Intel Xeon E-2186G processor 3,8 GHz 12 MB Smart Cache

Intel Xeon E-2186G, Intel Xeon E, LGA 1151 (Socket H4), 14 nm, Intel, E-2186G, 3,8 GHz

Nog 1 beschikbaar (bel voor reservering)

Fabrikant Intel
MPN CM8068403379918
EAN 8592978121716
€ 693,00 excl. BTW

Intel Xeon E-2186G processor 3,8 GHz 12 MB Smart Cache

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® vPro™ Platform Eligibility
Intel® vPro™ Technology is a set of security and manageability capabilities built into the processor aimed at addressing four critical areas of IT security: 1) Threat management, including protection from rootkits, viruses, and malware 2) Identity and web site access point protection 3) Confidential personal and business data protection 4) Remote and local monitoring, remediation, and repair of PCs and workstations.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processormodel*
E-2186G
Basisfrequentie processor*
3,8 GHz
Processorfamilie*
Intel Xeon E
Aantal processorkernen*
6
Processor socket*
LGA 1151 (Socket H4)
Component voor
Server/werkplaats
Processor lithografie*
14 nm
Processor aantal threads
12
Systeembus
8 GT/s
Processor operating modes*
64-bit
Maximale turbofrequentie van processor
4,7 GHz
Processor cache
12 MB
Processor cache type
Smart Cache
Thermal Design Power (TDP)
95 W
Box*
Nee
Inclusief koeler*
Nee
Stepping
U0
Bus type
DMI3
Geheugenbandbreedte ondersteund door de processor ( max)
41,6 GB/s
Codenaam processor
Coffee Lake
Processorcode
SR3WR
ARK ID processor
134855

Geheugen

Maximaal intern geheugen ondersteund door processor
128 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor
2666 MHz
Geheugen kanaal*
Dubbelkanaals
ECC
Ja

Grafisch

Ingebouwde grafische adapter*
Ja
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Intel UHD Graphics P630
Maximaal geheugen ingebouwde grafische adapter
128 GB
On-board ondersteunde grafische adapter uitgangen
Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI
Basisfrequentie ingebouwde grafische adapter
350 MHz
Graphics on-board -adapter dynamische frequentie (max)
1200 MHz
Aantal displays ondersteund (door on-board grafische adapter)
3
4K-ondersteuning
Ja
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
4096 x 2304 Pixels
Maximale resolutie (eDP - Integrated Flat Panel)
4096 x 2304 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2160 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
60 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
24 Hz
On-board grafische adapter ID
0x3E96
Discreet grafische adapter model*
Niet beschikbaar

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Server
Maximaal aantal PCI Express-lijnen
16
PCI Express slots versie
3.0
PCI Express configuraties
1x16, 2x8, 1x8+2x4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0
Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Nee
PCI Express CEM revisie
3.0

Kenmerken

Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
G077159

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Ja
Intel® InTru™ 3D Technology
Ja
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Trusted Execution Technology
Ja
Intel® Memory Protection Extensions (Intel® MPX)
Ja
Intel® Turbo Boost Technology 2.0 frequency
4,7 GHz
Intel® Transactional Synchronization Extensions
Ja
Intel® Enhanced Halt State
Ja
Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID)
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® TSX-NI
Ja
Intel® OS Guard
Ja
Intel® Clear Video-technologie
Ja
Intel® Software Guard Extensions (Intel® SGX)
Ja
Intel® 64
Ja
Versie Intel® Secure Key Technology
1,00
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Versie Intel® TSX-NI
1,00
Intel® Optane™ Memory Ready
Ja
Intel® Boot Guard
Ja
Intel® vPro™ Platform Eligibility
Ja

Eisen aan de omgeving

Tjunction
100 °C

Technische details

Bandbreedte bus
8
Type buseenheden
GT/s
Lanceringsdatum
Q3'18
Maximale resolutie & verversingsfrequentie (DisplayPort)
4096x2304@60Hz
Maximale resolutie & verversingsfrequentie (HDMI)
4096x2160@24Hz
Maximale resolutie & verversingsfrequentie (Integrated Flat Panel)
4096x2304@60Hz
Maximale resolutie & verversingsfrequentie (VGA)
N/A
Processorcache
12288 KB
Type product
Processor
Status
Launched
Maximaal geheugen
128 GB
Merknaam processor
Intel Xeon
Ondersteunde geheugen types
DDR4-SDRAM
Laatste wijziging
63903513
Productfamilie
Intel Xeon Processors
Bussnelheid
8 GT/s
Maximaal geheugen grafische adapter
128 GB
Processor-id
0x3E96
Onderhoudsstatus
Baseline Servicing

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85423119

Gewicht en omvang

Verpakkingsgrootte processor
37.5 x 37.5 mm

Overige specificaties

Maximum intern geheugen
128 GB
Maximaal intern geheugen
65536 MB
Grafische uitvoer
eDP/DP/HDMI/DVI
Videodecodering
Ja
