Digitus DN-95357 netwerk-switch Fast Ethernet (10/100) Power over Ethernet (PoE) Zwart
Digitus DN-95357, Fast Ethernet (10/100), Full duplex, Power over Ethernet (PoE)
Ruim op voorraad
Fabrikant
Digitus
MPN
DN-95357
EAN
4016032485926
€ 83,00
excl. BTW
€ 83,00
excl. BTW
excl. BTW
Digitus DN-95357 netwerk-switch Fast Ethernet (10/100) Power over Ethernet (PoE) Zwart
CCTV function for 250 meters of ultra-long-distance transmission
- Support IEEE802.3 at standard, compatible with IEEE802.3 af by electrical equipment (PD)
- Stand-up output power up to 30W
- Support IEEE802.3 x full duplex flow control and Backpressure half duplex flow control
- Panel lights to monitor working state and help fault analysis
- Perfect security mechanism
- Line-speed forwarding intelligent identification
- Support CCTV Function
- Support Energy-Efficient Ethernet (EEE) function (IEEE802.3az)
- Support PD-ALIVE function
DN-95357 has a CCTV function for 250 meters of ultra-long-distance transmission. Users can choose to turn on or off the CCTV function. Improve network security and restrain network storms, facilitate management and maintenance, and meet the networking and access requirements of enterprises, communities, hotels. office networks, and campus networks.
- Support IEEE802.3 at standard, compatible with IEEE802.3 af by electrical equipment (PD)
- Stand-up output power up to 30W
- Support IEEE802.3 x full duplex flow control and Backpressure half duplex flow control
- Panel lights to monitor working state and help fault analysis
- Perfect security mechanism
- Line-speed forwarding intelligent identification
- Support CCTV Function
- Support Energy-Efficient Ethernet (EEE) function (IEEE802.3az)
- Support PD-ALIVE function
DN-95357 has a CCTV function for 250 meters of ultra-long-distance transmission. Users can choose to turn on or off the CCTV function. Improve network security and restrain network storms, facilitate management and maintenance, and meet the networking and access requirements of enterprises, communities, hotels. office networks, and campus networks.
- Interface: 10＊10/100/1000Mbps auto-negotiation RJ45 port
- PoE standard: IEEE802.3af/at
- PoE port: 1~8
- PoE total: 60W
- Power supply: 65W
- Key function: CCTV
- PoE port output:Max 30W
- RJ45 PoE power supply: Mode A Anode1/2 Cathode3/6
- Indicator: PWR（Green）, LNK/ACT （Green）PoE（Orange）
- Network media: 10BASE-T: UTP category 3,4,5 cable （≤100m）
- 100BASE-TX: UTP category 5, 5e cable （≤100m）
- 1000BASE-T: UTP category 5, 5e cable （≤100m）
- MAC Address Table: 2K, Automatic study, automatic updates
- jumbo frame: 9216Bytes
- Packet buffer: 2Mbit
- Transfer Mode: Store-and-forward
- Packet Forward Speed: 14.88Mpps
- Bandwidth: 20Gbps
- Device Dimension: 168*93*32mm
- green energy saving: Support IEEE（802.3az）
- mains input: 100~240V AC, 50/60Hz
- Operating Temperature: 0°C ~ 40 °C
- Storage Temperature: -40 °C ~ 70 °C
- Operating Humidity: 10% ~ 90% non-condensing
- Storage Humidity: 5% ~ 90% non-condensing
- Surge Protection: Common mode ±2KV, differential mode ±1KV
- MTBF: >50000 hour
- Electrostatic standard: Contact ±6KV, air ±8KV
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten*
10
Type basis-switching RJ-45 Ethernet-poorten*
Fast Ethernet (10/100)
Fast Ethernet (koperen) ports kwantiteit
10
Netstekker
AC-in-aansluiting
Netwerk
Netwerkstandaard*
IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
10G support*
Nee
Koperen ethernetbekabelingstechnologie
10BASE-TX, 1000BASE-T
Ondersteundende kabel types
Cat3, Cat4, Cat5, Cat5e
Full duplex
Ja
Half-duplex
Ja
Datastroombeheer
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100 Mbit/s
Data-uitwisseling
Verzending snelheid
14,88 Mpps
MAC-adrestabel*
2000 entries
Store-and-forward
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
9216
Packet buffergeheugen
2 MB
Design
Rack-montage*
Nee
Stapelbaar*
Nee
Kleur van het product
Zwart
LED-indicatoren
Activiteit, Power over Ethernet (PoE), Link, Stroom
Land van herkomst
China
Prestatie
Mean time between failures (MTBF)
50000 uur
Energie
Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
Energie
AC-ingangsfrequentie
50 - 60 Hz
Stroomverbruik (typisch)
65 W
Spanningsbeveiliging
Ja
Overspanningsbeveiliging in voltage
2 kV
Power over Ethernet (PoE)
Power over Ethernet (PoE)*
Ja
Hoeveelheid Power over Ethernet (PoE) ports
8
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
60 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 90 procent
Gewicht en omvang
Breedte
168 mm
Diepte
93 mm
Hoogte
32 mm
Verpakking
Meegeleverde kabels
AC
Snelstartgids
Ja
Breedte verpakking
192 mm
Diepte verpakking
237 mm
Hoogte verpakking
87 mm
Verpakkingsvolume
3958,85 cm³
Gewicht verpakking
1,03 kg
Logistieke gegevens
Code UK-handelstarief
85176200
Overige specificaties
Bandbreedte
20 Gbit/s
