Intel Core i7-9700K processor 3,6 GHz 12 MB Smart Cache Box

Intel Core i7-9700K, Intel® Core™ i7, LGA 1151 (Socket H4), 14 nm, Intel, i7-9700K, 3,6 GHz

Niet op voorraad

Fabrikant Intel
MPN BX80684I79700K
EAN 5032037141642
€ 365,00 excl. BTW

Intel Core i7-9700K processor 3,6 GHz 12 MB Smart Cache Box

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

Intel® vPro™ Platform Eligibility
Intel® vPro™ Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel® 9de generatie Core™ i7
Processormodel*
i7-9700K
Basisfrequentie processor*
3,6 GHz
Processorfamilie*
Intel® Core™ i7
Aantal processorkernen*
8
Processor socket*
LGA 1151 (Socket H4)
Component voor
PC
Processor lithografie*
14 nm
Processor aantal threads
8
Systeembus
8 GT/s
Processor operating modes*
64-bit
Maximale turbofrequentie van processor
4,9 GHz
Processor cache
12 MB
Processor cache type
Smart Cache
Thermal Design Power (TDP)
95 W
Box*
Ja
Inclusief koeler*
Nee
Generatie
9th Generation
Stepping
P0
Bus type
DMI3
Geheugenbandbreedte ondersteund door de processor ( max)
41,6 GB/s
Codenaam processor
Coffee Lake
Processorcode
SRELT
ARK ID processor
186604

Geheugen

Maximaal intern geheugen ondersteund door processor
64 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor
2666 MHz
Geheugen kanaal*
Dubbelkanaals
ECC
Nee

Grafisch

Ingebouwde grafische adapter*
Ja
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Intel® UHD Graphics 630
Maximaal geheugen ingebouwde grafische adapter
64 GB
On-board ondersteunde grafische adapter uitgangen
DisplayPort, Embedded DisplayPort (eDP), HDMI
Basisfrequentie ingebouwde grafische adapter
350 MHz
Graphics on-board -adapter dynamische frequentie (max)
1200 MHz
Aantal displays ondersteund (door on-board grafische adapter)
3
4K-ondersteuning
Ja
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
4096 x 2304 Pixels
Maximale resolutie (eDP - Integrated Flat Panel)
4096 x 2304 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2304 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
60 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
24 Hz
On-board grafische adapter ID
0x3E98

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Desktop
Maximaal aantal PCI Express-lijnen
16
PCI Express slots versie
3.0
PCI Express configuraties
1x16, 2x8, 1x8+2x4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0
Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Nee
Thermal solution specificatie
PCG 2015D
PCI Express CEM revisie
3.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Nee
Intel® Identity Protection Technology (Intel® IPT)
Ja
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Ja
Intel® InTru™ 3D Technology
Ja
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Trusted Execution Technology
Ja
Intel® Memory Protection Extensions (Intel® MPX)
Ja
Intel® Turbo Boost Technology 2.0 frequency
4,9 GHz
Intel® Transactional Synchronization Extensions
Ja
Intel® Enhanced Halt State
Ja
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID)
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® TSX-NI
Ja
Intel® Stable Image Platform Program (SIPP)
Ja
Intel® OS Guard
Ja
Intel® Clear Video-technologie
Ja
Intel® Software Guard Extensions (Intel® SGX)
Ja
Intel® 64
Ja
Versie Intel® Identity Protection Technology
1,00
Versie Intel® Secure Key Technology
1,00
Versie Intel® Stable Image Platform Program (SIPP)
1,00
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Versie Intel® TSX-NI
1,00
Intel® Optane™ Memory Ready
Ja
Intel® Boot Guard
Ja
Intel® vPro™ Platform Eligibility
Ja

Eisen aan de omgeving

Tjunction
100 °C

Technische details

Bandbreedte bus
8
Type buseenheden
GT/s
Lanceringsdatum
Q4'18
Maximale resolutie & verversingsfrequentie (DisplayPort)
4096 x 2304@60Hz
Maximale resolutie & verversingsfrequentie (HDMI)
4096x2304@24Hz
Maximale resolutie & verversingsfrequentie (Integrated Flat Panel)
4096x2304@60Hz
Processorcache
12288 KB
Type product
Processor
Status
Launched
Maximaal geheugen
128 GB
Merknaam processor
9th Gen Intel Core i7 9th Gen Intel Core i7 Processor
Ondersteunde geheugen types
DDR4-SDRAM
Laatste wijziging
63903513
Productfamilie
Intel Core Processors
Bussnelheid
8 GT/s
Maximaal geheugen grafische adapter
64 GB
Processor-id
0x3E98

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85423119

Verpakking

Breedte verpakking
44 mm
Diepte verpakking
116 mm
Hoogte verpakking
101 mm
Gewicht verpakking
87 g
Type verpakking
Retaildoos

Gewicht en omvang

Verpakkingsgrootte processor
37.5 x 37.5 mm

Overige specificaties

Maximum intern geheugen
128 GB
Maximaal intern geheugen
65536 MB
