Digitus DS-12890 KVM-switch Zwart

Digitus DS-12890, 4096 x 2160 Pixels, 4K Ultra HD, 11,75 W, Zwart

Ruim op voorraad

Fabrikant Digitus
MPN DS-12890
EAN 4016032475606
€ 165,00 excl. BTW

Digitus DS-12890 KVM-switch Zwart

Operate 4 PCs with one USB keyboard and mouse – switch between four computers by pressing a button or with the remote control

- Use a monitor, a mouse and a keyboard to operate four computers
- USB ports for mouse and keyboard
- Audio connections for microphone/speaker
- Integrated USB hub with 2 x USB 3.0 connections for additional peripheral equipment
- Switching between the PCs via switch on the KVM switch, remote control or hot key on the keyboard
- External receiver for signals from remote control included
- Compatible with HDMI 2.0 / HDCP 2.2 / DisplayPort 1.2 / HDR / FreeSync
- LED status and functional displays on the front side
- Wall installation possible
- Plug and Play - no driver installation required

With the DIGITUS® 4-Port KVM Switch, you can operate four 4k-compatible PCs using a single USB keyboard and mouse. By pressing a button or using the remote control included in delivery, you can switch comfortably between the PCs, sparing you the trouble of replugging all cables. Output to a monitor occurs either via the integrated HDMI® or the DisplayPort™ output. You can also switch between the audio signals for the microphone and speaker. In addition, two USB 3.0 ports are included on the front side for use with other peripheral devices like USB sticks or external hard drives on all PCs. If you place the KVM switch in an inaccessible location, you can use the IR receiver and connection cable included in delivery even if the KVM switch itself is not within the range of the remote control. Status LEDs on the front side of the switch show you the current configuration at all times. The slim switch features the added benefits of sturdy metal housing and the option of wall mounting.
  • Inputs: 4 x DisplayPort™, 4 x USB B (3.0), 4 x audio input, 4 x audio output
  • Output: 1 x DisplayPort™, 1 x HDMI®, 1 x audio input, 1 x audio output, 2 x USB A 2.0
  • Additional connections front side: 2 x USB A 3.0, 1 x audio input, 1 x audio output, 1x infrared receiver, 1x IR output
  • Audio inputs/outputs: 3.5 mm stereo jack socket
  • LED front side: Power, 4 x Online, 4 x Selection PC
  • Switch: Power On/Off, Toggle PC1 / PC2 / PC3 / PC4
  • HDMI® version: 2.0
  • HDCP version: 2.2 / 1.4
  • DisplayPort™ version: 1.2
  • UHD resolution: 4096 x 2160p / 60 Hz
  • Subsampling: RGB 4:4:4/ YCbCr 4:4:4/ YCbCr 4:2:2/ YCbCr 4:2:0
  • Bandwidth DisplayPort™: 32.4 Gbps all channels (8.1 Gbps per channel), supports HDR
  • Bandwidth HDMI®: 18 Gbps all channels (6 Gbps per channel), supports HDR
  • Color depth DisplayPort™: 48 bit (all channels)
  • Color depth HDMI®: 36 bit (all channels)
  • Power supply power adapter: 100 - 240 V AC / 50/60 Hz, 0.6 A
  • Power supply KVM switch: 5 V / 3 A / 15 W
  • Operating temperature: 0°C ~ 45°C
  • Operating humidity: 10% - 85% RH (non-condensing)
  • Housing material: Metal
  • Installation bracket for wall mounting included
  • External receiver for signals from remote control included
  • Dimensions: 24,3 x 7.5 x 2.6 cm (WxDxH)
  • Weight: 505,4 g
  • Color: Black

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Aansluiting toetsenbord*
USB
Aansluiting muis*
USB
Aansluiting video*
HDMI/DisplayPort
Aantal HDMI-poorten
1
HDMI versie
2.0
Aantal DisplayPorts
5
DisplayPort versie
1.2
Console-poorten*
3.5mm hoofdtelefoon, 3.5mm mic, DisplayPort, USB B
Aantal USB 2.0-Type-A-hubpoorten
2
Aantal USB 3.2-hubpoorten type A (3.1 Gen 1)
2
Aansluiting voor netstroomadapter
Ja

Prestatie

HD type*
4K Ultra HD
Maximum resolutie*
4096 x 2160 Pixels
Videobandbreedte
60 Hz
HDCP
Ja
Plug and play
Ja

Design

Rack-montage*
Nee
Kleur van het product*
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Ja
Schermschakelknop
Ja
drukknop
Ja

Beeldscherm

Ingebouwd display*
Nee

Energie

AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
DC voltage input
5 V
Stroom
0.6 A

Energie

Spanning
5 V
Output current
3 A
Stroomverbruik (typisch)
11,75 W
Externe adapter
Ja

Minimale systeemeisen

Ondersteunt Windows
Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP
Ondersteunt Linux
Ja
Ondersteunt Mac-besturingssysteem
Ja
Ondersteunde server operating systems
Windows 2000 Server

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-10 - 80 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 85 procent
Luchtvochtigheid bij opslag
5 - 90 procent

Gewicht en omvang

Breedte
75 mm
Diepte
243 mm
Hoogte
26 mm
Gewicht
505,4 g

Verpakking

Breedte verpakking
230 mm
Diepte verpakking
180 mm
Verpakkingsvolume
2691 cm³
Gewicht verpakking
1,33 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176200
Code UK-handelstarief
84718000
Land van herkomst
China

Overige specificaties

Aantal poorten
8
