Fractal Design Meshify 2 Tower Zwart

Fractal Design Meshify 2, Tower, PC, Zwart, ATX, EATX, micro ATX, Mini-ITX, Staal, Gamen

Ruim op voorraad

Fabrikant Fractal Design
MPN FD-C-MES2A-01
EAN 7340172702429
€ 175,00 excl. BTW

Fractal Design Meshify 2 Tower Zwart

The new Meshify 2 is a classic evolved with focus on distinctive design, spacious interior and rugged good looks.

Detachable front filter
- New front nylon filter that can be removed for increased airflow
- New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts
- Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans

Superlative storage
- Convert to Storage Layout and install up to 11 HDDs alongside four dedicated SSDs mounts (6x SSD/HDD trays, 2x SSD brackets and 1x Multibracket included)
- Transformable interior design utilizing a movable wall for enhancing custom builds
- The included Multibracket lets you convert any unused fan position to an HDD, SSD or pump mount
- Tool-less, top-latching side panels allow quick access while preventing accidental drops

Extremely flexible
- Fits your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout
- Support for radiators up to 360 mm (front), 420 mm (top) and 280 mm (base)
- Easily holds large motherboards up to and including 285 mm E-ATX

Open and interchangeable
Remove the entire top to build and route with zero hindrance.

Type-C Interface
USB 3.1 Gen 2 Type-C front I/O offers fast-charging and speeds up to 10 Gbps

Nexus+ 2 fan hub
Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans

Versatile Multibracket
Versatile Multibracket that converts any unused fan position to an HDD, SSD or pump mount

Cable management
Detachable PSU cable shield and integrated cable guides with velcro straps further simplify cable management behind the board
  • Iconic angular mesh design provides filtered airflow with a bold, stealth-inspired aesthetic
  • Spacious adaptable interior for motherboards up to (and including) 285 mm E-ATX
  • Support for radiators up to 360 mm (front), 420 mm (top) and 280 mm (base)

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Design

Materiaal
Staal
Vormfactor*
Tower
Soort*
PC
Kleur van het product*
Zwart
Supported motherboard form factors*
ATX, EATX, micro ATX, Mini-ITX
Aantal 3.5" bays*
6
Aantal 2.5" bays
2
Aantal uitbreidingssleuven
9
Aantal storage drives ondersteund
23
Zijraam
Nee
Geschikt voor
Gamen
Anti-stof filter
Ja
Verbeterd kabelbeheer
Ja
Reset button
Ja
Aan-/uitknop
Ja
Maximum CPU cooler hoogte
18,5 cm
Maximum grafische kaart lengte
31,5 cm
Maximum PSU lengte
25 cm

Power voorraad

Vermogenstoevoer inclusief*
Nee
Ondersteunde vormfactoren stroomvoorziening
ATX

Poorten & interfaces

Audio-ingangen
Ja
Audio-uitgang
Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A*
2
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C*
1

Koeling

Aantal geïntstalleerde ventilators voorkant
2x 140 mm

Koeling

Maximale aantal ventilators voorkant
3
Voorste ventilators ondersteunende diameters
120,140 mm
Geïnstalleerde ventilators achterkant
1x 140 mm
Maximaal aantal ventilators achterkant
1
Achterkant ventilators ondersteunende diameters
120,140 mm
Maximaal aantal ventilators bovenkant
3
Bovenste ventilators ondersteunende diameters
120,140 mm
Maximaal aantal ventilators onderkant
2
Ondersterste ventilators ondersteunende diameters
120,140 mm
Ondersteunde afmetingen voorste radiator
280,360 mm
Ondersteunde afmetingen achterste radiator
120 mm
Ondersteunde afmetingen bovenste radiator
360,420 mm

Opslagmedia

HDD/SSD-combimodel
Ja
Maximum aantal HDD's per behuizing
18

Gewicht en omvang

Breedte
240 mm
Diepte
542 mm
Hoogte
474 mm
Gewicht
10,1 kg

Verpakking

Breedte verpakking
542 mm
Diepte verpakking
634 mm
Hoogte verpakking
324 mm
Gewicht verpakking
12,8 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84733080
