LevelOne IGP-1061 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

LevelOne IGP-1061, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)

Ruim op voorraad

Fabrikant LevelOne
MPN IGP-1061
EAN 4015867227886
€ 286,00 excl. BTW

LevelOne IGP-1061 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

The LevelOne IGP-1061 L2 Managed Gigabit PoE Industrial Switch, provides 8 PoE ports 10/100/1000Base plus 2 port Gigabit SFP to enable high speed network at mission-critical environment. With the industrial standard DIN-rail mount, plus the clearly visible status LEDs provide simple monitoring of port link activity. Moreover, the SFP slots support pluggable modules that enabling you to choose from a variety of transceivers. This switch is Power Sourcing Equipment (PSE), and it is fully complied with IEEE802.3af/at/bt PoE standard at maximum 90W(1-2 port) power budget. It helps to save infrastructure wiring costs dramatically by eliminating electric wiring and less UPS needed.
  • 8 Gigabit PoE ports and 2 Gigabit SFP ports
  • Port 1~2 10/100/1000Base-T RJ45(IEEE 802.3bt) PoE 90W
  • Port 3~8 support IEEE 802.3at Power over Ethernet Plus (PoE+)
  • Compatible with IEEE802.3af/at/bt
  • Support L2 management, such as QoS, VLAN, MSTP, Multi-brocast, ports management and PoE management
  • Supports ERPS for ring topology
  • 6KV surge protection, 8KV contact /15KV air ESD protection
  • Provides DIN-rail, wall or desktop mounting
  • 40°C to 75°C operating temperature range

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja
ARP-inspectie
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
8
Aantal geïnstalleerde SFP modules*
2
Console port
RJ-45

Netwerk

Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Koperen ethernetbekabelingstechnologie
10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Spanning tree protocol
Ja
Auto-negotiation
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN

Data-uitwisseling

MAC-adrestabel*
8000 entries
Statische route
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
10000

Beveiliging

DHCP-functies
DHCP Option 82, DHCP client, DHCP relay, DHCP snooping
MAC adres filtering
Ja
BPDU filtering / bescherming
Ja
Wachtwoordbeveiliging
Ja

Multicast-functies

Multicast-ondersteuning
Ja

Design

Rack-montage*
Nee
Kleur van het product
Zwart

Design

LED-indicatoren
Activiteit, Link, Power over Ethernet (PoE), Stroom
DIN rail bevestiging
Ja
Land van herkomst
China
Certificering
CE, RoHS

Prestatie

Intern geheugen
1024 MB
Flash memory
128 MB
Fanloos
Ja
Mean time between failures (MTBF)
338634 uur

Energie

Stroombron*
DC
DC voltage input
48 - 57 V
Stroomverbruik (typisch)
5 W
Vermogensverbruik (max)
380 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Vermogen per poort Power over Ethernet (PoE)
10 W
Totaal Power over Ethernet (PoE)-budget
360 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-40 - 75 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 95 procent
Luchtvochtigheid bij opslag
0 - 95 procent

Gewicht en omvang

Breedte
165 mm
Diepte
115 mm
Hoogte
50 mm
Gewicht
500 g

Verpakking

Snelstartgids
Ja
Type verpakking
Doos
Breedte verpakking
270 mm
Diepte verpakking
181 mm
Hoogte verpakking
74 mm
Gewicht verpakking
1,13 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
