Intel Core i7-13700F processor 30 MB Smart Cache Box

Intel Core i7-13700F, Intel® Core™ i7, LGA 1700, Intel, i7-13700F, 64-bit, Intel® 13de generatie Core™ i7

Ruim op voorraad

Fabrikant Intel
MPN BX8071513700F
EAN 5032037260237
€ 388,00 excl. BTW

Intel Core i7-13700F processor 30 MB Smart Cache Box

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel® 13de generatie Core™ i7
Processormodel*
i7-13700F
Processorfamilie*
Intel® Core™ i7
Aantal processorkernen*
16
Processor socket*
LGA 1700
Processor aantal threads
24
Processor operating modes*
64-bit
Prestatiekernen
8
Efficiënte kernen
8
Maximale turbofrequentie van processor
5,2 GHz
Prestatie-kernboostfrequentie
5,1 GHz
Prestatie-kernbasisfrequentie
2,1 GHz
Efficiënte kernboostfrequentie
4,1 GHz
Efficiënte kernbasisfrequentie
1,5 GHz
Processor cache
30 MB
Processor cache type
Smart Cache
Box*
Ja
Processor basisvermogen
65 W
Maximaal turbovermogen
219 W
Bus type
DMI4
Maximum aantal DMI lanes
8
Geheugenbandbreedte ondersteund door de processor ( max)
89,6 GB/s
Codenaam processor
Raptor Lake
ARK ID processor
230491

Geheugen

Maximaal intern geheugen ondersteund door processor
128 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM, DDR5-SDRAM
Geheugen kanaal*
Dubbelkanaals
Geheugen bandbreedte (max)
89,6 GB/s

Grafisch

Ingebouwde grafische adapter*
Nee
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Niet beschikbaar
Discreet grafische adapter model*
Niet beschikbaar

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Desktop
Gebruiksvoorwaarden
PC/Client/Tablet
Maximaal aantal PCI Express-lijnen
20
PCI Express slots versie
5.0, 4.0
PCI Express configuraties
1x16+1x4, 2x8+1x4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0

Kenmerken

Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Nee
Directe media-interface (DMI) revisie
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Speed Shift-technologie
Ja
Intel® Turbo Boost Max Technology 3.0 frequency
5,2 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Ja
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Thread Director
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® OS Guard
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Turbo Boost Max Technology 3.0
Ja
Intel® Boot Guard
Ja
Intel® Deep Learning Boost (Intel® DL Boost)
Ja
Intel® Volume Management Device (VMD)
Ja
Mode-based Execute Control (MBE)
Ja
Intel® Standard Manageability (ISM, Standaard beheerbaarheid)
Ja

Eisen aan de omgeving

Tjunction
100 °C

Logistieke gegevens

Code geharmoniseerd systeem (HS)
8542310001

Verpakking

Type verpakking
Retaildoos

Technische details

Doelgroep
Gaming, Content Creation
Lanceringsdatum
Q1'23
Status
Launched

Gewicht en omvang

Verpakkingsgrootte processor
45 x 37.5 mm

Overige specificaties

L2 cache
24576 KB
Maximum intern geheugen
128 GB
