LevelOne GTU-5211 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Zwart

LevelOne GTU-5211, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Rack-montage

Ruim op voorraad

Fabrikant LevelOne
MPN GTU-5211
EAN 4015867230961
€ 275,00 excl. BTW

LevelOne GTU-5211 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Zwart

Gigabit Speeds: Take Your Data to the Next Level

The GTU-5211 is a 52-port Gigabit Ethernet Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 176Gbps and bring Gigabit speeds all the way to your computers.

Bandwidth hungry? Not a problem.

What happens when you have several users accessing multimedia applications all at the same time? No need to worry as GTU-5211 allows you to move large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files over the network instantly and without lag.

Plug and Play, Flexible and Easy

The GTU-5211 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.
  • 48 Gigabit Ethernet ports and 4 10-Gigabit SFP+ slots
  • Supports 32K MAC address auto-learning and auto-aging
  • 10K jumbo frames to increase data transfer rates
  • IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
  • Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
48
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
48
Aantal geïnstalleerde SFP+ modules*
4
Netstekker
AC-in-aansluiting

Netwerk

Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Ja
Full duplex
Ja
Datastroombeheer
Ja
Auto MDI/MDI-X
Ja
MAC-adres zelflerende functie
Ja
MAC-adres zelfverouderende functie
Ja

Data-uitwisseling

Switchingcapaciteit*
176 Gbit/s
MAC-adrestabel*
32000 entries
Jumbo Frames ondersteuning
Ja
Jumbo frames
10000
Packet buffergeheugen
16 MB

Design

Rack-montage*
Ja
Stapelbaar*
Nee
Kleur van het product
Zwart
LED-indicatoren
Activiteit, Link, Stroom
Certificering
CE, UKCA, FCC Part 15, Subpart B Class B, RoHS

Prestatie

Intern geheugen
256 MB
Flash memory
16 MB
Geluidsniveau
30 dB

Prestatie

Fanloos
Nee

Energie

Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50/60 Hz
Stroomverbruik (typisch)
48 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
163,8 BTU/h

Gewicht en omvang

Breedte
440 mm
Diepte
290 mm
Hoogte
44,5 mm
Gewicht
3,39 kg

Verpakking

Meegeleverde kabels
AC
Snelstartgids
Ja
Type verpakking
Doos
Rekbevestigingspakket
Ja
Breedte verpakking
515 mm
Diepte verpakking
380 mm
Hoogte verpakking
93 mm
Gewicht verpakking
4 kg
