LevelOne GES-2108P netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

LevelOne GES-2108P, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)

Ruim op voorraad

Fabrikant LevelOne
MPN GES-2108P
EAN 4015867229200
€ 116,00 excl. BTW

LevelOne GES-2108P netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

The LevelOne GES-2108P Hilbert gigabit PoE smart lite switch is a next-generation Ethernet Switch offering powerful better PoE functionality and usability that delivers the cost-effectively business and transports Ethernet services via copper connections. GES-2108P delivers 8 (10M/100M/1G) RJ45/PoE+ (Support 802.3at/af, and total up to 112.8W) ports. can be matched with the latest LevelOne IP Locator, the software is the easiest to use switch discovery tool, it can search all Hilbert series switches, instantly know the forgotten IP and other info. Compatible with mainstream Windows and Mac operating systems.

The LevelOne GES-2108P provides high HW performance and environment flexibility for Enterprises. GES-2108P is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership."
  • 8 PoE-Plus Gigabit Ethernet ports supports PoE Watchdog
  • Total PoE power budget: 112.8W, up to 30W per port
  • IEEE 802.3af/at PoE compliant to simplify deployment and installation
  • 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
  • Supports 4K MAC address auto-learning and auto-aging
  • 9K jumbo frames to increase data transfer rates
  • IP Multicast Filtering through IGMP Snooping V1 / V2
  • 802.1Q tag-based VLAN allows network segmentation to enhance performance and security
  • IEEE 802.1p QoS with 4 priority queues
  • Supports unknown unicast / broadcast / multicast storm control
  • Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
  • 4KV surge protection, 6KV contact / 8KV air ESD protection
  • Web-based and smart lite Management
  • Supports LevelOne IP Locator for easier IP management

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
8

Netwerk

Netwerkstandaard*
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Port mirroring
Ja
Full duplex
Ja
Half-duplex
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Auto MDI/MDI-X
Ja
Auto-negotiation
Ja
MAC-adres zelflerende functie
Ja
MAC-adres zelfverouderende functie
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Tagged VLAN
Aantal VLANs
32

Data-uitwisseling

Switchingcapaciteit*
16 Gbit/s
MAC-adrestabel*
4000 entries
Aantal wachtrijen
4
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000
Packet buffergeheugen
1,5 MB

Beveiliging

IGMP snooping
Ja

Multicast-functies

Multicast-ondersteuning
Ja

Design

Rack-montage*
Nee
Kleur van het product
Zwart
LED-indicatoren
Activiteit, Link, Power over Ethernet (PoE)
Land van herkomst
China
Certificering
UKCA, FCC Class A

Prestatie

Flash memory
2 MB
Fanloos
Ja
Mean time between failures (MTBF)
43800 uur

Technische details

Aantal dozen per pallet (lucht)
18 stuk(s)

Technische details

Pallet brutolengte
80 cm
Pallet brutobreedte
120 cm
Pallethoogte (lucht)
158,4 cm

Energie

Stroombron*
DC/PoE
Vermogenstoevoer inclusief*
Ja
DC voltage input
54 V
Stroom
2.2 A
Vermogensverbruik (max)
120 W
Spanningsbeveiliging
Ja
Overspanningsbeveiliging in voltage
8 kV

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Aantal Power over Ethernet plus (PoE +)-poorten
8
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
112,8 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
27,3 BTU/h

Gewicht en omvang

Breedte
160 mm
Diepte
95 mm
Hoogte
29 mm
Gewicht
400 g

Verpakking

Meegeleverde kabels
AC
Inclusief AC-adapter
Ja
Type verpakking
Doos
Breedte verpakking
310 mm
Diepte verpakking
230 mm
Hoogte verpakking
65 mm
Gewicht verpakking
1,3 kg

Duurzaamheid

Naleving van duurzaamheid
Ja
Duurzaamheidscertificaten
CE, RoHS

Logistieke gegevens

Netto gewicht kartonnen doos
600 g
(Buitenste) hoofdverpakking breedte
350 mm
(Buitenste) hoofdverpakking lengte
330 mm
(Buitenste) hoofdverpakking hoogte
480 mm
(Buitenste) hoofdverpakking brutogewicht
13,6 kg
Hoeveelheid per (buitenste) hoofdverpakking
10 stuk(s)
