Digitus DN-95355 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Zwart

Digitus DN-95355, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack-montage, 1U

Ruim op voorraad

Fabrikant Digitus
MPN DN-95355
EAN 4016032485056
€ 155,00 excl. BTW

Digitus DN-95355 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Zwart

Key Function: VLAN & CCTV

- 16*10/100Mbps PoE RJ45 Ports
- 1*10/100/1000Mbps Combo Ports
- 1*10/100/1000Mbps RJ45 Ports
- Complies with IEEE802.3af/at Power over Ethernet
- Supports PoE Power up to 30W for each PoE port
- Auto detect power device
- Remote power and Data feeding up to 100m
- Flow Control for Full Duplex operation and back pressure for Half Duplex Operation
- Support VLAN and CCTV function
- 8K MAC address, automatic address learning and address aging
- Support Energy-Efficient Ethernet (EEE) function EEE802.3az
- Support PD Alive function(the switch port is disconnected will automatically connected)

"DN-95355 PoE Switch is 16-port 10/100Mbps PoE + 1G Combo +1GE PoE Switch.
The PoE ports can automatically detect and supply power to IEEE802.3af/at compliant Powered Devices (PD).
The electrical power and data transmission on the same cable can expand your network to the places where no power lines or outlets,
where you can install devices such as APs, IP cameras, or IP phones etc.
The PoE Switch provides a simple, cost- effective, and non-blocking wire-speed performance
with 11-inch metal shape for rack deployment in office or department network application.
  • 16*10/100Mbps PoE RJ45 Ports
  • 1*10/100/1000Mbps Combo Ports
  • 1*10/100/1000Mbps RJ45 Ports
  • Complies with IEEE802.3af/at Power over Ethernet
  • Supports PoE Power up to 32W for each PoE port
  • Auto detect power device
  • Remote power and Data feeding up to 100m
  • Flow Control for Full Duplex operation and back pressure for Half Duplex Operation
  • Support VLAN and CCTV function
  • 16K MAC address, automatic address learning and address aging
  • Support Energy-Efficient Ethernet (EEE) function EEE802.3az
  • Support PD Alive function(the switch port is disconnected will automatically connected)
  • Standard: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af, IEEE802.3at
  • Interface: 16*10/100Mbps RJ45 port, 1*10/100/1000Mbps Combo port 1 * 10/100/1000Mbps RJ45 port
  • Network Media: 10BASE-T: UTP category 3,4,5 cable (≤100m),100BASE-TX: UTP category 5,5e cable (≤100m),1000BASE-T: UTP category 5e,6 cable (≤100m),1000BASE-X: SMF, MMF
  • LED: PWR, PoE, LINK/ACT, PoE Max

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
16
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Fast Ethernet (koperen) ports kwantiteit
16
Aantal Gigabit Ethernet (koper)-poorten
1
Aantal Combo SFP-poorten
1
Netstekker
AC-in-aansluiting

Netwerk

Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Koperen ethernetbekabelingstechnologie
100BASE-TX, 1000BASE-TX
Ondersteundende kabel types
Cat5, Cat5e, Cat6
Full duplex
Ja
Half-duplex
Ja
Datastroombeheer
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
MAC-adres zelflerende functie
Ja
MAC-adres zelfverouderende functie
Ja
VLAN=ondersteuning
Ja

Data-uitwisseling

MAC-adrestabel*
16000 entries

Design

Rack-montage*
Ja
Stapelbaar*
Nee
Vormfactor
1U
Kleur van het product
Zwart
Materiaal behuizing
Metaal

Design

LED-indicatoren
Ja
Aantal ventilatoren
1 ventilator(en)
Land van herkomst
China

Energie

Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Vermogen per poort Power over Ethernet (PoE)
32 W

Gewicht en omvang

Breedte
180 mm
Diepte
280 mm
Hoogte
44 mm
Gewicht
1,75 kg

Verpakking

Meegeleverde kabels
AC
Snelstartgids
Ja
Breedte verpakking
230 mm
Diepte verpakking
80 mm
Hoogte verpakking
370 mm
Verpakkingsvolume
6808 cm³
Gewicht verpakking
2,5 kg

Logistieke gegevens

Code UK-handelstarief
85176200
