LevelOne GTL-2661, Managed, L2, Gigabit Ethernet (10/100/1000), Rack-montage

Ruim op voorraad

Fabrikant LevelOne
MPN GTL-2661
EAN 4015867203057

LevelOne GTL-2661 Managed L2 Gigabit Ethernet (10/100/1000) Zwart

The GTL-2661 series includes high performance Gigabit Ethernet Layer2 switches featuring 26 ports; 24 10/100/1000BASE-T ports, two 10G SFP+ ports, and one 10G expansion slot for a dual port module. The switch is ideal for high performance server aggregations, such as enterprise data centers, where it can connect high end or network attached file servers through fiber ports. It can also deployed as a backbone upgrade, or to provide Gigabit to the desktop for power users. This switch is packed with features and is a cost effective solution that brings continuous availability, enhanced security, and advanced QoS to the network edge, while maintaining simplicity of management.
  • 24 Gigabit Ethernet ports and 2 10-Gigabit SFP+ slots
  • IEEE 802.3ad LACP for auto port aggregation
  • IEEE 802.1d/w/s Spanning Tree Protocol (STP) and port mirroring
  • Provides QoS control based on IP DSCP for advanced traffic prioritization and bandwidth management
  • MLD, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, and TFTP Management
  • Dynamic ARP Inspection (DAI) protects switches against ARP spoofing
  • Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
  • Supports IPv4/IPv6 network operation

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja
Traffic-classificatie
Ja
System event log
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF+
2
Console port
RJ-45

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Ja
Koperen ethernetbekabelingstechnologie
10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Spanning tree protocol
Ja
Kabellengtedetectie
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Tagged VLAN, MAC address-based VLAN, Port-based VLAN

Data-uitwisseling

Switchingcapaciteit*
88 Gbit/s
Verzending snelheid
65,5 Mpps
MAC-adrestabel*
16000 entries
Store-and-forward
Ja
Aantal wachtrijen
8
Statische route
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
10000
Packet buffergeheugen
12 MB

Beveiliging

DHCP-functies
DHCP snooping, DHCP relay, DHCPv6 snooping, DHCP client
Access Control List (ACL)
Ja
Statische poort beveiliging
Ja
SSH/SSL support
Ja
BPDU filtering / bescherming
Ja
Wachtwoordbeveiliging
Ja
DoS aanval preventie
Ja

Protocollen

Beheerprotocollen
MLD, Telnet, SNMP V1, V2c & V3, RMON, Web Browser, TFTP
Ondersteunde netwerkprotocollen
IPv4/IPv6

Design

Rack-montage*
Ja

Design

Kleur van het product
Zwart
Reset button
Ja
LED-indicatoren
Activiteit, Link, Stroom
Land van herkomst
China
Veiligheid
UL
Certificering
CE class A, FCC, VCCI, BSMI

Prestatie

Intern geheugen
32 MB
Upgraden van firmware mogelijk
Ja
Telnet
Ja
Fanloos
Ja
Mean time between failures (MTBF)
636219 uur

Energie

Stroombron*
AC
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Stroomverbruik (typisch)
20 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Warmtedissipatie
68,242 BTU/h

Gewicht en omvang

Breedte
220 mm
Diepte
440 mm
Hoogte
44 mm
Gewicht
2,29 kg

Verpakking

Meegeleverde kabels
AC, LAN (RJ-45)
Snelstartgids
Ja
Type verpakking
Doos
Rekbevestigingspakket
Ja
Ondersteunings-cd
Ja
Breedte verpakking
405 mm
Diepte verpakking
580 mm
Hoogte verpakking
80 mm
Gewicht verpakking
3,02 kg

Logistieke gegevens

(Buitenste) hoofdverpakking breedte
340 mm
(Buitenste) hoofdverpakking lengte
600 mm
(Buitenste) hoofdverpakking hoogte
435 mm
Code geharmoniseerd systeem (HS)
85176990
(Buitenste) hoofdverpakking brutogewicht
11 kg
Hoeveelheid per (buitenste) hoofdverpakking
4 stuk(s)
