Lenovo X722 Intern Ethernet 1000 Mbit/s
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Poorten & interfaces
Connectiviteitstechnologie*
Bedraad
Hostinterface*
PCI Express
Interface*
Ethernet
Aantal Ethernet LAN (RJ-45)-poorten
4
Netwerk
Maximale overdrachtssnelheid van gegevens*
1000 Mbit/s
Netwerkstandaard*
IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Ondersteunde beveiligingsalgoritmen
SNMP
Jumbo Frames ondersteuning
Ja
Jumbo frames
9728
Quality of Service (QoS)
Ja
VLAN-tagging
Ja
Design
Kleur van het product
Groen
Intern*
Ja
Chipset
Intel® C624
Design
Certificering
UL recognized to UL60950-1 2nd Edition
FCC Rules, Part 15, Class A
Australian EMC Framework (RCM)
Japan VCCI, Class A
Industry Canada, ICES-003, Class A
EU (CE Mark)
Korea KC-RRA, Class A
Compatibele producten
SR630
SR650
SR850
SR860
SR950
Minimale systeemeisen
Ondersteunt Linux
Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2
Andere ondersteundende systemen
VMware vSphere ESXi
Ondersteunde server operating systems
Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016
Duurzaamheid
Duurzaamheidscertificaten
RoHS
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85176990
Overige specificaties
Datastroombeheer
Ja
Aantal VLANs
4096
PCI-SIG* SR-IOV Capable
Ja
Receive Side Scaling (RSS)
Ja
