Lenovo RackSwitch G7028, Managed, L2, Gigabit Ethernet (10/100/1000), Rack-montage, 1U

Niet op voorraad

Fabrikant Lenovo
MPN 7159C1X
EAN 0889488024094

Lenovo RackSwitch G7028 Managed L2 Gigabit Ethernet (10/100/1000) 1U Zwart

The Lenovo RackSwitch™ G7028 is an inexpensive, entry-level Layer 2 1/10 Gb Ethernet switch that is designed for the data center. Data center customers continue to deploy applications by using 1 GbE networking switches while 10 GbE continues to grow for customer solutions that require greater I/O bandwidth. The RackSwitch G7028 is an ideal solution for data center customers who need an economical 1 Gb and 10 Gb connectivity solution.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF+
4
Console port
RJ-45
Aantal USB 2.0-poorten
1
Netstekker
AC-in-aansluiting

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Ja
Port mirroring
Ja
Verbindingsaggregatie
Ja
Spanning tree protocol
Ja
VLAN=ondersteuning
Ja
Aantal VLANs
4095

Optische vezel

Fiber ethernet cabling technologie
10GBASE-LR, 10GBASE-SR

Data-uitwisseling

Throughput
128000 Mpps
MAC-adrestabel*
8000 entries

Beveiliging

Access Control List (ACL)
Ja
Ondersteunde beveiligingsalgoritmen
SSH

Multicast-functies

Multicast-ondersteuning
Ja

Protocollen

Beheerprotocollen
isCLI; SNMP v1/v3

Design

Rack-montage*
Ja
Vormfactor
1U
Kleur van het product
Zwart
LED-indicatoren
Ja
Aantal ventilatoren
3 ventilator(en)

Prestatie

Geluidsniveau
65 dB
Mean time between failures (MTBF)
128407 uur

Energie

Vermogenstoevoer inclusief*
Ja
Aantal voedingen
1
AC-ingangsspanning
100 - 240 V
Stroomverbruik (typisch)
90 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent

Gewicht en omvang

Breedte
440 mm
Diepte
382 mm
Hoogte
44 mm
Gewicht
5,3 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
