HUAWEI eKit S600 Series S620-24T16X8Y2CZ Managed L3 Gigabit Ethernet (10/100/1000) 1U Grijs

HUAWEI eKit S600 Series S620-24T16X8Y2CZ, Managed, L3, Gigabit Ethernet (10/100/1000), Rack-montage, 1U

Nog 2 beschikbaar (bel voor reservering)

Fabrikant Huawei
MPN 98012536
EAN 6901443457441
€ 991,00 excl. BTW

HUAWEI eKit S600 Series S620-24T16X8Y2CZ Managed L3 Gigabit Ethernet (10/100/1000) 1U Grijs

Huawei S620-24T16X8Y2CZ

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L3
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja
Cloud-beheerd
Ja
Traffic shaping
Ja
ARP-inspectie
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF
8
Aantal moduleslots SPF+
16
Aantal QSFP28-poorten
2

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
10G support*
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Spanning tree protocol
Ja
Head-of-line (HOL) blocking
Ja
VLAN=ondersteuning
Ja
Aantal VLANs
4000

Data-uitwisseling

Switchingcapaciteit*
1168 Gbit/s
Verzending snelheid
867 Mpps
MAC-adrestabel*
64000 entries

Beveiliging

Access Control List (ACL)
Ja
IGMP snooping
Ja
Ondersteunde beveiligingsalgoritmen
SNMP, SNMPv2, SNMPv3
SSH/SSL support
Ja
Bescherming lus
Ja

Beveiliging

Authenticatie
MAC-gebaseerde authenticatie, Poortgebaseerde authenticatie
Authenticatie type
HWTACACS, Network Access Control (NAC), RADIUS

Multicast-functies

Multicast-ondersteuning
Ja

Protocollen

Beheerprotocollen
SNMPv1/v2/v3
Ondersteunde netwerkprotocollen
RIP, OSPF, IS-IS, BGP,RIPng, OSPFv3, IS-ISv6, BGP4+

Design

Rack-montage*
Ja
Vormfactor
1U
Kleur van het product
Grijs
LED-indicatoren
Ja

Energie

Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50/60 Hz
DC voltage input
48 - 60 V
Stroomverbruik (typisch)
122 W
Vermogensverbruik (max)
127 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-5 - 45 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Luchtvochtigheid bij opslag
5 - 95 procent

Gewicht en omvang

Breedte
442 mm
Diepte
420 mm
Hoogte
43,6 mm
Gewicht
6,31 kg

Inhoud van de verpakking

Gebruikershandleiding
Ja
