LevelOne AX3000 3000 Mbit/s Wit Power over Ethernet (PoE)

LevelOne AX3000, 3000 Mbit/s, 574 Mbit/s, 2401 Mbit/s, 10,100,1000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, 10/100/1000Base-T(X)

Ruim op voorraad

Fabrikant LevelOne
MPN WAB-8021
EAN 4015867231630
€ 161,00 excl. BTW

LevelOne AX3000 3000 Mbit/s Wit Power over Ethernet (PoE)

The LevelOne WAB-8021 is a standalone, AX3000 Omni-directional outdoor dual-band Wi-Fi 6 PoE wireless access point that features Gigabit Ethernet ports and advanced 802.11ax Wave 2 MU-MIMO (Multi-User Multiple-Input Multiple-Output), allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. capable of a combined speed of up to 2976 Mbps(574Mbps in 2.4GHz/2401Mbps in 5GHz) and Omni-directional outdoor transmission distance of up to 100m.

The device runs on 2.4 and 5 GHz frequency, It also offers support for the new WPA3 encryption. Of course, the WAB-8021 is also equipped with PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP67 means the WAB-8021 is designed for outdoor deployments, and can withstand rain, humidity, dust and snow. A fast, versatile and secure access point for a wide variety of outdoor network requirements.
  • Provides wireless speeds of up to 3000Mbps(574Mbps in 2.4GHz/2401Mbps in 5GHz)
  • OFDMA and MU-MIMO support
  • Compatible with IEEE 802.11a/b/g/n/ac/ax Wave 2 wireless standards
  • Built-in 2 x 2 MIMO antenna
  • Multi-operation modes to suit different wireless applications
  • Provides up to 8 SSIDs to separate network traffic
  • High power and receiver sensitivity designed to boost your signal coverage and link speed
  • Supports WPA3 encryption
  • Weatherproof IP67-rated housing

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

2,4 GHz*
Ja
5 GHz*
Ja
6 GHz*
Nee
Maximale overdrachtssnelheid van gegevens*
3000 Mbit/s
Maximale overdrachtssnelheid van gegevens (2.4 GHz)
574 Mbit/s
Maximale overdrachtssnelheid van gegevens (5 GHz)
2401 Mbit/s
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Netwerkstandaard
IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Bekabelingstechnologie
10/100/1000Base-T(X)
Aantal kanalen
165 kanalen
MIMO
Ja
MIMO-type
Multi User MIMO
Spread spectrum methode
OFDMA
Maximum outdoorbereik
100 m
Gevoeligheid ontvanger
2.4 GHz Radio : l 802.11b / 1Mbps / RX Sensitivity : -90 (dBm) l 802.11b / 11Mbps / RX Sensitivity : -85 (dBm) l 802.11g / 6Mbps / RX Sensitivity : -90 (dBm) l 802.11g / 54Mbps / RX Sensitivity : -72 (dBm) l 802.11n HT20 / MCS0 / RX Sensitivity : -87 (dBm) l 802.11n HT20 / MCS7 / RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX Sensitivity : -85 (dBm) l 802.11n HT40 / MCS7 / RX Sensitivity : -68 (dBm) l 802.11ax HE20 / MCS0 / RX Sensitivity : -83 (dBm) l 802.11ax HE20 / MCS11 / RX Sensitivity : -60 (dBm) l 802.11ax HE40 / MCS0 / RX Sensitivity : -83 (dBm) l 802.11ax HE40 / MCS11 / RX Sensitivity : -56 (dBm) 5 GHz Radio : l 802.11a HT20 / 6Mbps/ RX Sensitivity : -92 (dBm) l 802.11a HT20 / 54Mbps/ RX Sensitivity : -72 (dBm) l 802.11n HT20 / MCS0 / RX Sensitivity : -90 (dBm) l 802.11n HT20 / MCS7 / RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX Sensitivity : -88 (dBm) l 802.11n HT40 / MCS7 / RX Sensitivity : -68 (dBm) l 802.11ac VHT20 / MCS0 / RX Sensitivity : -88 (dBm) l 802.11ac VHT20 / MCS8 / RX Sensitivity : -70 (dBm) l 802.11ac VHT40 / MCS0 / RX Sensitivity : -88 (dBm) l 802.11ac VHT40 / MCS7 / RX Sensitivity : -68 (dBm) l 802.11ac VHT80 / MCS0 / RX Sensitivity : -85 (dBm) l 802.11ac VHT80 / MCS9 / RX Sensitivity : -58 (dBm) l 802.11ax HE20 / MCS0 / RX Sensitivity : -88 (dBm) l 802.11ax HE20 / MCS11 / RX Sensitivity : -62 (dBm) l 802.11ax HE40 / MCS0 / RX Sensitivity : -86 (dBm) l 802.11ax HE40 / MCS11 / RX Sensitivity : -58 (dBm) l 802.11ax HE80 / MCS0 / RX Sensitivity : -84 (dBm) l 802.11ax HE80 / MCS11 / RX Sensitivity : -55 (dBm) l 802.11ax HE160 / MCS0 / RX Sensitivity : -82 (dBm) l 802.11ax HE160 / MCS11 / RX Sensitivity : -51 (dBm)

Beveiliging

Ondersteunde beveiligingsalgoritmen*
WPA2, WPA3
Aantal SSID-ondersteuningen
8

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
1
WAN-poort
Wi-Fi

Energie

Power over Ethernet (PoE)*
Ja
Stroomverbruik (typisch)
16 W

Design

Plaatsing*
Paal
Kleur van het product*
Wit
Internationale veiligheidscode (IP)
IP67
LED-indicatoren
Stroom, Status, Systeem
Land van herkomst
China

Antenne

Soort antenne*
Intern
Type antennerichting
Omni-directioneel

Prestatie

Flash memory
128 MB
Intern geheugen
512 MB

Gewicht en omvang

Breedte
230 mm
Diepte
107 mm
Hoogte
38 mm
Gewicht
1,3 kg

Verpakking

Breedte verpakking
380 mm
Diepte verpakking
230 mm
Hoogte verpakking
107 mm
Gewicht verpakking
1,73 kg
Type verpakking
Doos

Inhoud van de verpakking

Aantal producten inbegrepen
1 stuk(s)
Montage gereedschap
Ja
Snelstartgids
Ja

Overige specificaties

Draadloze standaard
IEEE 802.11a/b/g/n/ac/ax

Eisen aan de omgeving

Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Bedrijfstemperatuur (T-T)
-20 - 50 °C
Temperatuur bij opslag
-20 - 80 °C
Luchtvochtigheid bij opslag
5 - 95 procent

Duurzaamheid

Duurzaamheidscertificaten
CE, RoHS
