LevelOne GEP-1061 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart
LevelOne GEP-1061, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack-montage
Ruim op voorraad
Fabrikant
LevelOne
MPN
GEP-1061NEUEVERSION
EAN
4015867227350
€ 454,00
excl. BTW
€ 454,00
excl. BTW
excl. BTW
LevelOne GEP-1061 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart
The GEP-1061 is LevelOne latest generation of 10-Port L2 Managed Gigabit PoE Switch, with 2 Gigabit SFP Uplink ports. also offers powerful Web Smart configuration for PoE management, and QoS / VLAN / MSTP / Multi-broadcast / ports management features. Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 20Gbps and bring Gigabit speeds all the way to your computers.
The GEP-1061 PoE-enabled switches features an IEEE 802.3af/at/bt standard, better PoE functionality with 180W PoE power budget and usability. supports up to 2 ports at 90W, or 6 ports at 30W or 8 ports at 15.4W to meet the increasing power demands of users. giving you flexibility in power allocation for a variety of powered devices enabling you to scale your operations to meet business growth, operational cost savings, and ease of management.
The GEP-1061 PoE-enabled switches features an IEEE 802.3af/at/bt standard, better PoE functionality with 180W PoE power budget and usability. supports up to 2 ports at 90W, or 6 ports at 30W or 8 ports at 15.4W to meet the increasing power demands of users. giving you flexibility in power allocation for a variety of powered devices enabling you to scale your operations to meet business growth, operational cost savings, and ease of management.
- With 8 *10/100/1000Mbps PoE ports and 2*1000Mbps SFP ports, with L2 network management
- Total 180W PoE power budget and usability, up to 2 ports at 90W(1-2 port), or 6 ports at 30W or 8 ports at 15.4W
- IEEE 802.3af/at/bt PoE compliant to simplify deployment and installation
- Support Web Smart configuration for PoE management, and QoS / VLAN / MSTP / Multi-broadcast / ports management features
- 6KV surge protection, 6KV contact / 8KV air ESD protection
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Beheerfuncties
Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Traffic-classificatie
Ja
System event log
Ja
Poorten & interfaces
Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Combo SFP-poorten
2
Fibre channel-poorten
2
Vezel-optische connector
SFP
Console port
RJ-45
Netwerk
Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Port mirroring
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Spanning tree protocol
Ja
Kabellengtedetectie
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN
Aantal VLANs
4000
Optische vezel
Fiber ethernet cabling technologie
100BASE-X, 1000BASE-X
Data-uitwisseling
Switchingcapaciteit*
20 Gbit/s
Verzending snelheid
14,9 Mpps
MAC-adrestabel*
8000 entries
Store-and-forward
Ja
Aantal trunks
8
Aantal wachtrijen
8
Statische route
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
10000
Packet buffergeheugen
4,1 MB
Beveiliging
DHCP-functies
DHCP client, DHCP snooping
Access Control List (ACL)
Ja
Regels voor toegangscontrolelijst (ACL)
512
IGMP snooping
Ja
MAC adres filtering
Ja
SSH/SSL support
Ja
BPDU filtering / bescherming
Ja
Wachtwoordbeveiliging
Ja
DoS aanval preventie
Ja
Multicast-functies
Multicast-ondersteuning
Ja
Protocollen
IPv4- & IPv6-functies
IPv6 Telnet, IPv6 ping, IPv6 tracert
Design
Rack-montage*
Ja
Stapelbaar*
Nee
Kleur van het product
Zwart
Reset button
Ja
LED-indicatoren
Activiteit, Link, Stroom
Land van herkomst
China
Certificering
CE class A, FCC, UL, VCCI, BSMI
Prestatie
Intern geheugen
32 MB
Telnet
Ja
Energie
Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Stroomverbruik (typisch)
80 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)*
Ja
Hoeveelheid Power over Ethernet (PoE) ports
8
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
125 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
-10 - 50 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 95 procent
Gewicht en omvang
Breedte
181 mm
Diepte
270 mm
Hoogte
44 mm
Gewicht
800 g
Verpakking
Meegeleverde kabels
AC, LAN (RJ-45)
Snelstartgids
Ja
Type verpakking
Blister
Rekbevestigingspakket
Ja
Ondersteunings-cd
Ja
Breedte verpakking
255 mm
Diepte verpakking
82 mm
Hoogte verpakking
345 mm
Gewicht verpakking
2 kg
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85176990
