Intel Core i5-13500 processor 24 MB Smart Cache Box

Intel Core i5-13500, Intel® Core™ i5, LGA 1700, Intel, i5-13500, 64-bit, Intel® 13de generatie Core™ i5

Ruim op voorraad

Fabrikant Intel
MPN BX8071513500
EAN 5032037260251
€ 202,00 excl. BTW

Intel Core i5-13500 processor 24 MB Smart Cache Box

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel® 13de generatie Core™ i5
Processormodel*
i5-13500
Processorfamilie*
Intel® Core™ i5
Aantal processorkernen*
14
Processor socket*
LGA 1700
Processor aantal threads
20
Processor operating modes*
64-bit
Prestatiekernen
6
Efficiënte kernen
8
Maximale turbofrequentie van processor
4,8 GHz
Prestatie-kernboostfrequentie
4,8 GHz
Prestatie-kernbasisfrequentie
2,5 GHz
Efficiënte kernboostfrequentie
3,5 GHz
Efficiënte kernbasisfrequentie
1,8 GHz
Processor cache
24 MB
Processor cache type
Smart Cache
Box*
Ja
Processor basisvermogen
65 W
Maximaal turbovermogen
154 W
Bus type
DMI4
Maximum aantal DMI lanes
8
Geheugenbandbreedte ondersteund door de processor ( max)
76,8 GB/s
Codenaam processor
Raptor Lake
ARK ID processor
230580

Geheugen

Maximaal intern geheugen ondersteund door processor
128 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM, DDR5-SDRAM
Geheugen kanaal*
Dubbelkanaals
ECC
Ja
Geheugen bandbreedte (max)
76,8 GB/s

Grafisch

Ingebouwde grafische adapter*
Ja
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Intel UHD Graphics 770
On-board ondersteunde grafische adapter uitgangen
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Basisfrequentie ingebouwde grafische adapter
300 MHz
Graphics on-board -adapter dynamische frequentie (max)
1550 MHz
Aantal displays ondersteund (door on-board grafische adapter)
4
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
7680 x 4320 Pixels
Maximale resolutie (eDP - Integrated Flat Panel)
5120 x 3200 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2160 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
120 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
60 Hz
On-board grafische adapter ID
0x4680
Discreet grafische adapter model*
Niet beschikbaar
Aantal verwerkingseenheden
32
Multi-Formaat Codec-motoren
2

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Desktop
Gebruiksvoorwaarden
PC/Client/Tablet, Workstation
Maximaal aantal PCI Express-lijnen
20
PCI Express slots versie
5.0, 4.0
PCI Express configuraties
1x16+1x4, 2x8+1x4

Kenmerken

Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0
Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Ja
Directe media-interface (DMI) revisie
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Ja
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Trusted Execution Technology
Ja
Intel® Speed Shift-technologie
Ja
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Ja
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Thread Director
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® Active Management Technology (Intel® AMT)
Ja
Intel® Stable Image Platform Program (SIPP)
Ja
Intel® OS Guard
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Turbo Boost Max Technology 3.0
Nee
Intel® Boot Guard
Ja
Intel® Deep Learning Boost (Intel® DL Boost)
Ja
Intel® Volume Management Device (VMD)
Ja
Mode-based Execute Control (MBE)
Ja
Intel® vPro™ Platform Eligibility
Ja
Intel® Standard Manageability (ISM, Standaard beheerbaarheid)
Ja
Intel® One-Click Recovery (Herstel met 1 klik)
Ja
Intel® Remote Platform Erase (RPE)
Ja
Intel® virtualisatietechnologie met omleidingsbescherming (VT-rp)
Ja
Intel vPro® Enterprise-platformvoorwaarden
Ja
Intel®-technologie voor dreigingsdetectie (TDT)
Ja
Intel® Hardware Shield-voorwaarden
Ja
Intel® totale geheugencodering - Meerdere sleutels
Ja
Intel vPro® Essentials-platformvoorwaarden
Ja

Eisen aan de omgeving

Tjunction
100 °C

Technische details

Doelgroep
Gaming
OpenCL-versie
3.0
Lanceringsdatum
Q1'23
Status
Launched

Logistieke gegevens

Code geharmoniseerd systeem (HS)
8542310001

Verpakking

Type verpakking
Retaildoos

Gewicht en omvang

Verpakkingsgrootte processor
45 x 37.5 mm

Overige specificaties

L2 cache
11776 KB
Maximum intern geheugen
128 GB
Grafische uitvoer
eDP 1.4b, DP 1.4a, HDMI 2.1
