LevelOne WAP-8121 433 Mbit/s Wit Power over Ethernet (PoE)

LevelOne WAP-8121, 433 Mbit/s, 10,100,1000 Mbit/s, 2.4 - 5.825 GHz, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n,..., 80 gebruiker(s), 36 kanalen

Ruim op voorraad

Fabrikant LevelOne
MPN WAP-8121
EAN 4015867199190
€ 84,00 excl. BTW

LevelOne WAP-8121 433 Mbit/s Wit Power over Ethernet (PoE)

- Compatible with IEEE 802.11a/b/g/n/ac wireless standards
- Multi-operation modes to suit different wireless applications
- IEEE 802.3af PoE compliant to simplify deployment and installation
- Provides up to 8 SSIDs to separate network traffic and enhance security
- Auto Channel Selection for low interference band

"The LevelOne WAP-8121 is a sophisticated, fast dual-band managed wireless access point, offering up to 450 Mbps on the 5 GHz band and up to 300 Mbps on the 2.4 GHz band. It provides a combined throughput of 750 Mbps using 802.11ac standards. The advanced wireless access point also supports all legacy wireless devices on 802.11a/b/g/n. WAP-8121 performs automatic testing and assigns channels dynamically to detect conflicts and channel interference, constantly optimising performance in the background. The device runs on PoE, negating the need for electrical wiring.
Central management allows for adjustments to the RF (Radio Frequency) (according to )the environment, further optimising the performance of the network by adjusting and balancing workloads as well as detecting areas of weak reception. it provides WEP, WPA-PSK, WPA-TKIP, and WPA2 AES secured connectivity for securing the Wireless Area Network and to prevent unauthorized access. The device supports up to four(Eight) SSIDs allowing unique configuration settings for different network regions. The sophisticated and stylish access point mounts on a ceiling, providing a low-profile, highly effective networking solution.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

2,4 GHz*
Ja
5 GHz*
Ja
Maximale overdrachtssnelheid van gegevens*
433 Mbit/s
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s
Frequentieband
2.4 - 5.825 GHz
Netwerkstandaard
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Aantal gebruikers
80 gebruiker(s)
Aantal kanalen
36 kanalen
Automatische kanaalselectie
Ja
Modulatie
16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wifi Multimedia (WMM)/(WME)
Ja
Datastroombeheer
Ja
Quality of Service (QoS)
Ja
Gevoeligheid ontvanger
2.4GHz: 802.11n (20MHZ): -70 dBm 802.11n (40MHZ): -68 dBm 802.11g: -72 dBm 802.11b: -95 dBm 5GHz: 802.11ac (80MHZ): -62 dBm 802.11ac (40MHZ): -65 dBm 802.11ac (20MHZ): -68 dBm 802.11n (40MHZ): -68 dBm 802.11n (20MHZ): -70 dBm 802.11a: -72 dBm

Beveiliging

Ondersteunde beveiligingsalgoritmen*
64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
Service Set Identifier (SSID) functies
SSID-broadcast aan/uit
Aantal SSID-ondersteuningen
8

Beheerfuncties

Web-gebaseerd management
Ja
Switch type
Managed
Upgraden van firmware mogelijk
Ja

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
2
WAN-poort
Ethernet (RJ-45), Wi-Fi
Aansluiting voor netstroomadapter
Ja

Energie

Power over Ethernet (PoE)*
Ja
Spanning
12 V
Output current
1,5 A
Stroomverbruik (typisch)
15 W

Design

Plaatsing*
Plafond, Muur
Kleur van het product*
Wit
Reset button
Ja
LED-indicatoren
Stroom, WLAN
Certificering
CE/FCC
Intern
Nee

Antenne

Type antennerichting
Omni-directioneel
Antennefuncties
Ingebouwde antenne
Antennas quantity
3
Antenne versterkingsniveau (max)
15 dBi

Gewicht en omvang

Breedte
189 mm
Diepte
38,5 mm
Hoogte
189 mm
Gewicht
326 g

Verpakking

Breedte verpakking
214 mm
Diepte verpakking
62 mm
Hoogte verpakking
317 mm
Gewicht verpakking
680 g

Inhoud van de verpakking

Meegeleverde kabels
LAN (RJ-45)
Snelstartgids
Ja

Eisen aan de omgeving

Relatieve vochtigheid in bedrijf (V-V)
-20 - 50 procent
Bedrijfstemperatuur (T-T)
-40 - 70 °C
Temperatuur bij opslag
5 - 90 °C
Luchtvochtigheid bij opslag
10 - 90 procent

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
