LevelOne WAP-8131 draadloos toegangspunt (WAP) 1800 Mbit/s Wit Power over Ethernet (PoE)

LevelOne WAP-8131, 1800 Mbit/s, 574 Mbit/s, 1201 Mbit/s, 2.412 - 2.484, 5.18G -5.825, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3,..., 165 kanalen

Ruim op voorraad

Fabrikant LevelOne
MPN WAP-8131
EAN 4015867227879
€ 268,00 excl. BTW

LevelOne WAP-8131 draadloos toegangspunt (WAP) 1800 Mbit/s Wit Power over Ethernet (PoE)

The LevelOne WAP-8131 is a standalone, AX1800 dual-band Wi-Fi 6 PoE wireless access point that features dual Gigabit Ethernet ports and advanced 802.11ax Wave 2 MU-MIMO (Multi-User Multiple-Input Multiple-Output), allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. capable of a combined speed of up to 1775 Mbps.
The WAP-8131 provides 2.4 and 5 GHz frequencies and can be used as a high-quality stand-alone access point in a corporate environment or for demanding installations. It also offers support for the new WPA3 encryption. Of course, the WAP-8131 is also equipped with PoE, which eliminates the need for an external power supply, simplifying installation. A fast, versatile and secure access point for a variety of network requirements, especially when high speeds are important for many users.
  • Provides wireless speeds of up to 1800Mbps(574Mbps in 2.4GHz/1201Mbps in 5GHz)
  • OFDMA and MU-MIMO support
  • Compatible with IEEE 802.11a/b/g/n/ac/ax Wave 2 wireless standards
  • Built-in 2 x 2 MIMO antenna
  • Multi-operation modes to suit different wireless applications
  • Dual power support: 12V DC/PoE (IEEE 802.3at)
  • Provides up to 8 SSIDs to separate network traffic
  • High power and receiver sensitivity designed to boost your signal coverage and link speed
  • Supports WPA3 encryption, compatible with WPA2/WPA

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

2,4 GHz*
Ja
5 GHz*
Ja
6 GHz*
Nee
Maximale overdrachtssnelheid van gegevens*
1800 Mbit/s
Maximale overdrachtssnelheid van gegevens (2.4 GHz)
574 Mbit/s
Maximale overdrachtssnelheid van gegevens (5 GHz)
1201 Mbit/s
Frequentieband
2.412 - 2.484, 5.18G -5.825
Netwerkstandaard
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Aantal kanalen
165 kanalen
MIMO
Ja
MIMO-type
Multi User MIMO
Spread spectrum methode
OFDMA
Bedrijfsmodi
Gateway, Repeater, AP

Beveiliging

Ondersteunde beveiligingsalgoritmen*
AES, WPA, WPA2, WPA3
Service Set Identifier (SSID) functies
Multiple SSIDs
Aantal SSID-ondersteuningen
8

Beheerfuncties

Web-gebaseerd management
Ja

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
2
Aansluiting voor netstroomadapter
Ja

Energie

Power over Ethernet (PoE)*
Ja
Vermogensverbruik (max)
14 W

Design

Plaatsing*
Plafond, Muur
Kleur van het product*
Wit
LED-indicatoren
Status
Land van herkomst
China

Antenne

Soort antenne*
Intern
Antennas quantity
4
Antenne versterkingsniveau (max)
4 dBi

Prestatie

Chipset
Qualcomm IPQ6000

Prestatie

Flash memory
128 MB
Intern geheugen
512 MB

Technische details

Aantal dozen per pallet (lucht)
10 stuk(s)
Pallet nettohoogte
164,4 cm
Pallet nettodiepte
80 cm
Pallet nettobreedte
120 cm

Gewicht en omvang

Breedte
186 mm
Diepte
186 mm
Hoogte
42,5 mm
Gewicht
418,5 g

Verpakking

Breedte verpakking
243 mm
Diepte verpakking
235 mm
Hoogte verpakking
76 mm
Gewicht verpakking
750 g

Inhoud van de verpakking

Meegeleverde kabels
LAN (RJ-45)
Snelstartgids
Ja

Eisen aan de omgeving

Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Bedrijfstemperatuur (T-T)
0 - 55 °C
Temperatuur bij opslag
0 - 70 °C
Luchtvochtigheid bij opslag
5 - 90 procent

Duurzaamheid

Naleving van duurzaamheid
Ja
Duurzaamheidscertificaten
CE, RoHS

Logistieke gegevens

(Buitenste) hoofdverpakking breedte
410 mm
(Buitenste) hoofdverpakking lengte
520 mm
(Buitenste) hoofdverpakking hoogte
500 mm
(Buitenste) hoofdverpakking brutogewicht
16 kg
Hoeveelheid per (buitenste) hoofdverpakking
20 stuk(s)
