Digitus DN-95104 PoE adapter & injector Gigabit Ethernet 55 V
Reduce cabling for Wireless APs, IP Phone and any PoE-ready device
- Complies with the 802.3at Ultra PoE and 802.3af PoE standards
- Easily merge of power and data cables into a single cable
- Extend your network to places where there are no power supply cables or sockets available
- no setup needed
- The output is equipped with a current limit, a short-circuit fuse, and automatic terminal device recognition and classification.
The Digitus PoE Injector allows you to minimize cabling during installation of PoE-ready devices such as IP network cameras. Data supply and power supply to the devices is accomplished using a single Ethernet cable. This makes laying a separate power cable unnecessary and allows you to extend your network to places where there are no outlets or power cables. The Injector is fully compliant with the IEEE802.3at Ultra PoE standard and delivers an output power of 60 W.
- Complies with the 802.3at Ultra PoE and 802.3af PoE standards
- Easily merge of power and data cables into a single cable
- Extend your network to places where there are no power supply cables or sockets available
- no setup needed
- The output is equipped with a current limit, a short-circuit fuse, and automatic terminal device recognition and classification.
The Digitus PoE Injector allows you to minimize cabling during installation of PoE-ready devices such as IP network cameras. Data supply and power supply to the devices is accomplished using a single Ethernet cable. This makes laying a separate power cable unnecessary and allows you to extend your network to places where there are no outlets or power cables. The Injector is fully compliant with the IEEE802.3at Ultra PoE standard and delivers an output power of 60 W.
- Complies with the 802.3at Ultra PoE and 802.3af PoE standards
- Easily merge of power and data cables into a single cable
- Extend your network to places where there are no power supply cables or sockets available
- no setup needed
- Supports all IEEE 802.3at-compliant PoE devices (such as access points, VoIP telephones, and IP cameras)
- Transmission range of up to 100 m – with an additional PoE extender, this can be increased to up to 400 m
- Own consumption: 1,6W max
- Internal consumption (full loaded): 10 W max.
- Input: 1x RJ-45 (data)
- Output: 1x RJ-45 (power and data)
- Data output: 100/100/1000 Mbps Gigabit
- Power output: 60 W
- Output voltage: 55 V DC
- Operating temperature range: -10 °C to +45 °C
- Dimensions: 193 mm x 85 mm x 41 mm
- Weight: 380 g
- The output is equipped with a current limit, a short-circuit fuse and automatic terminal device recognition and classification.
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Netwerk
Ethernet interface type
Gigabit Ethernet
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Power over Ethernet (PoE)
Ja
Netwerkstandaard
IEEE 802.3at
Kenmerken
Kleur van het product
Zwart
Maximale afstand
400 m
LED-indicatoren
Ja
Land van herkomst
China
Poorten & interfaces
Aantal Ethernet LAN (RJ-45)-poorten
2
Aansluiting voor netstroomadapter
Ja
Energie
Stroom via Ethernet (PoE)*
55 V
Uitgangsvermogen
60 W
Vermogensverbruik (max)
10 W
Totaal Power over Ethernet (PoE)-budget
60 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
-10 - 45 °C
Gewicht en omvang
Gewicht
380 g
Afmetingen (B x D x H)
193 x 85 x 41 mm
Verpakking
Breedte verpakking
140 mm
Diepte verpakking
210 mm
Gewicht verpakking
602,5 g
Verpakkingsvolume
1470 cm³
Inhoud van de verpakking
Aantal producten inbegrepen
1 stuk(s)
Logistieke gegevens
Code UK-handelstarief
85176200
Code geharmoniseerd systeem (HS)
85044095
