Fujitsu 2x1Gbit Cu Intel I350-T2, Intern, Bedraad, PCI Express, Ethernet, 1000 Mbit/s

Ruim op voorraad

Fabrikant Fujitsu
MPN S26361-F4610-L502
EAN 4053026551786

Fujitsu 2x1Gbit Cu Intel I350-T2 Intern Ethernet 1000 Mbit/s

PLAN CP 2x1Gbit Cu Intel ® I350-T2

Trust the network communication of the new Ethernet LAN adapter. The new Intel® I350-T2 Ethernet LAN Adapter, based on the latest Intel® 1GbE chip technology, offers two Gigabit Ethernet ports for 10/100/1000BaseT.

Virtualization support and Wake-on-LAN with selectable port are just some of the features from which you will benefit. Optimal support for your virtualization is provided by the support for Virtual Machine Device Queues (VMDq), Single Root I/O virtualization and sharing specification (SR-IOV). SR-IOV requires corresponding support in the
system BIOS and in the operating system. PCI-SIG SR-IOV defines extensions of the PCI Express (PCIe) specification and enables PCI hardware resources to be shared with several system images or Virtual
Machines.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Connectiviteitstechnologie*
Bedraad
Hostinterface*
PCI Express
Interface*
Ethernet
Aantal Ethernet LAN (RJ-45)-poorten
2
PCI versie
2.1

Netwerk

Maximale overdrachtssnelheid van gegevens*
1000 Mbit/s
Netwerkstandaard*
IEEE 802.1as, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Ethernet LAN
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Bekabelingstechnologie
10/100/1000BaseT(X)
Wake-on-LAN
Ja
Jumbo Frames ondersteuning
Ja
Ondersteunde netwerkprotocollen
iSCSI
LAN controller
Intel® I350

Design

Component voor*
Server
Intern*
Ja
Chipset
Intel® I350-AM2
LED-indicatoren
Ja

Energie

Stroomverbruik (typisch)
4,4 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 55 °C
Temperatuur bij opslag
-40 - 70 °C

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990

Overige specificaties

Datastroombeheer
Ja
