Hewlett Packard Enterprise ANT-3x3-5712 antenne Omnidirectionele antenne N-type 11,5 dBi

Hewlett Packard Enterprise ANT-3x3-5712, 11,5 dBi, 4.9-6.0 GHz, 50 Ohm, 70°, 25°, Omnidirectionele antenne

Niet op voorraad

Fabrikant HP
MPN JW033A
EAN 5415247153719
€ 408,00 excl. BTW

Hewlett Packard Enterprise ANT-3x3-5712 antenne Omnidirectionele antenne N-type 11,5 dBi

ANT-3x3-5712 is a multipolarized antenna with 70° horizontal and 25° vertical beamwidths. This antenna is ideally suited for 5-GHz point- to-multipoint mesh connections.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Prestatie

Frequentieband*
4.9-6.0 GHz
Impedantie
50 Ohm
H-plane (3 dB straalbreedte)
70°
E-plane (3 dB straalbreedte)
25°
Antenne versterkingsniveau (max)*
11,5 dBi

Kenmerken

Soort antenne*
Omnidirectionele antenne
Aansluiting antenne*
N-type
Geslacht connector
Vrouwelijk
Polarisatie
Dubbele polarisatie
Voltage Standing Wave Ratio (VSWR)
2:1
Materiaal behuizing
Aluminium, Kunststof
Kleur van het product
Wit

Energie

Vermogensverbruik (max)
6 W

Gewicht en omvang

Breedte
190 mm
Diepte
190 mm
Hoogte
30 mm
Gewicht
1 kg

Inhoud van de verpakking

Montage gereedschap
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85177100
