Intel Core i7-13700 processor 30 MB Smart Cache

Intel Core i7-13700, Intel® Core™ i7, LGA 1700, Intel, i7-13700, 64-bit, Intel® 13de generatie Core™ i7

Ruim op voorraad

Fabrikant Intel
MPN CM8071504820805
EAN 8592978422417
€ 309,00 excl. BTW

Intel Core i7-13700 processor 30 MB Smart Cache

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel® 13de generatie Core™ i7
Processormodel*
i7-13700
Processorfamilie*
Intel® Core™ i7
Aantal processorkernen*
16
Processor socket*
LGA 1700
Processor aantal threads
24
Processor operating modes*
64-bit
Prestatiekernen
8
Efficiënte kernen
8
Maximale turbofrequentie van processor
5,2 GHz
Prestatie-kernboostfrequentie
5,1 GHz
Prestatie-kernbasisfrequentie
2,1 GHz
Efficiënte kernboostfrequentie
4,1 GHz
Efficiënte kernbasisfrequentie
1,5 GHz
Processor cache
30 MB
Processor cache type
Smart Cache
Box*
Nee
Processor basisvermogen
65 W
Maximaal turbovermogen
219 W
Bus type
DMI4
Maximum aantal DMI lanes
8
Geheugenbandbreedte ondersteund door de processor ( max)
89,6 GB/s
Codenaam processor
Raptor Lake
ARK ID processor
230490

Geheugen

Maximaal intern geheugen ondersteund door processor
128 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM, DDR5-SDRAM
Geheugen kanaal*
Dubbelkanaals
ECC
Ja
Geheugen bandbreedte (max)
89,6 GB/s

Grafisch

Ingebouwde grafische adapter*
Ja
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Intel UHD Graphics 770
On-board ondersteunde grafische adapter uitgangen
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
Basisfrequentie ingebouwde grafische adapter
300 MHz
Graphics on-board -adapter dynamische frequentie (max)
1600 MHz
Aantal displays ondersteund (door on-board grafische adapter)
4
On-board grafische adapter DirectX-versie
12.0
On-board grafische adapter OpenGL versie
4.5
Graphics aan boord maximale resolutie adapter (DisplayPort )
7680 x 4320 Pixels
Maximale resolutie (eDP - Integrated Flat Panel)
5120 x 3200 Pixels
Maximale resolutie ingebouwde grafische adapter (HDMI)
4096 x 2160 Pixels
Grafische adapter refresh rate on-board bij maximale resolutie (DisplayPort )
60 Hz
Refresh rate op maximale resolutie (eDP - Integrated Flat Panel)
120 Hz
Verversingsfrequentie ingebouwde grafische adapter bij maximale resolutie (HDMI)
60 Hz
On-board grafische adapter ID
0xA780
Discreet grafische adapter model*
Niet beschikbaar
Aantal verwerkingseenheden
32
Multi-Formaat Codec-motoren
2

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Desktop
Gebruiksvoorwaarden
PC/Client/Tablet, Workstation
Maximaal aantal PCI Express-lijnen
20
PCI Express slots versie
5.0, 4.0
PCI Express configuraties
1x16+1x4, 2x8+1x4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0

Kenmerken

Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Ja
Directe media-interface (DMI) revisie
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® Quick Sync Video Technology
Ja
Intel® Clear Video HD Technology (Intel® CVT HD)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Trusted Execution Technology
Ja
Intel® Speed Shift-technologie
Ja
Intel® Turbo Boost Max Technology 3.0 frequency
5,2 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Ja
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Thread Director
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® Active Management Technology (Intel® AMT)
Ja
Intel® Stable Image Platform Program (SIPP)
Ja
Intel® OS Guard
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Turbo Boost Max Technology 3.0
Ja
Intel® Boot Guard
Ja
Intel® Deep Learning Boost (Intel® DL Boost)
Ja
Intel® Volume Management Device (VMD)
Ja
Mode-based Execute Control (MBE)
Ja
Intel® vPro™ Platform Eligibility
Ja
Intel® Standard Manageability (ISM, Standaard beheerbaarheid)
Ja
Intel® One-Click Recovery (Herstel met 1 klik)
Ja
Intel® Remote Platform Erase (RPE)
Ja
Intel® virtualisatietechnologie met omleidingsbescherming (VT-rp)
Ja
Intel vPro® Enterprise-platformvoorwaarden
Ja
Intel®-technologie voor dreigingsdetectie (TDT)
Ja
Intel® Hardware Shield-voorwaarden
Ja
Intel® totale geheugencodering - Meerdere sleutels
Ja
Intel vPro® Essentials-platformvoorwaarden
Ja

Eisen aan de omgeving

Tjunction
100 °C

Technische details

Doelgroep
Gaming, Content Creation
OpenCL-versie
3.0
Lanceringsdatum
Q1'23
Status
Launched

Logistieke gegevens

Code geharmoniseerd systeem (HS)
8542310001

Verpakking

Type verpakking
Retaildoos

Gewicht en omvang

Verpakkingsgrootte processor
45 x 37.5 mm

Overige specificaties

L2 cache
24576 KB
Maximum intern geheugen
128 GB
Grafische uitvoer
eDP 1.4b, DP 1.4a, HDMI 2.1
