Digitus DS-12882 KVM-switch Zwart

Digitus DS-12882, 3840 x 2160 Pixels, 4K Ultra HD, Zwart

Ruim op voorraad

Fabrikant Digitus
MPN DS-12882
EAN 4016032478140
€ 184,00 excl. BTW

Digitus DS-12882 KVM-switch Zwart

Operate 4 PCs with dual display using a USB keyboard and mouse combination – switch between four computers by pressing a button

- Use two monitors, a mouse / keyboard to operate 4 computers with dual display
- Supports a maximum UHD resolution of 4K / 60 Hz + FreeSync
- USB ports for mouse and keyboard
- Audio connections for microphone/speaker, supports Dolby True HD and DTS HD Master Audio
- Integrated USB hub with USB A port for additional peripheral equipment
- Switching between the PCs via switch on the KVM switch or hot key on the keyboard
- LED status and functional displays on the front side
- The KVM switch is supplied with power via the USB connection through a connected computer
- Real Plug and Play - no software or driver installation required (BIOS hardware connection)
- Sturdy metal housing

With the DIGITUS® 4-Port KVM Switch for dual displays, you can operate four 4k-compatible PCs using a single USB keyboard and mouse combination. By pressing a button or hot key, you can switch comfortably between all four PCs and are spared the trouble of replugging all cables. Output on up to two monitors is provided via two DisplayPort® outputs on the rear side. You can also switch between the audio signals for the microphone and speaker. In addition, a USB port is included on the front side for use with other peripheral devices like USB sticks or external hard drives on both PCs. The connected peripheral devices are each assigned to the active PC. Status LEDs on the front side of the switch show you the current configuration at all times. The slim switch features the added benefits of sturdy metal housing.
  • UHD resolution: 4K / 60 Hz (3840 x 2160p) / Subsampling: YUV 4:4:4
  • Inputs: 8 x DP® inputs (4x2), 4 x USB B, 4 x Audio combo socket 3.5 mm jack (microphone, speaker)
  • Outputs (console): 2 x DP®, 2 x USB A (mouse, keyboard), 2 x Stereo audio 3.5 m jack (microphone, speaker)
  • Additional connection on the front side: 1 x USB A for additional peripheral equipment such as printers or USB sticks
  • USB specifications: USB 2.0 compliant (full speed)
  • Supported audio formats: Dolby True HD, DTS HD Master Audio
  • Switching between the PCs: Switch on the front side or hot keys
  • Status LED on front side shows current configuration
  • The device is platform-independent, suitable for all operating systems
  • Operating temperature: 0 °C to 50 °C
  • Storage temperature: -20 °C to +60 °C
  • Operating humidity: 0% - 80% RH (non-condensing)
  • Case material: Metal
  • Power supply device: USB power supply or optional 9 V DC power adapter (300 mA, 5.5x2.1 mm plug)
  • Dimensions: 20.2 x 11.0 x 6.6 cm (WxDxH)
  • Weight: 920 g

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Aantal computers*
1
Aansluiting toetsenbord*
USB
Aansluiting muis*
USB
Aansluiting video*
DisplayPort
Aantal DisplayPorts
8
Aantal poorten USB 2.0 Type-B
4
Console-poorten*
3.5mm hoofdtelefoon, 3.5mm mic, DisplayPort, USB A
Aantal USB-poorten console
2
Aantal Console DisplayPorts-poorten
2
Audio-aansluitingen
Ja
Aansluiting voor netstroomadapter
Ja

Prestatie

HD type*
4K Ultra HD
Maximum resolutie*
3840 x 2160 Pixels
Videobandbreedte
60 Hz
Aantal displays ondersteund
4

Design

Rack-montage*
Nee
Kleur van het product*
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Ja
Sneltoetsen
Ja

Beeldscherm

Ingebouwd display*
Nee

Energie

Stroombron
DC
DC voltage input
9 V

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C
Temperatuur bij opslag
-20 - 60 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 80 procent
Luchtvochtigheid bij opslag
0 - 80 procent

Gewicht en omvang

Breedte
202 mm
Diepte
110 mm
Hoogte
66 mm
Gewicht
920 g

Verpakking

Breedte verpakking
230 mm
Diepte verpakking
220 mm
Verpakkingsvolume
8096 cm³
Gewicht verpakking
1,85 kg

Inhoud van de verpakking

Meegeleverde kabels
DisplayPort, KVM
Gebruikershandleiding
Ja

Logistieke gegevens

Code UK-handelstarief
84718000
Land van herkomst
China
