Productinformatie
A 12-Gb eight internal port SAS 3.0 mezzanine card with dual core RAID-On-Chip (ROC), RAID levels 0,1,5,6, PCIe Generation 3, and an optional Maintenance Free Backup Unit.
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Ontwerp
Formaat | Storage Connector Module |
---|---|
Connector oriëntatie | Zijkant |
Poorten & interfaces
Hostinterface | PCI Express x8 |
---|---|
PCI Express slots versie | 3.0 |
Interne SAS-poorten | 8 |
PCI Card form factor | Full-height (low-profile) |
Ondersteunde opslagstationinterfaces | SAS, SATA |
Prestatie
Intern geheugen | 1024 MB |
---|---|
Intern geheugentype | DDR3 |
Kloksnelheid geheugen | 1866 MHz |
Type processor | SAS3108 |
Processorfamilie | LSI |
Sustained data transfer rate (native) | 12288 MB/s |
Number of devices supported | 128 |
Overdrachtssnelheid | 12 Gbit/s |
Compatibele batterij backup opties | AXXRMFBU5 |
RAID ARK ID | 82029 |
Compatibele producten | Intel Server System R1208WT2GS Intel Server System R1208WTTGS Intel Server System R1304WT2GS Intel Server System R1304WTTGS Intel Server System R2208WT2YS Intel Server System R2208WTTYC1 Intel Server System R2208WTTYS Intel Server System R2224WTTYS Intel |
Soorten RAID | 0, 1, 10, 5, 50, 6, 60 |
Code geharmoniseerd systeem (HS) | 84733080 |
Export Control Classification Number (ECCN) | 4A994B |
Commodity Classification Automated Tracking System (CCATS) | NA |
JBOD-functie | Nee |
Minimale systeemeisen
Ondersteunt Windows | Ja |
---|---|
Ondersteunt Linux | Ja |
Eisen aan de omgeving
Temperatuur, in bedrijf | 0 - 65 °C |
---|
Overige specificaties
Compatibele besturingssystemen | Windows, Linux, VMware |
---|---|
Ondersteunde apparaten | SAS/SATA |
Interne poorten | 8 |
Andere kenmerken | Support for Premium Feature Options |
Extra functies | Support for optional Maintenance Free Backup Unit and Premium Feature upgrade keys. |
Technische details
Overdrachtssnelheid | 12288 Mbit/s |
---|---|
Processormodel | LSISAS3108 |
Verpakkingsinhoud | (1) Intel Integrated RAID Module RMS3CC080, (4) standoffs, and (4) standoff locking pins |
Producttype | RAID |
Introductiedatum | Q3'14 |
Productnaam | Intel Integrated RAID Module RMS3CC080 |
Marktsegment | Server |
Lanceringsdatum | Q3'14 |
Status van bestelling | Launched |
RAID keying | SIOM |
Oriëntatie RAID-aansluiting | Side |
PCI Express host-interface | PCIe x8 Gen3 |
Datum verwachte stopzetting | Q2'23 |
Bijkopen verlengde garantie beschikbaar (selecteer landen) | Ja |
Doelgroep | Mainstream |
Laatste wijziging | 63903513 |
Laatste besteldatum | 2019-08-03 05:00:37 |
