Productinformatie
Met Intel® Turbo Boost Technologie wordt de processorfrequentie indien nodig dynamisch verhoogd door te profiteren van thermische en energiemarges. Hierdoor beschikt u over extra snelheid wanneer dit nodig is en bespaart u stroom wanneer u minder snelheid nodig hebt. Intel® vPro? technologie is een set beveiligings- en beheerfuncties die zijn ingebouwd in de processor en die zijn gericht op de vier belangrijkste gebieden van IT-beveiliging: 1) bedreigingsmanagement, inclusief beveiliging uit rootkits, virussen en malware 2) Identeitbescherming en beveiliging van het website access point 3) Beveiliging van vertrouwelijke persoonlijke en zakelijke gegevens 4) Externe en lokale bewaking, remediatie en reparatie van PC's en werkstations. Intel® Virtualization Technology for Directed I/O (VT-d) bouwt voort op de bestaande ondersteuning voor virtualisatie met IA-32 (VT-x) en de Itanium® processor (VT-i), en voegt nieuwe ondersteuning toe voor I/O-apparaatvirtualisatie. Intel VT-d kan eindgebruikers helpen om de beveiliging en betrouwbaarheid van de systemen te verbeteren en kan betere prestaties van I/O-apparaten in een gevirtualiseerde omgeving opleveren.
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Processor
Aantal processorkernen | 4 |
---|---|
Processorfamilie | Intel® Xeon® E3 v6 |
Processor socket | LGA 1151 (Socket H4) |
Component voor | Server/workstation |
Box | Ja |
Processormodel | E3-1230 v6 |
Processor aantal threads | 8 |
Systeembus | 8 GT/s |
Processor operating modes | 64-bit |
Bus type | DMI3 |
Stepping | B0 |
Frequentie van processor | 3.5 GHz |
Processor lithografie | 14 nm |
Maximale turbofrequentie van processor | 3,9 GHz |
Codenaam processor | Kaby Lake |
Processor cache | 8 MB |
Processor cache type | Smart Cache |
Inclusief koeler | Ja |
Processorfabrikant | Intel |
Basisfrequentie processor | 3,5 GHz |
Component voor | Server/werkplaats |
Geheugen
Ondersteunde geheugen types | DDR4-SDRAM, DDR3L-SDRAM |
---|---|
ECC | Ja |
Geheugen kanaal | Dual-channel |
Maximaal intern geheugen ondersteund door processor | 64 GB |
Geheugentypen ondersteund door processor | DDR4-SDRAM, DDR3L-SDRAM |
Klokgeheugen-snelheden ondersteund door processor | 1866,2400 MHz |
Geheugenbandbreedte ondersteund door de processor ( max) | 37,5 GB/s |
Geheugenkanalen ondersteund door processor | Dual |
ECC ondersteund door processor | Ja |
Grafisch
4K-ondersteuning | Nee |
---|---|
Ingebouwde grafische adapter | Nee |
Ingebouwde grafische adapter | Nee |
Energie
VID Voltage Range | 0,55 - 1,52 V |
---|
Kenmerken
Idle States | Ja |
---|---|
Execute Disable Bit | Ja |
Thermal Monitoring Technologies | Ja |
PCI Express slots versie | 3.0 |
PCI Express configuraties | 1x16, 2x8, 1x8+2x4 |
Ondersteunde instructie sets | SSE4.1, SSE4.2, AVX 2.0 |
Ingebouwde opties beschikbaar | Nee |
Schaalbaarheid | 1S |
Thermal Design Power (TDP) | 72 W |
Maximaal aantal PCI Express-lijnen | 16 |
Verpakkingsgrootte processor | 37.5 x 37.5 mm |
ARK ID processor | 97474 |
Code geharmoniseerd systeem (HS) | 85423119 |
PCI Express CEM revisie | 3.0 |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | G077159 |
Verpakking
Type verpakking | Retaildoos |
---|
Processor speciale functies
Intel® Trusted Execution Technology | Ja |
---|---|
Enhanced Intel SpeedStep Technology | Ja |
Intel® Secure Key | Ja |
Intel® TSX-NI | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® Enhanced Halt State | Ja |
Intel® 64 | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® Clear Video-technologie | Nee |
Intel® Virtualization Technology (VT-x) | Ja |
Versie Intel® Secure Key Technology | 1,00 |
Versie Intel® TSX-NI | 1,00 |
Intel® Software Guard Extensions (Intel® SGX) | Ja |
Conflictvrije processor | Ja |
Intel® AES New Instructions (Intel® AES-NI) | Ja |
Intel® Hyper Threading Technology (Intel® HT Technology) | Ja |
Intel® vPro™ Technology | Ja |
Intel® Clear Video HD Technology (Intel® CVT HD) | Nee |
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID) | Nee |
Intel® OS Guard | Ja |
Intel® Quick Sync Video Technology | Nee |
Intel® Turbo Boost Technology | 2.0 |
Intel® InTru™ 3D Technology | Nee |
Intel® Optane™ Memory Ready | Ja |
Intel® Memory Protection Extensions (Intel® MPX) | Ja |
Intel® Boot Guard | Ja |
Intel® vPro™ Platform Eligibility | Ja |
Conflictvrije processor | Ja |
Intel® InTru? 3D Technology | Nee |
Intel® Optane? Memory Ready | Ja |
Intel® vPro? Platform Eligibility | Ja |
Intel® Turbo Boost Technology 2.0 frequency | 3,9 GHz |
Intel® Transactional Synchronization Extensions | Ja |
Gewicht en omvang
Breedte verpakking | 70 mm |
---|---|
Diepte verpakking | 116 mm |
Hoogte verpakking | 101 mm |
Overige specificaties
Maximum intern geheugen | 64 GB |
---|---|
Maximaal intern geheugen | 65536 MB |
CPU configuratie (max) | 1 |
Grafische uitvoer | N/A |
Technische details
Processorcache | 8192 KB |
---|---|
Producttype | Processor |
Maximaal geheugen | 64 GB |
Maximale resolutie & verversingsfrequentie (VGA) | N/A |
Status van bestelling | Launched |
Type buseenheden | GT/s |
Bandbreedte bus | 8 |
Maximale resolutie & verversingsfrequentie (Integrated Flat Panel) | N/A |
Maximale resolutie & verversingsfrequentie (HDMI) | N/A |
Merknaam processor | Intel Xeon |
Lanceringsdatum | Q1'17 |
Marktsegment | Server |
Maximale resolutie & verversingsfrequentie (DisplayPort) | N/A |
Productfamilie | Intel Xeon Processors |
Laatste wijziging | 63903513 |
Bussnelheid | 8 GT/s |
