Digitus DN-95331, Managed, L2+, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)

Nog slechts 9 beschikbaar

Fabrikant Digitus
MPN DN-95331
EAN 4016032464365

Digitus DN-95331 netwerk-switch Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

L2+ managed Gigabit PoE Switch 802.3at - suitable for installation in 10-inch housing

- 8-Port 10/100/1000 Mbps
- 8 x PoE ports with 80 W total output 802.3at (PoE+)
- Network standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at
- IEEE802.3x full-duplex flow control & IEEE 802.3ab link aggregation
- Management interfaces: WEB, SNMP, SSH, CLI, Telnet, TACACS+, RMON
- PoE Management, Port Control, Port Isolation, Loop Detection, Port Mirroring
- Backplane bandwidth: 16 Gbps
- VLAN features
- L2+ layer features

The 8-port Gigabit PoE Switch is designed for the networks of small to mid-sized companies. With special features such as port control, port mirroring, VLAN functions and multicast support, the switch is optimally tailored to the application convergence needs of mid-sized networks. Based on ASIC integration technology, non-blocking IP switching solutions are supported with gigabit speed. The switch can be used as a desktop switch or for installation in 10-inch housing. 8 gigabit ports with PoE+ support and a total output of 80 watts are integrated, which you can use to operate devices such as wireless access points, IP cameras or VoIP telephones. The switch can be configured for specific requirements using various interfaces. The installation height is one rack unit.
  • Number of PoE ports: 8 x 10/100/1000Base-TX RJ45
  • Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x full-duplex flow control, IEEE802.3ab link aggregation
  • PoE standards: IEEE802.3af, IEEE802.3at
  • Forwarding rate: 10/100/1000Mbps
  • LED displays: Power, Link/Act
  • Backplane bandwidth: 16G
  • Forwarding capacity: 11.9 Mpps
  • Jumbo frame size: 16 K
  • MAC addresses: 8K
  • Package buffer storage: 4.1 Mbit
  • RAM for CPU: 1 Gbit / Flash memory: 128 Mbit
  • PoE total budget: 80 watt output 802.3at (PoE+ support)
  • PoE budget per port: 30 watt max.
  • PoE voltage: 52 V
  • PoE PIN assignment: V- (RJ45 Pin1, 2), V+ (RJ45 Pin 3,6) Mode A, Endspan
  • PoE Management: PoE status and control, PoE schedule, PD alive auto check
  • Port features: Port Control, Port Isolation, Port Loop Detection
  • Port mirroring: Multi to 1 Sniffer
  • VLAN: Port-based & 802.1q Tag-based VLANs
  • Link aggregation: 8 groups
  • Rate limit: 64kbps
  • Spanning tree: Supports STP, RSTP, MSTP
  • Ring protocol: Supports EAPS
  • Multicast: Supports 256 multicast groups & IGMP snooping for multimedia applications
  • Supports Static ARP & Static Routing, up to 32 VLAN interfaces
  • QoS: 4 lines per port, scheduling algorithm: WRR, SP, WFQ, port-based, MAC-based, 802.1p, DSCP classification
  • ACL: Standard IP, Extend IP, MAC IP, ARP, 512 entries
  • Security: MAC-based authentication, AAA/RADIUS authentication, WEB/Telnet password protection, Accessing privilege mode password protection
  • Supports SMNP
  • Supports ICMPv6, IPv6 Neighbor Discovery, MLD Snooping, IPv6 Telnet
  • Management interfaces: WEB, SNMP, SSH, CLI, Telnet, TACACS+, RMON
  • L3-VLAN Interface: 32
  • Operating voltage: 100 - 240 V AC, 50/60 Hz, integrated power adapter (IEC C13 plug for non-heating appliances)
  • Power suppy: 96 W max.
  • Operating temperature: 0 °C to 40 °C
  • Storage temperature: -10 °C to +70 °C
  • Operating humidity: 5% - 95% (non condensing)
  • Housing: Metal (with protective conductor terminal)
  • Dimensions: W 250 x D 150 x H 44 mm
  • Weight: 1.140 kg (without packaging)

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2+
Quality of Service (QoS)
Ja
ARP-inspectie
Ja
Locatie-instellingen (CLI) configureren
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)

Netwerk

Netwerkstandaard*
IEEE 802.3at
Full duplex
Ja
IP routing
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Interface-based VLAN, Port-based VLAN, Tagged VLAN

Data-uitwisseling

Verzending snelheid
11,9 Mpps
MAC-adrestabel*
8000 entries
Jumbo Frames ondersteuning
Ja
Jumbo frames
16000

Beveiliging

Access Control List (ACL)
Ja
IGMP snooping
Ja
SSH/SSL support
Ja

Multicast-functies

Multicast-ondersteuning
Ja

Design

Rack-montage*
Nee
Stapelbaar*
Ja
Kleur van het product
Zwart
Vandaalbestendig
Nee

Design

Geschikt voor buitengebruik
Nee
Land van herkomst
China

Energie

Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Stroomverbruik (typisch)
96 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Type Power over Ethernet (PoE) ondersteunt
PoE+
Totaal Power over Ethernet (PoE)-budget
80 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-10 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent

Gewicht en omvang

Breedte
250 mm
Diepte
150 mm
Hoogte
44 mm
Gewicht
1,14 kg

Verpakking

Breedte verpakking
240 mm
Diepte verpakking
70 mm
Verpakkingsvolume
5376 cm³
Gewicht verpakking
1,6 kg

Logistieke gegevens

Code UK-handelstarief
85176200
Code geharmoniseerd systeem (HS)
85176990

Overige specificaties

Ethernet interface type
Gigabit Ethernet
