Intel Core i5-13400F, Intel® Core™ i5, LGA 1700, Intel, i5-13400F, 64-bit, Intel® 13de generatie Core™ i5

Ruim op voorraad

Fabrikant Intel
MPN CM8071505093012
EAN 8592978422424

Intel Core i5-13400F processor 20 MB Smart Cache

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Idle States
Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

Intel® Volume Management Device (VMD)
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorgeneratie
Intel® 13de generatie Core™ i5
Processormodel*
i5-13400F
Processorfamilie*
Intel® Core™ i5
Aantal processorkernen*
10
Processor socket*
LGA 1700
Processor aantal threads
16
Processor operating modes*
64-bit
Prestatiekernen
6
Efficiënte kernen
4
Maximale turbofrequentie van processor
4,6 GHz
Prestatie-kernboostfrequentie
4,6 GHz
Prestatie-kernbasisfrequentie
2,5 GHz
Efficiënte kernboostfrequentie
3,3 GHz
Efficiënte kernbasisfrequentie
1,8 GHz
Processor cache
20 MB
Processor cache type
Smart Cache
Box*
Nee
Processor basisvermogen
65 W
Maximaal turbovermogen
148 W
Bus type
DMI4
Maximum aantal DMI lanes
8
Geheugenbandbreedte ondersteund door de processor ( max)
76,8 GB/s
Codenaam processor
Raptor Lake
ARK ID processor
230501

Geheugen

Maximaal intern geheugen ondersteund door processor
192 GB
Geheugentypen ondersteund door processor
DDR4-SDRAM, DDR5-SDRAM
Geheugen kanaal*
Dubbelkanaals
Geheugen bandbreedte (max)
76,8 GB/s

Grafisch

Ingebouwde grafische adapter*
Nee
Aparte grafische adapter*
Nee
On-board graphics adapter model*
Niet beschikbaar
Discreet grafische adapter model*
Niet beschikbaar

Kenmerken

Execute Disable Bit
Ja
Idle States
Ja
Thermal Monitoring Technologies
Ja
Marktsegment
Desktop
Gebruiksvoorwaarden
PC/Client/Tablet
Maximaal aantal PCI Express-lijnen
20
PCI Express slots versie
5.0, 4.0

Kenmerken

PCI Express configuraties
1x16+1x4, 2x8+1x4
Ondersteunde instructie sets
SSE4.1, SSE4.2, AVX 2.0
Schaalbaarheid
1S
CPU configuratie (max)
1
Ingebouwde opties beschikbaar
Nee
Directe media-interface (DMI) revisie
4.0
Export Control Classification Number (ECCN)
5A992C
Commodity Classification Automated Tracking System (CCATS)
740.17B1

Processor speciale functies

Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Ja
Enhanced Intel SpeedStep Technology
Ja
Intel® Speed Shift-technologie
Ja
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
Ja
Intel® Control-flow Enforcement Technology (CET)
Ja
Intel® Thread Director
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® Secure Key
Ja
Intel® OS Guard
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Turbo Boost Max Technology 3.0
Nee
Intel® Boot Guard
Ja
Intel® Deep Learning Boost (Intel® DL Boost)
Ja
Intel® Volume Management Device (VMD)
Ja
Mode-based Execute Control (MBE)
Ja
Intel® Standard Manageability (ISM, Standaard beheerbaarheid)
Ja

Eisen aan de omgeving

Tjunction
100 °C

Logistieke gegevens

Code geharmoniseerd systeem (HS)
8542310001

Technische details

Doelgroep
Gaming
Lanceringsdatum
Q1'23
Status
Launched

Gewicht en omvang

Verpakkingsgrootte processor
45 x 37.5 mm

Overige specificaties

L2 cache
9728 KB
Maximum intern geheugen
192 GB
