
- Extensive Layer 2 features for optimal configuration
- L2 features: VLAN, Link-Aggregation, Port-Mirroring, Port-Trunking, SNMP Netzwerk Management, QoS-/CoS-Anwendungen, STP/RSTP/MSTP
- Installation in 19" server and wall cabinets possible

The DIGITUS® Gigabit Ethernet Layer 2 switches with 24 x RJ45 Gigabit ports and 4 uplink ports are designed for medium to large network systems. For the uplink ports, you have the choice of 2 x SFP/RJ45 combo ports and 2 pure SFP uplink ports. They provide smart features that are ideal for simple QoS/CoS applications and the 19'' size makes an uncomplicated integration into your network possible. The switches are a great choice to improve the performance and efficiency of your network.
  • 24 x RJ45 ports (1000Mbps)
  • 2 x RJ45/ SFP combo ports for fiber optic connection or Ethernet
  • 2 x SFP uplink ports for SFP modules
  • 1 x RJ45 console port
  • Compatible with following standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z and 802.3ad - Auto MDI/MDI-X Funktion
  • 8K MAC addresses
  • QoS support layer 4 classification
  • Port mirroring for efficient network surveillance
  • Port Trunk for bandwidth aggregation
  • VLAN for performance and security
  • 802.1x Port Authentication
  • SNMP Network Management
  • Built-in Web-based management
  • Surge protection +/- 6 kV
  • Dimensions: 440 x 208 x 44 mm (WxDxH)

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Combo SFP-poorten
2
Aantal moduleslots SPF
2
Console port
RJ-45

Netwerk

Netwerkstandaard*
IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Port mirroring
Ja
Auto MDI/MDI-X
Ja
VLAN=ondersteuning
Ja

Data-uitwisseling

MAC-adrestabel*
8000 entries

Beveiliging

Ondersteunde beveiligingsalgoritmen
SNMP
Authenticatie
Poortgebaseerde authenticatie

Design

Rack-montage*
Ja
Kleur van het product
Zwart, Grijs

Design

Vandaalbestendig
Nee
Geschikt voor buitengebruik
Nee
Land van herkomst
China

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Gewicht en omvang

Breedte
440 mm
Diepte
208 mm
Hoogte
44 mm

Verpakking

Meegeleverde kabels
AC
Snelstartgids
Ja
Rekbevestigingspakket
Ja
Breedte verpakking
300 mm
Diepte verpakking
562 mm
Verpakkingsvolume
15174 cm³
Gewicht verpakking
2,15 kg

Logistieke gegevens

Code UK-handelstarief
85176200
Code geharmoniseerd systeem (HS)
85176990

Overige specificaties

Ethernet interface type
Gigabit Ethernet
