Digitus DN-95359 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Zwart

Digitus DN-95359, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack-montage, 1U

Nog 14 beschikbaar

Fabrikant Digitus
MPN DN-95359
EAN 4016032486503
€ 362,00 excl. BTW

Digitus DN-95359 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Zwart

The DN-95359 is a case-shaped device with a chassis of 1U high. It provides 24 10/100/1000Base-TX ports + 2 gigabit SFP ports. It provides 24 Port PoE Injector.

- Provides 24 10/100/1000 Base-TX ports + 2 gigabit SFP ports, Provides 24 PoE injector
- Build-in power supplies, 330W, High back-plane bandwidth 52Gbps
- Support ICMPv6, IPv6 Neighbor Discovery,MLD Snooping, IPv6 Telnet, standard IP/ Extend IP / MAC IP / ARP ACL, IGMP snooping for Multi-media application
- Support Port mirror and bandwidth control,IEEE802.3x Flow control
- Support Port Based VLAN / 802.1Q Tag VLAN, IEEE802.3ad Port trunk with LACP
- Support Spanning tree protocol IEEE802.1d/802.1w/802.1s
- Support IEEE 802.1p class of service, IEEE 802.1x user authentication
- Support Broadcast storm filter, System event log, command line interface management
- Management by Web / SNMP / SSH / Telnet (IPv6 ready) / Console

The DN-95359 is a manageable 24 +2 port PoE switch with L2 features. It is mainly used in the structural LAN area. With a total PoE power budget of 330 watts, the DN-95359 supplies up to 24 connected PoE devices such as IP security cameras or VoIP telephones with up to 30 watts per port. Due to the large backplane bandwidth of 52 Gbps, data can be processed and forwarded quickly. Furthermore, features such as ICMPv6, IGMP & MLD snooping, port mirroring, broadcast storm filter and many more are supported.
  • Provides 24 10/100/1000 Base-TX ports + 2 gigabit SFP ports
  • Provides 24 PoE injector
  • Build-in power supplies, 330W
  • High back-plane bandwidth 52Gbps
  • Support ICMPv6
  • Support IPv6 Neighbour Discovery
  • Support MLD Snooping
  • Support IPv6 Telnet
  • Support standard IP/ Extend IP / MAC IP / ARP ACL
  • Support IGMP snooping for Multi-media application
  • Support Port mirror and bandwidth control
  • Support IEEE802.3x Flow control
  • Support Port Based VLAN / 802.1Q Tag VLAN
  • Support IEEE802.3ad Port trunk with LACP
  • Support Spanning tree protocol IEEE802.1d/802.1w/802.1s
  • Support IEEE 802.1p class of service
  • Support IEEE 802.1x user authentication
  • Support Broadcast storm filter
  • Support System event log
  • Support command line interface management
  • Management by Web / SNMP / SSH / Telnet (IPv6 ready) / Console
  • Switching Capacity: 52 Gbps
  • Forwarding Capacity: 38.7 Mpps
  • Forwarding Mode:Store and Forward
  • Packet Buffer Memory: 4.1 Mbit
  • RAM for CPU: 1 Gbit
  • Flash Memory: 128 Mbit
  • MAC Address Table: 8K
  • Max. Jumbo Frame size: 16K
  • VLAN Quantity: 4K
  • ACL Table: 512
  • L3 Interface: 32
  • Port Queues: 8
  • Dimensions: 440 x 200 x 44 mm
  • Operating Temperature: 0 to 40℃
  • Storage Temperature:-10 to 70℃
  • Operating Humidity: 5 to 95% Noncondensing
  • Power Method: 100-240VAC, 50/60Hz
  • Max. Power ConsumptionIncluding PoE Output: 330W
  • Max. power consumption including PoE output: 330W

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
System event log
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
26
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
24
Aantal geïnstalleerde SFP modules*
2
Vezel-optische connector
SFP

Netwerk

Netwerkstandaard*
IEEE 802.3at
10G support*
Nee
Port mirroring
Ja
Datastroombeheer
Ja
Broadcast stormbeheer
Ja
Spanning tree protocol
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Port-based VLAN, Tagged VLAN
Aantal VLANs
4094

Data-uitwisseling

Switchingcapaciteit*
52 Gbit/s
Verzending snelheid
38,7 Mpps
MAC-adrestabel*
8000 entries
Store-and-forward
Ja
Aantal wachtrijen
8
Jumbo Frames ondersteuning
Ja
Jumbo frames
16000
Packet buffergeheugen
4,1 MB

Beveiliging

Access Control List (ACL)
Ja
IGMP snooping
Ja

Multicast-functies

Multicast Listener Discovery (MLD) snooping
✓

Protocollen

IPv4- & IPv6-functies
IPv6 Telnet

Design

Rack-montage*
Ja
Stapelbaar*
Nee
Vormfactor
1U

Design

Kleur van het product
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Ja
Land van herkomst
China

Prestatie

Flash memory
128 MB

Energie

Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50/60 Hz
Uitgangsvermogen
24 W
Vermogensverbruik (max)
330 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Totaal Power over Ethernet (PoE)-budget
330 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-10 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent

Gewicht en omvang

Breedte
440 mm
Diepte
200 mm
Hoogte
44 mm

Verpakking

Meegeleverde kabels
AC
Gebruikershandleiding
Ja
Rekbevestigingspakket
Ja
Breedte verpakking
280 mm
Diepte verpakking
102 mm
Hoogte verpakking
505 mm
Verpakkingsvolume
14422,8 cm³
Gewicht verpakking
4,24 kg

Logistieke gegevens

Code UK-handelstarief
85176200

Overige specificaties

Bandbreedte
52 Gbit/s
Ethernet interface type
Gigabit Ethernet
